| Ref | Part Number | Description |
|---|
| 2 |
48100-02 |
BRONZE BUSHING Price: Call Us |
| 3 |
04050-05 |
RETAINING RING, 1-1/8 EXTERNAL Price: Call Us |
| 4 |
48114-04 |
Fitting, Grease This part replaces 48114-01. Price: Call Us |
| 8 |
45008 |
REAR WHEEL PIVOT Price: Call Us |
| 12 |
45035 |
REAR WHEEL YOKE Price: Call Us |
| 13 |
48005 |
Rear Wheel Assy. This part replaces 48005-01. Price: Call Us |
| 14 |
481894 |
Rim Assy, This part replaces 48005-03. Price: Call Us |
| 15 |
481895 |
Cup, Bearing This part replaces 48005-04. Price: Call Us |
| 16 |
481896 |
Cone, Bearing This part replaces 48005-05. Price: Call Us |
| 17 |
481897 |
Seal, Wheel Bearing This part replaces 48005-06. Price: Call Us |
| 18 |
43020-01 |
SPACER, REAR WHEEL SHORT Price: Call Us |
| 19 |
43020-02 |
SPACER, REAR WHEEL LONG Price: Call Us |
| 20 |
43021 |
SLEEVE, REAR WHEEL Price: Call Us |
| 24 |
45009 |
STEERING SHAFT Price: Call Us |
| 25 |
48100-01 |
Bronze Bearing This part replaces 48100-07. Price: Call Us |
| 26 |
04050-03 |
RETAINING RING, 7/8" EXTERNAL Price: Call Us |
| 27 |
45175 |
PEDAL, FOOT SAFETY SWITCH Price: Call Us |
| 28 |
48369 |
PAD, LH Price: Call Us |
| 29 |
48370 |
PAD, SAFETY PEDAL Price: Call Us |
| 30 |
481056 |
Spring, Foot Safety Switch This part replaces 48049. Price: Call Us |
| 31 |
481476 |
Switch, Foot Safety This part replaces 48026. Price: Call Us |
| 34 |
04021-08 |
HEX NUT, ELASTIC STOP LOCK 1/4-20 Price: Call Us |
| 35 |
48100-06 |
BRONZE BUSHING Price: Call Us |
| 36 |
48100-03 |
BRONZE BUSHING Price: Call Us |
| 37 |
45151 |
FOOT PEDAL Price: Call Us |
| 38 |
48338 |
PAD, FOOT PEDAL REVERSE Price: Call Us |
| 39 |
48337 |
PAD, FOOT PEDAL FORWARD Price: Call Us |
| 40 |
48100-06 |
BRONZE BUSHING Price: Call Us |
| 41 |
04065-01 |
PIN, DRIVE LOCK, 3/16 X 1-1/4 Price: Call Us |
| 42 |
45209 |
FOOT PEDAL ARM Price: Call Us |
| 43 |
48118 |
BALL JOINT Price: Call Us |
| 47 |
44022 |
CONTROL ROD Price: Call Us |
| 48 |
48208 |
PULLEY, WINCH CABLE Price: Call Us |
| 50 |
48100-04 |
BRONZE BUSHING Price: Call Us |
| 52 |
04021-07 |
HEX NUT, ELASTIC STOP LOCK 1/2-13 Price: Call Us |
| 53 |
48097 |
BUMPER STOP COVER Price: Call Us |
| 54 |
48336 |
PAD, RH Price: Call Us |
| 55 |
44028 |
RETAINER, WINCH CABLE Price: Call Us |
| 57 |
48159 |
GRIP Price: Call Us |
| 61 |
42366 |
REINFORCEMENT, SEAT SPRING Price: Call Us |
| 62 |
42026 |
SEAT SPRING Price: Call Us |
| 66 |
45210 |
SEAT PLATE Price: Call Us |
| 69 |
04041-11 |
FLAT WASHER, 13/32 X 1-1/2 X 7 GA. Price: Call Us |
| 78 |
42527 |
SPRING, NEUTRAL Price: Call Us |
| 79 |
48409 |
BEARING, NEUTRAL DETENT Price: Call Us |
| 80 |
42528 |
SHIM, SPRING Price: Call Us |
| 81 |
42529 |
KEEPER, SPRING Price: Call Us |
