| Ref | Part Number | Description |
|---|
| 1 |
198875 |
SPEED SELECTOR ASSEMBLY Price: Call Us |
| 1 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 2 |
17501010 |
SCREW 10-24 X .625 Price: Call Us |
| 2 |
58-5460 |
VALVE-SELECTOR Price: $479.05 |
| 3 |
340-22 |
FITTING-TEE Price: $90.38 |
| 3 |
402685X428 |
END PLATE Price: Call Us |
| 4 |
115-8017 |
REEL MOTOR KIT This part replaces 93-1412. Price: $1,999.51 |
| 4 |
17490508 |
SCREW 5/16-18 X .50 Price: Call Us |
| 5 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 5 |
57079 |
WASHER Price: Call Us |
| 6 |
405485 |
CONTROL ARM Price: Call Us |
| 7 |
198580 |
CLEVIS PIN Price: Call Us |
| 7 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 8 |
403097X431 |
SHIFTER PLATE Price: Call Us |
| 9 |
33014-00 |
NUT-HEX Price: $0.25 |
| 9 |
402881 |
SHOULDER BOLT Price: Call Us |
| 10 |
403096X431 |
SHIFTER BRACKET Price: Call Us |
| 10 |
48-9530 |
NUT Price: $1.78 |
| 11 |
191730 |
NUT 1/4-20 Price: Call Us |
| 11 |
323-6 |
SCREW-HH Price: $0.66 |
| 12 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 12 |
402856X431 |
CLUTCH PLATE Price: Call Us |
| 13 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 13 |
416717X431 |
CLUTCH BRACKET Price: Call Us |
| 14 |
187101 |
SHIFTER LINK Price: Call Us |
| 14 |
340-93 |
TEE-ADAPTER Price: $57.05 |
| 15 |
105-9271-01 |
BRACKET-BUMPER Price: $84.53 |
| 15 |
700279 |
RETAINER Price: Call Us |
| 16 |
427542 |
CONTROL SHAFT Price: Call Us |
| 16 |
48-3280 |
STOP-BUMP Price: $35.14 |
| 17 |
402568 |
CLUTCH ROD Price: Call Us |
| 17 |
60-0090 |
PIN-PIVOT Price: $93.25 |
| 18 |
169675 |
RETAINER Price: Call Us |
| 18 |
60-0190 |
STRIP Price: $36.98 |
| 19 |
33114-016 |
SCREW-HH Price: $0.27 |
| 19 |
401732 |
SHIFTER YOKE Price: Call Us |
| 20 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
402310 |
PIVOT ROD Price: Call Us |
| 21 |
12000036 |
RETAINER Price: Call Us |
| 21 |
60-0100 |
PIN-PIVOT Price: $94.46 |
| 22 |
402878 |
RETURN SPRING Price: Call Us |
| 23 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 23 |
751153 |
NUT 5/16-18 Price: Call Us |
| 24 |
115-8048-01 |
NO. 4 LIFT ARM ASM This part replaces 92-9296-01. Price: $986.93 |
| 24 |
408981 |
BEARING Price: Call Us |
| 25 |
325-34 |
SCREW-HH Price: $2.37 |
| 25 |
73930500 |
NUT 5/16-18 Price: Call Us |
| 26 |
198176X431 |
RUBBER WHEEL PLATE Price: Call Us |
| 26 |
58-4380 |
PIN Price: $25.11 |
| 27 |
179831 |
RUBBER RING Price: Call Us |
| 27 |
60-1280 |
PIN Price: $3.53 |
| 28 |
175344 |
BEARING Price: Call Us |
| 28 |
60-1350 |
ROD-PUSH Price: $87.82 |
| 29 |
178613 |
WHEEL HUB Price: Call Us |
| 29 |
60-1640 |
STRIP Price: $26.76 |
| 30 |
324-6 |
SCREW-HH Price: $0.81 |
| 30 |
74760514 |
SCREW 5/16-18-.875 Price: Call Us |
| 31 |
115-8049-01 |
NO. 5 LIFT ARM ASM This part replaces 92-9297-01. Price: $924.15 |
| 31 |
12000012 |
RETAINER RING Price: Call Us |
| 32 |
402187 |
SPROCKET SHAFT Price: Call Us |
| 33 |
323-14 |
SCREW-HH Price: $1.34 |
| 33 |
401619 |
CHAIN Price: Call Us |
| 34 |
115-8011 |
CYLINDER-HYD This part replaces 104-5225. Price: $784.12 |
| 34 |
417234 |
SPROCKET WELDMENT Price: Call Us |
| 35 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 35 |
401984X431 |
SHIFTER BRACKET Price: Call Us |
| 36 |
180135 |
SPRING Price: Call Us |
| 37 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 37 |
402652 |
PLATE PIVOT ROD Price: Call Us |
| 38 |
428288 |
E-RING .375 Price: Call Us |
| 39 |
184471 |
SHOULDER SCREW Price: Call Us |
| 39 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 40 |
410877 |
BOTTOM PAN Price: Call Us |
| 40 |
58-2720 |
PIN Price: $49.81 |
| 41 |
115-8045-01 |
NO. 1 LIFT ARM ASM This part replaces 92-9289-01. Price: $977.54 |
| 41 |
413429X431 |
SPRING BRACKET Price: Call Us |
| 42 |
402689 |
DRIVE PLATE ASSEMBLY Price: Call Us |
| 42 |
58-9210 |
CAM Price: $92.20 |
| 43 |
414557 |
IDLER SPRING Price: Call Us |
| 43 |
60-0080 |
BUSHING Price: $14.79 |
| 44 |
178828 |
IDLER SPRING Price: Call Us |
| 44 |
53-5940 |
SCREW Price: $2.90 |
| 45 |
402504 |
PULLEY SHAFT Price: Call Us |
| 45 |
60-1340 |
ROD-PUSH Price: $85.25 |
| 46 |
401820 |
DRIVE PLATE Price: Call Us |
| 46 |
58-3570 |
SPRING Price: $16.80 |
| 47 |
117-8981 |
BUSHING-RUBBER This part replaces 59-7140. Price: $13.27 |
| 47 |
198791 |
BEARING Price: Call Us |
| 48 |
402393 |
PULLEY HALF Price: Call Us |
| 48 |
58-9630 |
SLEEVE Price: $123.35 |
| 49 |
17541008 |
SCREW 10-24 X .50 Price: Call Us |
| 49 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 50 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 50 |
402511 |
SPACER BEARING Price: Call Us |
| 51 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 51 |
418894X431 |
SWING PLATE Price: Call Us |
| 52 |
132010 |
NUT 3/8-16 Price: Call Us |
| 52 |
93-7331 |
DECAL-WARNING Price: $10.35 |
| 53 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 54 |
3217-6 |
NUT-HEX Price: $1.19 |
| 56 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 57 |
3256-26 |
WASHER-FLAT Price: $0.39 |
