| Ref | Part Number | Description |
|---|
| 1 |
394941 |
Cylinder Assembly Price: Call Us |
| 2 |
261623 |
Bearing Price: Call Us |
| 3 |
391086 |
Seal-Oil Price: Call Us |
| 9 |
27803 |
Gasket-Breather Price: Call Us |
| 10 |
93394 |
Screw Price: Call Us |
| 11 |
280225 |
Tube-Breather Price: Call Us |
| 12 |
271142 |
Gasket-Crankcase Cover-1/64" thick Price: Call Us |
| 13 |
93111 |
Screw-Cylinder Hd. Price: Call Us |
| 14 |
93113 |
Screw-Cylinder Head Price: Call Us |
| 15 |
91084 |
Plug-Pipe Price: Call Us |
| 16 |
393382 |
Crankshaft Price: Call Us |
| 18 |
393552 |
Base Assembly-Crankcase Price: Call Us |
| 20 |
291675 |
Seal-Oil Price: Call Us |
| 22 |
93882 |
Screw-Crankcase Cover Mtg. Price: Call Us |
| 24 |
222698 |
Key Price: Call Us |
| 25 |
394955 |
Piston Assembly-Std. Price: Call Us |
| 26 |
394959 |
Ring Set-Piston-Std Price: Call Us |
| 27 |
260924 |
Lock-Piston Pin Price: Call Us |
| 28 |
299691 |
Pin-Piston (Std.) Price: Call Us |
| 29 |
393270 |
Rod Assembly-Connecting Note: For Connecting Rod with .020" undersize Crankpin Bore-Order No.393714. Price: Call Us |
| 31 |
220863 |
Washer Price: Call Us |
| 32 |
92909 |
Screw-Conn. Rod Price: Call Us |
| 33 |
390420 |
Valve-Exhaust Price: Call Us |
| 34 |
261528 |
Valve-Intake Uses: Seal Assembly and Retainer (Ref. No.868) Price: Call Us |
| 35 |
65906 |
Spring-Valve Price: Call Us |
| 36 |
28828 |
Spring-Exhaust Valve Price: Call Us |
| 40 |
221596 |
Retainer-Valve Price: Call Us |
| 41 |
292260 |
Retainer-Valve Price: Call Us |
| 42 |
93630 |
Retainer-Rotocoil Price: Call Us |
| 45 |
261368 |
Tappet-Valve Price: Call Us |
| 46 |
212337 |
Gear-Cam (Used with Electronic Ignition) Price: Call Us |
| 120 |
92290 |
Washer-Lock Price: Call Us |
| 187 |
299146 |
Line-Fuel (28" long) (Cut to Suit) Price: Call Us |
| 219 |
393415 |
Oil Slinger Assembly Price: Call Us |
| 219A |
394348 |
Gear-Governor Price: Call Us |
| 220 |
222773 |
Washer-Thrust Price: Call Us |
| 230 |
220863 |
Washer Price: Call Us |
| 240 |
394358 |
Filter-Fuel Price: Call Us |
| 244 |
230318 |
Connector-Fuel Price: Call Us |
| 284A |
93469 |
Screw Price: Call Us |
| 304 |
393287 |
Housing-Blower Price: Call Us |
| 305 |
93158 |
Screw Price: Call Us |
| 337 |
394539 |
Plug-Spark (Resistor) Price: Call Us |
| 353 |
92791 |
Washer-Lock Price: Call Us |
| 354 |
90576 |
Nut Price: Call Us |
| 356 |
298693 |
Wire-Ground Price: Call Us |
| 358 |
394501 |
Gasket Set Price: Call Us |
| 383 |
89838 |
Wrench-Plug, Spark Price: Call Us |
| 422 |
222875 |
Clamp-Oil Filter Price: Call Us |
| 506 |
231174 |
Terminal Price: Call Us |
| 507 |
280180 |
Grommet-Insulator Price: Call Us |
| 520 |
93722 |
Terminal Price: Call Us |
| 523 |
394020 |
Cap and Dipstick-Oil Filler Price: Call Us |
| 524 |
271157 |
Seal-FillerTube Price: Call Us |
| 525 |
280224 |
Tube-Oil Filler Price: Call Us |
| 552 |
261559 |
Lower Bushing-Governor Price: Call Us |
| 552A |
261560 |
Upper Bushing-Governor Price: Call Us |
| 556 |
93585 |
Screw-Sem Price: Call Us |
| 567 |
93777 |
Screw Price: Call Us |
| 569 |
270981 |
Gasket-Crankcase Price: Call Us |
| 572 |
222912 |
Baffle-Air(Cyl. #2) Price: Call Us |
| 573 |
392934 |
Back Plate Assembly Price: Call Us |
| 601 |
93053 |
Clamp-Hose Price: Call Us |
| 615 |
93851 |
Retainer-E-Ring Price: Call Us |
| 616 |
394349 |
Crank-Governor Price: Call Us |
| 634A |
271316 |
Foam Seal-Governor Shaft Price: Call Us |
| 635 |
66538 |
Boot-Plug, Spark Price: Call Us |
| 741 |
231445 |
Gear-Timing Price: Call Us |
| 819 |
93686 |
Screw-Hex Head Price: Call Us |
| 842 |
271170 |
Seal-Oil FillerCap Price: Call Us |
| 847 |
394394 |
Dipstick Tube Assembly Price: Call Us |
| 868 |
393606 |
Seal Assembly Retainer Price: Call Us |
| 869 |
261463 |
Seat-Intake Valve Price: Call Us |
| 870 |
210940 |
Seat-Exhaust Valve Price: Call Us |
| 871 |
231218 |
Guide-Valve Price: Call Us |
| 271188 |
Gasket-Crankcase |
Cover-.005" thick Price: Call Us 271188 |
| 271189 |
Gasket-Crankcase |
Cover-.009" thick Price: Call Us 271189 |
| 394956 |
Piston |
Assembly-.010" O.S. Price: Call Us 394956 |
| 394957 |
Piston |
Assembly-.020" O.S. Price: Call Us 394957 |
| 394958 |
Piston |
Assembly-.030" O.S. Price: Call Us 394958 |
| 394960 |
Ring |
Set-Piston-.010" O.S. Price: Call Us 394960 |
| 394961 |
Ring |
Set-Piston-.020" O.S. Price: Call Us 394961 |
| 394962 |
Ring |
Set-Piston-.030" O.S. Price: Call Us 394962 |
