EDGER ASSEMBLY
Parts (72)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 125-9619-03 | HINGE-DOOR, LH Price: $34.45 |
| 1 | 534332500 | Power Switch Price: $3.33 |
| 2 | 130-5675 | LH GLASS ASM Price: $880.70 |
| 2 | 534234245 | Handle Set Price: Call Us |
| 3 | 121-8605-03 | FRAME-DOOR, LH Price: $400.97 |
| 3 | 534234500 | Power Cord Price: $3.33 |
| 4 | 534193004 | Trigger Switch Price: $3.33 |
| 5 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 5 | 534402800 | P.C. Bridge Kit Price: $19.99 |
| 6 | 534184700 | Screw Price: $1.99 |
| 7 | 125-9676 | WASHER-BACKUP Price: $1.70 |
| 7 | 534222400 | Screw Price: $1.99 |
| 8 | 534336403 | Harness Price: $5.99 |
| 9 | 125-9520 | SCREW-SHOULDER, HSH Price: $1.83 |
| 9 | 534222503 | Upper Handle Tube Price: $3.33 |
| 10 | 534713000 | Lockwasher Price: $0.99 |
| 11 | 534970001 | Screw Price: $3.33 |
| 11 | 98-3104 | STUD-BALL Price: $4.61 |
| 12 | 121-8391 | LATCH-LH Price: $57.87 |
| 12 | 534223200 | Lower Handle Tube Price: $3.33 |
| 13 | 121-8630 | HANDLE ASM Price: $121.56 |
| 13 | 534134500 | Resistor Price: $2.99 |
| 14 | 33103-025 | SCREW-HHF Price: $0.54 |
| 14 | 534323302 | Motor Cover Price: $8.99 |
| 15 | 121-8395 | PLATE-SUPPORT, LATCH Price: $5.43 |
| 15 | 534174501 | Screw Price: $0.99 |
| 16 | 3234-21 | SCREW-HHF Price: $2.19 |
| 16 | 534240003 | Wheel Price: $3.99 |
| 17 | 104-7201 | NUT-HF Price: $0.69 |
| 17 | 534781011 | Axle Price: $1.99 |
| 18 | 125-9982 | BUSHING-FLANGE Price: $1.76 |
| 18 | 534121000 | Push Nut Price: $1.99 |
| 19 | 534225022 | Motor Price: $3.33 |
| 20 | 534136100 | Washer Price: $1.99 |
| 21 | 534740002 | Axle Price: $3.33 |
| 22 | 534730001 | Wheel Price: $3.99 |
| 23 | 530403094 | Nut This part replaces 534235901. Price: $1.99 |
| 24 | 534346702 | Guard Housing Price: $3.33 |
| 25 | 534136401 | Screw Price: $1.99 |
| 26 | 534323500 | Edge Guide Price: $2.99 |
| 27 | 534222403 | Screw Price: $1.99 |
| 28 | 534222401 | Screw Price: $3.33 |
| 29 | 534193800 | Screw Price: $3.33 |
| 30 | 534323405 | Side Guard Price: $4.99 |
| 31 | 534228700 | Screw Price: $1.99 |
| 32 | 534207101 | Endbell Ass'y. (Drive) Price: $3.33 |
| 33 | 534228800 | Washer Price: $1.99 |
| 34 | 534227001 | Field Ass'y. Price: $24.99 |
| 35 | 534747002 | Retaining Ring Price: $1.99 |
| 36 | 534225120 | Armature Ass'y. Price: $37.99 |
| 37 | 534246700 | Retaining Ring Price: $0.99 |
| 38 | 534228802 | Washer Price: $0.99 |
| 39 | 534238903 | Washer Price: $1.99 |
| 40 | 534227501 | Endbell Ass'y. (Brush) Price: $3.33 |
| 41 | 534226000 | Insulator Price: $3.33 |
| 42 | 534227800 | Brush Price: $3.16 |
| 43 | 534228000 | Brush Spring Price: $1.99 |
| 44 | 534227700 | Brush Holder Price: $3.33 |
| 45 | 534135900 | Bolt Price: $1.99 |
| 46 | 534520022 | Washer Price: $1.99 |
| 47 | 534135605 | Sleeve Price: $3.33 |
| 48 | 534135400 | Clutch Plate Price: $3.33 |
| 49 | 534136300 | Washer Price: $1.99 |
| 50 | 534238900 | Spring Washer Price: $1.99 |
| 51 | 534135500 | Clutch Sleeve Price: $5.99 |
| 52 | 534135305 | Fan Price: $3.33 |
| 53 | 952710529 | Blade Price: Call Us |
| 54 | 534135700 | Lockstrap Price: $1.99 |
| 55 | 534136600 | Lockwasher Price: $1.99 |
| 56 | 534136200 | Nut Price: $1.99 |
| 57 | 534224000 | Connector Tab Price: $0.99 |
| 58 | 534450400 | Brush Kit (Incl. 42,43,44) Price: $12.32 |
