| Ref | Part Number | Description |
|---|
| 1 |
603-0023 |
PEDESTAL A Not Available Price: |
| 1 |
94-3145 |
SCREW-PULLEY Price: $9.84 |
| 2 |
712-3044 |
NUT, 1/4 WING Not Available Price: |
| 2 |
74-8080 |
WASHER This part replaces 94-3146. Price: $4.77 |
| 3 |
736-0463 |
Washer, Flat, .251 x .62 x .052 Thk Price: $3.91 |
| 3 |
94-3144 |
PULLEY-CRANKSHAFT Price: $766.47 |
| 4 |
74-8100 |
GEAR-PINION Price: $58.79 |
| 4 |
931-3115A |
SIDE PANEL (LH) Not Available This part replaces 731-3115. Price: |
| 5 |
931-3116 |
SIDE-PANEL (RH) Not Available This part replaces 731-3116. Price: |
| 5 |
95-3485 |
Sprocket-Oil Pump Price: Call Us |
| 6 |
74-8120 |
KEY-WOODRUFF Price: $3.36 |
| 6 |
759-3777 |
LABEL KIT L/H SIDE Not Available Price: |
| 7 |
710-0376 |
Screw, 5/16-18 X 1 Znd Hex Hd Cap This part replaces 710-3002. Price: $3.66 |
| 7 |
94-3150 |
SCREW-HH Price: $1.50 |
| 8 |
74-7560 |
LOCKWASHER This part replaces 94-3151. Price: $0.67 |
| 8 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 9 |
703-0008 |
GRILLE HOUSING RETAINER Not Available Price: |
| 9 |
74-8140 |
COVER Price: $137.43 |
| 10 |
731-3099 |
GRILLE INSERT Not Available Price: |
| 10 |
74-8150 |
GASKET-COVER Price: $4.08 |
| 11 |
931-3102 |
GRILLE LENS This part replaces 731-3102. Price: $36.19 |
| 11 |
94-3148 |
SEAL Price: $33.41 |
| 12 |
74-8170 |
BEARING SET (STD) Price: $208.01 |
| 12 |
931-3178 |
GRILLE Not Available This part replaces 731-3178. Price: |
| 13 |
703-1829-0499 |
HOOD HINGE ASSEMBLY (CUB BEIGE) Not Available This part replaces 703-1829. Price: |
| 13 |
94-3141 |
DISCONTINUED Price: Call Us |
| 14 |
710-3214 |
STUD-DOUBLE ENDED Not Available Price: |
| 14 |
74-8230 |
SHAFT-CRANK Price: $3,552.00 |
| 15 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 15 |
94-3147 |
DISCONTINUED Price: Call Us |
| 16 |
703-1856 |
PLATE, HINGE Not Available Price: |
| 16 |
74-8250 |
PIN This part replaces 74-7990. Price: $0.97 |
| 17 |
710-0748 |
SCREW #12-14 x .500 Not Available Price: |
| 17 |
94-3149 |
GEAR-FLYWHEEL Price: $113.49 |
| 18 |
74-8270 |
DISCONTINUED Price: Call Us |
| 18 |
931-3089B |
HOOD Not Available This part replaces 731-3089A. Price: |
| 19 |
95-3484 |
Screw-HH Price: Call Us |
| 19 |
979-3536 |
LABEL-CCC SCRIPT Not Available This part replaces 779-3536. Price: |
| 20 |
710-3217 |
Screw, Truss Hd, #8-32 x .38 Lg Price: $5.94 |
| 20 |
74-8290 |
DISCONTINUED Price: Call Us |
| 21 |
732-3063A |
Clip, Hood Latch Price: Call Us |
| 21 |
74-8300 |
CLIP-PIN, PISTON Price: $2.96 |
| 22 |
736-0310 |
Washer, Flat, .16 x .38 x .045 Thk Price: $3.50 |
| 22 |
74-8310 |
PIN-PISTON Price: $24.33 |
| 23 |
912-3072 |
HEX NUT KEPS #8-32 Not Available This part replaces 712-3072. Price: |
| 23 |
94-3158 |
PISTON RING SET Price: $233.60 |
| 24 |
911-3296 |
LATCH PIN Not Available This part replaces 711-3296. Price: |
| 24 |
98-9965 |
DISCONTINUED This part replaces 94-3154. Price: Call Us |
| 25 |
710-0286 |
Screw, Phillips Hd Truss Mach, 1/4-20 x .50 Lg Price: $3.86 |
| 25 |
74-8360 |
CONNECTING ROD This part replaces 94-3153. Price: $1,118.95 |
| 26 |
703-1955 |
BRACKET ASSY, LH PANEL MTG Not Available Price: |
| 27 |
703-2162-0499 |
PANEL SCREEN (RH) (CUB BEIGE) Not Available This part replaces 703-2162. Price: |
| 27 |
74-8380 |
DISCONTINUED Price: Call Us |
| 28 |
703-2163 |
PANEL SCREEN (LH) Not Available Price: |
| 28 |
74-8400 |
BOLT-ROD, CONNECTING This part replaces 94-3156. Price: $23.09 |
| 29 |
74-8420 |
PISTON SET Price: $3,551.52 |
| 29 |
94-3157 |
PISTON SET Price: $3,570.53 |
| 33 |
94-3152 |
SCREW-HH Price: $2.62 |
