| Ref | Part Number | Description |
|---|
| 1 |
93-6680 |
DECAL-DIESEL Price: $19.31 |
| 2 |
532179758 |
MUFFLER Price: $70.99 |
| 2 |
92-5759 |
PLATE-SEAT Price: $194.60 |
| 3 |
283-49 |
PIN-CLEVIS Price: $1.02 |
| 4 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 5 |
66-2800-03 |
ROD-SUPPORT ASM Price: $65.99 |
| 6 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 7 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 8 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 9 |
2412-133 |
CLAMP-R Price: $3.19 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 Price: $7.99 |
| 10 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 11 |
105-0036 |
FUSE BLOCK BRACKET ASM Price: $85.26 |
| 11 |
532180505 |
CLUTCH Price: $181.99 |
| 12 |
532194338 |
PULLEY.ASM.ENG.OGURA.3 Price: $41.99 |
| 12 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 13 |
32105-12 |
SCREW Price: $2.19 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
322-13 |
SCREW-HH Price: $2.73 |
| 15 |
581289901 |
FUEL.TANK.ASM.1.5.GAL.NON-EPA This part replaces 532407545. Price: $54.99 |
| 16 |
322-4 |
SCREW-HH Price: $0.35 |
| 17 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 18 |
32128-33 |
NUT-HF Price: $0.25 |
| 18 |
581075501 |
CAP.FUEL.TANK.SS/SNO.EPA.DOME This part replaces 532430220. Price: $14.99 |
| 19 |
70-1480 |
RELAY Price: $105.19 |
| 20 |
321-4 |
SCREW-HH Price: $0.99 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $22.99 |
| 21 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS THREAD Price: $2.99 |
| 22 |
66-2630 |
LATCH-SEAT Price: $18.77 |
| 23 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 24 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 25 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 26 |
28-8070 |
LANYARD Price: $13.85 |
| 27 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 28 |
532137040 |
LINE.FUEL.20 Price: $3.99 |
| 28 |
93-7841 |
DECAL-WARNING Price: $7.52 |
| 29 |
321-5 |
SCREW-HH Price: $0.22 |
| 29 |
532137180 |
ARRESTER SPARK (OPTIONAL) Price: $128.99 |
| 30 |
100-6576 |
GRIP-HANDLE Price: $2.98 |
| 32 |
92-8877 |
SEAT FRAME ASM Price: $257.82 |
| 35 |
66-8800 |
RELAY Price: $87.56 |
| 36 |
37-2690 |
CAPACITOR Price: $155.98 |
| 37 |
2412-74 |
R-CLAMP Price: $2.37 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
105-2509 |
DECAL-INSTRUCTIONS, STARTING Price: $36.49 |
| 38 |
105-2511 |
DECAL-INSTRUCTIONS, STARTING Price: $49.24 |
| 39 |
100-6551 |
LATCH-SPRING Price: $32.16 |
| 40 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 41 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
100-6577 |
DECAL-LOCK, LIFT Price: $8.60 |
| 42 |
539990247 |
LOCKWASHER.7/16 This part replaces 810040700. Price: $1.99 |
| 43 |
2412-106 |
CLAMP-R Price: $2.04 |
| 45 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 69 |
532272293 |
Gasket Eng 1 313 Id Tin Plated This part replaces 532165291. Price: $7.99 |
| 79 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532150280 |
SUB= 150280 This part replaces 532173937. Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
