| Ref | Part Number | Description |
|---|
| 1 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 1 |
31994 |
SHAFT & LEV Price: Call Us |
| 2 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 2 |
650506 |
SCREW This part replaces 630606. Price: $0.87 |
| 3 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 3 |
31995 |
SHUTTER Price: Call Us |
| 4 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 4 |
631499 |
SHAFT & LEV This part replaces 31996. Price: Call Us |
| 5 |
27113 |
SPRING Price: $2.62 |
| 5 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 5 |
532411764 |
DASH.P/L.TEX.CBL.CL.N/CHK.BLAC Price: $44.99 |
| 6 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 6 |
650399 |
SCREW This part replaces 630605. Price: $1.20 |
| 7 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 8 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 9 |
31503 |
SPRING Price: $1.23 |
| 10 |
30927 |
SHUTTER Price: Call Us |
| 11 |
27109 |
GASKET Price: $1.18 |
| 12 |
27108 |
GASKET Price: Call Us |
| 13 |
32256A |
REPAIR KIT This part replaces 32411A. Price: $45.70 |
| 14 |
27105 |
FLOAT Price: $20.00 |
| 14 |
532185847 |
HOOD.STEEL.ELITE.YELLOW Price: $84.99 |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 16 |
27136A |
DRAIN ASSY Price: $5.96 |
| 17 |
29170 |
FLOAT BOWL Price: Call Us |
| 18 |
532426792 |
GRILLE.ELITE.BASIC.LT.BLACK Price: $44.99 |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
28945 |
POWER SCREW Price: $18.86 |
| 22 |
630786 |
SPRING Price: $1.25 |
| 23 |
30355 |
NOZZLE Price: Call Us |
| 24 |
27544 |
O RING Price: $1.26 |
| 25 |
27554 |
GASKET Price: $1.05 |
| 27 |
32096 |
RET SPRING Price: $2.62 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS Price: $34.99 |
| 36 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 37 |
532414872 |
FENDER.TLT.FS.W/CPH.YELLOW This part replaces 532436523. Price: $149.99 |
| 52 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 58 |
532412280 |
DRAWBAR UPPER 2PC SMALL FENDER Price: $32.99 |
| 68 |
817490508 |
SCREW LT Price: $3.99 |
| 130 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 137 |
532184921 |
BUMPER.HOOD.LARGE.1.75" Price: $3.99 |
| 138 |
532409730 |
CUPHOLDER.TL.TEX.BLACK Price: $3.99 |
| 150 |
532184461 |
DUCT.INTAKE.AIR.KAW Price: $17.99 |
| 151 |
532407807 |
BRACKET PIVOT Price: $14.99 |
| 152 |
532199535 |
SHIELD.BROWNING.W/TEX Price: $11.99 |
| 153 |
532189837 |
LENS.GRILLE.BASIC.BAR.LT.CLR Price: $11.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 162 |
532142432 |
SCREW.HI-LO.CONSOLE Price: $3.99 |
| 175 |
532193243 |
CROSSMEMBER.LT Price: $17.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $6.99 |
| 177 |
532195228 |
BUSHING STEERING Price: $2.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $109.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. This part replaces 532404796. Price: $2.99 |
| 182 |
532193057 |
DASH.LOWER.LT.CCS Price: $64.99 |
| 183 |
874520520 |
BOLT.5/16-18X1-1/4 FULL THD Price: $2.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 194 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 196 |
532414579 |
CONSOLE.ASM.DECKLFT.BL/RBT.TLT Price: $22.99 |
| 213 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $8.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $2.99 |
| 228 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 235 |
532406129 |
SPACER FENDER Price: $2.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
