| Ref | Part Number | Description |
|---|
| 1 |
125-6995 |
PIN Price: $5.45 |
| 1 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 2 |
127-3025 |
HOUSING-FLYWHEEL Price: Call Us |
| 2 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 3 |
125-6910 |
CAP Price: $13.61 |
| 4 |
125-7226 |
BOLT Price: $4.09 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
125-7227 |
BOLT Price: $4.99 |
| 5 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 6 |
138-7826 |
OIL PAN ASM This part replaces 125-7241. Price: $968.12 |
| 6 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 7 |
125-6912 |
PLUG-DRAIN Price: $24.49 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
125-7177 |
WASHER-SEAL Price: $6.86 |
| 10 |
125-7035 |
SPACER Price: $102.62 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
125-7214 |
BOLT Price: $3.77 |
| 12 |
125-7215 |
BOLT Price: $3.48 |
| 13 |
125-7219 |
BOLT Price: $4.58 |
| 14 |
125-7220 |
BOLT Price: $4.99 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
125-6995 |
PIN Price: $5.45 |
| 16 |
125-6996 |
CASE ASM Price: $256.91 |
| 18 |
125-7106 |
SEAL-OIL Price: $23.98 |
| 19 |
125-7045 |
BOLT Price: $5.88 |
| 20 |
125-7217 |
BOLT Price: $4.58 |
| 21 |
127-3062 |
SENSOR-REV, FLYWHEEL Price: $149.87 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 25 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532185534. Price: $44.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 101 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
