| Ref | Part Number | Description |
|---|
| 1 |
137-6107 |
LONG REAR ROLLER ASM (2.5IN DIA)(22IN) This part replaces 114-5404. Price: $362.85 |
| 1 |
573995003 |
SEAT BRACKET Price: $49.99 |
| 2 |
107-3279 |
BRACKET-SCRAPER, LH Price: $28.60 |
| 2 |
506915301 |
SEAT SPRING Price: $17.99 |
| 3 |
107-3281 |
BRACKET-SCRAPER, RH Price: $28.60 |
| 3 |
734117441 |
WASHER Price: $3.99 |
| 4 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 4 |
725249371 |
Screw M10x25 Price: $1.82 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
587605301 |
SEAT ASSY KIT LOW HVA This part replaces 544433301. Price: $179.99 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 6 |
585065201 |
KNOB This part replaces 506565501. Price: $17.99 |
| 7 |
137-6109 |
FULL FRONT ROLLER ASM (2.5IN DIA)(22IN) This part replaces 114-5419. Price: $436.53 |
| 7 |
506565301 |
WASHER Price: $4.99 |
| 8 |
108-4475-03 |
SCRAPER-ROLLER, FULL FRONT Price: $49.43 |
| 8 |
734116441 |
SPACER Price: $3.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
506556301 |
BOLT Price: $3.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 15 |
112-7451 |
SCREW-TAP Price: $2.17 |
| 16 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 17 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 18 |
107-2999 |
SCRAPER ROD ASM Price: $47.25 |
