| Ref | Part Number | Description |
|---|
| 1 |
112-1350 |
STARTER ASM This part replaces 70-8760. Price: $448.98 |
| 1 |
772108A |
Transaxle Cover Price: Call Us |
| 2 |
67-4610 |
BOLT W/WASHER Price: $2.32 |
| 2 |
780086A |
Needle Bearing Price: Call Us |
| 3 |
70-8770 |
FRONT BRACKET ASM Price: $181.75 |
| 3 |
770102A |
Transaxle Case Price: Call Us |
| 4 |
67-4720 |
LEVER ASSEMBLY Price: $19.98 |
| 4 |
776260A |
Countershaft Price: Call Us |
| 5 |
67-4730 |
DISCONTINUED Price: Call Us |
| 5 |
776219B |
Output Shaft & Pinion Price: Call Us |
| 6 |
70-8780 |
DISCONTINUED Price: Call Us |
| 6 |
778139 |
Output Gear Price: Call Us |
| 7 |
56-1560 |
SWITCH ASM This part replaces 67-4750. Price: $440.70 |
| 7 |
778136 |
Spur Gear (15 teeth-steel) Price: Call Us |
| 8 |
56-1570 |
BOLT Price: $6.29 |
| 8 |
792136A |
Shifter Key Price: Call Us |
| 9 |
56-1680 |
COVER SET Price: $20.80 |
| 9 |
784352 |
Shifter Collar Price: Call Us |
| 10 |
56-1670 |
GEAR Price: $119.60 |
| 10 |
784355 |
Shift Rod & Fork Price: Call Us |
| 11 |
67-4790 |
DISCONTINUED Price: Call Us |
| 11 |
778229 |
Bevel Gear (42 teeth-steel) Price: Call Us |
| 12 |
67-4780 |
GEAR SET Price: $434.34 |
| 12 |
778113A |
Input Bevel Pinion Price: Call Us |
| 13 |
56-1640 |
STOPPER SET Price: $18.99 |
| 13 |
778221 |
Bevel Gear Price: Call Us |
| 14 |
67-4770 |
PINION SET Price: $192.09 |
| 14 |
778068 |
Bevel Pinion Gear Price: Call Us |
| 15 |
67-4760 |
SHAFT ASSEMBLY Price: $835.38 |
| 15 |
778260 |
Ring Gear Price: Call Us |
| 16 |
56-1610 |
BOLT Price: $6.86 |
| 17 |
56-1720 |
REAR BRKT Price: $150.01 |
| 17 |
786139 |
Drive Pin Price: Call Us |
| 18 |
786102 |
Spacer Price: Call Us |
| 18 |
93-3573 |
HOLDER ASSY-BRUSH This part replaces 56-1700. Price: $83.00 |
| 19 |
56-1710 |
DISCONTINUED Price: Call Us |
| 20 |
112-1350 |
STARTER ASM This part replaces 67-4800. Price: $448.98 |
| 20 |
792077 |
Steel Ball 5/16" dia. Price: Call Us |
| 21 |
792078 |
Set Screw 3/18-16 x 3/8" Price: Call Us |
| 21 |
93-3564 |
BEARING REAR This part replaces 56-1600. Price: $33.38 |
| 22 |
56-1590 |
FRONT BRG Price: $44.07 |
| 22 |
792079 |
Spring Price: Call Us |
| 23 |
788061 |
Seal Ring Price: Call Us |
| 25 |
792073 |
Screw 1/4-20 x 1-1/4" Price: Call Us |
| 26 |
792125 |
Retaining Ring (pkg of 2) Price: Call Us |
| 27 |
792035 |
Retaining Ring Price: Call Us |
| 28 |
788040 |
Retaining Ring Price: Call Us |
| 29 |
780072 |
Thrust Washer Price: Call Us |
| 30 |
780108 |
Thrust Washer Price: Call Us |
| 31 |
780001 |
Washer Price: Call Us |
| 34 |
780105A |
Flanged Bushing Price: Call Us |
| 35 |
780118A |
Flanged Bushing Price: Call Us |
| 36 |
790003 |
Brake Disk Price: Call Us |
| 37 |
790007 |
Brake Pad Plate Price: Call Us |
| 38 |
799021 |
Brake Pad (pkg of 2) Price: Call Us |
| 39 |
786026 |
Dowel Pin Price: Call Us |
| 40 |
792076A |
Flat Washer Price: Call Us |
| 42 |
792073 |
Screw 1/4-20 x 1-1/4" Price: Call Us |
| 42A |
792085A |
Screw 1/4-20 x 2-1/4" Price: Call Us |
| 43 |
792075 |
Lock Nut 5/16-24 Price: Call Us |
| 44 |
790025 |
Brake Pad Holder Price: Call Us |
| 46 |
786086 |
Brake Lever Bracket Price: Call Us |
| 47 |
774690 |
Axle (11-15/16" long) Price: Call Us |
| 48 |
774691 |
Axle (16-1/2" long) Price: Call Us |
| 49 |
778215 |
Spur Gear (37 teeth-steel) Price: Call Us |
| 65 |
780109 |
Thrust Washer Price: Call Us |
| 66 |
776135 |
Input Shaft (3.687" long) Price: Call Us |
| 67 |
776315A |
Shifter & Brake Shaft (4-keyed) Price: Call Us |
| 68 |
786116A |
Plug Price: Call Us |
| 69 |
780051 |
Thrust Washer Price: Call Us |
| 70 |
786118 |
Spacer Price: Call Us |
| 71 |
788069 |
Square Cut Seal Price: Call Us |
| 76 |
780090 |
Thrust Washer Price: Call Us |
| 77 |
788078A |
Retaining Ring (pkg of 2) Price: Call Us |
| 79 |
792144 |
Brake Spring Price: Call Us |
| 81 |
786081 |
Roller Chain (No. 41 chain, 24 links) Price: Call Us |
| 82 |
786082 |
Sprocket (9 teeth) Price: Call Us |
| 83 |
792123 |
Sprocket (18 teeth) Price: Call Us |
| 90 |
788067B |
Grease (32 oz. bottle Bentonite Grease) Price: Call Us |
