| Ref | Part Number | Description |
|---|
| 1 |
547664501 |
KIT.SVC.DECK.WLD.97.EZ_MUL.428 This part replaces 580465302. Price: $449.99 |
| 1 |
63-7440 |
SOLENOID Price: $480.88 |
| 2 |
42-9110 |
GASKET This part replaces 53-8130. Price: $29.21 |
| 2 |
532423062 |
PALNUT 1/4 Price: $2.99 |
| 3 |
84-1910 |
DISCONTINUED Price: Call Us |
| 5 |
68-9400 |
NUT-FLANGE Price: $2.29 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 6 |
66-2360-03 |
MUFFLER SUPPORT ASM This part replaces 66-2360. Price: $48.95 |
| 7 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 8 |
66-2870 |
CABLE-HOOD STOP Price: $27.51 |
| 9 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
93-9991-03 |
BRACKET-CLUTCH ANCHOR This part replaces 93-9991. Price: $15.31 |
| 11 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 12 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 13 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 13 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 14 |
321-3 |
SCREW-HH Price: $0.28 |
| 14 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 15 |
3296-9 |
NUT-HEX Price: $0.25 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 16 |
63-8230 |
ANGLE-CLUTCH ANCHOR Price: $8.43 |
| 17 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 17 |
66-2910 |
BUMPER Price: $1.94 |
| 18 |
3250-39 |
SCREW-PPH Price: $0.25 |
| 18 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 19 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 19 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $12.99 |
| 20 |
66-2900 |
BALLEND-FEMALE Price: $71.56 |
| 21 |
3220-2 |
NUT-JAM Price: $0.50 |
| 22 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 23 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 24 |
43-2740 |
GASKET ME 660042 Price: $8.23 |
| 25 |
3212-5 |
SCREW-HH Price: $2.46 |
| 26 |
63-6290 |
PIN-PTO TENSION Price: $24.06 |
| 27 |
3-6624 |
DISCONTINUED Price: Call Us |
| 27 |
583581401 |
BELT.97CM.ELECTRIC This part replaces 532445834. Price: $54.99 |
| 28 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 29 |
66-3100 |
SCREW-HH Price: $2.58 |
| 30 |
67-1631 |
SPACER Price: $13.71 |
| 31 |
32149-1 |
NUT-KEPS Price: $5.59 |
| 32 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 32 |
583584001 |
SPRING.DRVE.107&97CM.ELEC.DECK This part replaces 532446205. Price: $9.99 |
| 33 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 33 |
92-8799 |
BEARING-FLANGE Price: $126.15 |
| 34 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587256501. Price: $49.99 |
| 34 |
63-6250 |
DISCONTINUED Price: Call Us |
| 35 |
3230-4 |
BOLT-CARR Price: $0.47 |
| 35 |
532427984 |
BLADE.3N1.LH.CRD.97 Price: $49.99 |
| 36 |
256-299 |
BUSHING-STRAIGHT Price: $10.86 |
| 37 |
67-1800 |
DISCONTINUED Price: Call Us |
| 38 |
3-4324 |
WASHER-FLAT Price: $1.22 |
| 39 |
32121-32 |
PIN-ROLL Price: $1.34 |
| 40 |
110-9697 |
ELECTRIC CLUTCH KIT This part replaces 63-6050. Price: $1,166.55 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 41 |
63-8150 |
KEY-SQUARE Price: $9.44 |
| 42 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 42 |
63-6690 |
DISCONTINUED Price: Call Us |
| 43 |
323-34 |
SCREW-HH Price: $0.54 |
| 43 |
531170001 |
SERVICE KIT PULLEY PULLEY.MAND This part replaces 532199789. Price: $17.99 |
| 44 |
63-6030 |
CLUTCH HUB (MACHINED)*O Price: $356.75 |
| 45 |
532137152 |
HOUSING.MANDREL.44/46" VENT Price: $34.99 |
| 46 |
43-2750 |
NUT MM 409671 Price: $18.31 |
| 47 |
32151-83 |
RING-SNAP Price: $0.34 |
| 47 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 48 |
33114-020 |
SCREW-HH This part replaces 66-3160. Price: $0.28 |
| 49 |
33094-00 |
WASHER-PLAIN This part replaces 48-8030. Price: $0.25 |
| 50 |
322-6 |
SCREW-HH Price: $0.45 |
| 51 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 52 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 53 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 54 |
32128-28 |
NUT-HHF Price: $0.34 |
| 55 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 71 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 72 |
581454103 |
CHUTE.SLOTTED.HOLES.TEX.CRD.II This part replaces 581454102. Price: $79.99 |
| 75 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 84 |
532400140 |
BELT KEEPER.MANDREL.38"COATED Price: $39.99 |
| 85 |
532427985 |
BLADE.3N1.RH.CRD.97 Price: $49.99 |
| 86 |
583117001 |
BOLT.3/8-24X1.25GR8. LHTHRD This part replaces 532181713. Price: $3.99 |
| 87 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 88 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 91 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 94 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 95 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 96 |
583261101 |
SPACER.NORAM.CRD This part replaces 532400271. Price: $4.99 |
| 97 |
583119101 |
SHIELD.IDLER.MOWER.CRD. This part replaces 532182061. Price: $4.99 |
| 98 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 99 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 100 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 101 |
596040601 |
Hardware This part replaces 873680900. Price: $3.99 |
| 102 |
532402511 |
SPACER BEARING Price: $3.99 |
| 103 |
583514601 |
GUARD.FRONT.VENT.97.CRD This part replaces 532436992. Price: $6.99 |
| 105 |
583534001 |
LH.MANDREL.COVER.97.TEX.CRD This part replaces 532438744. Price: $24.99 |
| 110 |
587934801 |
CRD.SPUR.GEAR Price: $11.99 |
| 111 |
583514001 |
GASKET.GEARCASE.97.CRD (2 2) This part replaces 532436979. Price: $4.99 |
| 112 |
583571601 |
SHAFT.CRD.GEARCASE.ADAPTER This part replaces 532443852. Price: $14.99 |
| 114 |
588170501 |
VENT.BREATHER.1/8 NPT Price: $8.99 |
| 115 |
583608901 |
SCREW.TORX#10-24X1 This part replaces 818031016. Price: $2.99 |
| 116 |
594976601 |
Bolts This part replaces 872110414. Price: $1.99 |
| 117 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 118 |
583514401 |
ARM.CLUTCHING.97.TEX This part replaces 532436989. Price: $17.99 |
| 119 |
583527601 |
GEAR.CASE.SUBASM. This part replaces 532438166. Price: $59.99 |
| 120 |
583514501 |
KEEPER.BELT.RH.MANDREL.97.CRD This part replaces 532436991. Price: $6.99 |
| 121 |
583514101 |
WASHER.687.I.D.X.1 OD.X.062THK This part replaces 532436985. Price: $2.99 |
| 124 |
583514201 |
MANDREL SHAFT NON/GREASEABLE This part replaces 532436986. Price: $37.99 |
| 125 |
583548001 |
IDLER.BRACKET.ASM. This part replaces 532440420. Price: $29.99 |
| 127 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 128 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 129 |
583568101 |
ROD.SWAY.97&107.CRDI&II This part replaces 532443237. Price: $17.99 |
| 130 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 131 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 133 |
583505301 |
DOOR.MULCH This part replaces 532435538. Price: $11.99 |
| 134 |
583507401 |
PIN.HINGE This part replaces 532435861. Price: $5.99 |
| 135 |
532437988 |
E-RING.5/16" Price: $7.99 |
| 146 |
583582001 |
SPRING.EZ.MULCH.DOOR This part replaces 532445896. Price: $2.99 |
| 252 |
585308705 |
PLATE.REINFORCEMENT.X431 Price: $9.99 |
| 253 |
585308805 |
PLATE.REINFORCEMENT.LHS.X431 Price: $5.99 |
| 254 |
585309005 |
PLATE.REINFORCEMENT.LHS.X431 Price: $11.99 |
| 255 |
592807801 |
BOLT CUP HEAD SQUARE NECK 1/4- This part replaces 539109800. Price: $2.99 |
