| Ref | Part Number | Description |
|---|
| 1 |
186093X428 |
Wheel, Steering Price: Call Us |
| 1 |
703-1812A-0716 |
SEAT PIVOT BRACKET Not Available Price: |
| 2 |
195968 |
Axle Asm., Front Price: Call Us |
| 2 |
703-3208 |
Track, Seat - w/o Latch Price: $64.46 |
| 3 |
703-3431 |
SEAT WATCH TRACK Not Available Price: |
| 4 |
194743 |
Spindle Asm., LH Price: Call Us |
| 4 |
703-4149-0716 |
SEAT PIVOT LOWER BRACKET Not Available Price: |
| 5 |
194744 |
Spindle Asm., RH Price: Call Us |
| 5 |
703-4151-0637 |
SEAT BELT MOUNTING BRACKET Not Available Price: |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 6 |
710-1669 |
Screw, Pan Hd. Mach. 5/16-18 x 1.0 Price: $4.56 |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
710-3005 |
Screw, Hex Cap, 3/8-16 x 1.25 GR5 Price: $3.61 |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 8 |
710-0376 |
Screw, Hex Cap, 5/16-18 x 1.0 GR5 Price: $3.66 |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 9 |
712-04063 |
Nut, Hex Insert Flange Lock 5/16-18 GR5 Price: $3.56 |
| 10 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 11 |
732-0735A |
Compression Spring This part replaces 732-0735. Price: $27.35 |
| 12 |
735-04039 |
SEAT SPRING CAP Not Available Price: |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 13 |
736-0343 |
Washer, Flat, .33 x 1.25 x 12 Price: $3.90 |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
738-0140 |
Screw, Shoulder, .435 x .178:5/16-18 Price: $4.93 |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 15 |
750-0258 |
Spacer, .315 x .75 x .375 Price: $10.00 |
| 16 |
194746 |
Shaft Steering Price: Call Us |
| 16 |
750-04247 |
SEAT SPACER Not Available Price: |
| 17 |
957-04023 |
HIGH BACK SEAT Not Available This part replaces 757-04005. Price: |
| 18 |
757-3013 |
BELT SET-SEAT BOTH Not Available Price: |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 20 |
199743X428 |
Boot, Steering Price: Call Us |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 22 |
194845 |
Bushing, Strg. Blk Price: Call Us |
| 26 |
186095X428 |
Insert, Wheel Steering Price: Call Us |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 45 |
19113812 |
Washer 11/32 x 2-3/8 x 12 Ga. Price: Call Us |
| 50 |
73900600 |
Nut Lock 3/8-16 UNC Price: Call Us |
| 51 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x .060 Price: Call Us |
| 54 |
74760636 |
Bolt Hex 3/8-16 UNC x 2-1/4 Price: Call Us |
| 55 |
197636 |
Spacer Brace Axle Price: Call Us |
| 57 |
197246 |
Bracket Upstop Price: Call Us |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 63 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 66 |
71020748 |
Bolt Hex Fghd 7/16-14 x 3 Serr Price: Call Us |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
| 777D09646 |
LABEL-SEAT |
BACK Not Available Price: 777D09646 |
