Front Axle (Part 1)
Parts (77)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 111-9940 | STEERING CYLINDER ASM This part replaces 92-4724. Price: $274.42 |
| 1 | MA-19562116AG0 | CASE (LH) CENTER MFD Not Available Price: |
| 2 | 237-78 | O-RING Price: $3.85 |
| 2 | MA-10252178AG1 | PIPE-BREATHER MFD Not Available This part replaces MA-10252178001. Price: |
| 3 | 237-80 | O-RING Price: $6.10 |
| 3 | MA-11190621000 | PLUG Not Available Price: |
| 4 | 340-54 | ELBOW-45 DEG Price: $40.72 |
| 4 | MA-F5000-16000 | PLUG Not Available Price: |
| 5 | 340-14 | FITTING-HYD, 45 DEG Price: $42.29 |
| 5 | MA-08331001601 | SEAL WASHER Not Available This part replaces MA-08331001600. Price: |
| 6 | 237-65 | O-RING Price: $2.50 |
| 6 | MA-10352119AG0 | CASE (RH) CENTER MFD Not Available Price: |
| 7 | 94-8271 | TRACTION HOSE ASM Price: $127.83 |
| 7 | MA-11911211000 | CAP Not Available Price: |
| 8 | 106-6895-03 | BALL JOINT ASM This part replaces 69-9810. Price: $258.08 |
| 8 | MA-10401337000 | BOLT BEARING HOLDER Not Available Price: |
| 9 | 302-5 | FITTING-GREASE Price: $0.59 |
| 9 | MA-08300501500 | O-RING Not Available Price: |
| 10 | 237-22 | O-RING Price: $2.43 |
| 10 | MA-A9400110030 | BOLT MFD Not Available Price: |
| 11 | 340-97 | FITTING-ELBOW, 90 DEG Price: $36.21 |
| 11 | MA-A3600101003 | LOCK WASHER MFD Not Available Price: |
| 12 | 115-8015 | CYLINDER-HYDRAULIC This part replaces 92-6057. Price: $905.66 |
| 12 | MA-27403214200 | PLUG Not Available Price: |
| 13 | 32136-13 | NUT-SHH Price: $2.85 |
| 13 | MA-08331000800 | SEAL WASHER Not Available Price: |
| 14 | 3272-13 | PIN-COTTER Price: $0.25 |
| 14 | MA-10232115AG2 | CASE-BEARING MFD Not Available Price: |
| 15 | 48-6640 | BEARING Price: $10.04 |
| 15 | MA-08300500600 | O-RING Not Available Price: |
| 16 | 48-6660 | WASHER Price: $5.22 |
| 16 | MA-F1540110030 | BOLT W/WASHER Not Available Price: |
| 17 | 3296-49 | NUT-LOCK, NI Price: $4.93 |
| 17 | MA-10232136001 | SHIM Not Available Price: |
| 18 | 3234-12 | SCREW-HHF Price: $0.61 |
| 18 | MA-10232137001 | SHIM Not Available Price: |
| 19 | 69-8890 | CAP-SPINDLE Price: $13.32 |
| 19 | MA-10232138001 | SHIM Not Available Price: |
| 20 | 32151-10 | RING-RETAINING Price: $0.81 |
| 20 | MA-10212171000 | BUSHU Not Available Price: |
| 21 | 256-304 | WASHER-THRUST Price: $3.94 |
| 21 | MA-08300200250 | O-RING Not Available Price: |
| 22 | 69-6470 | BUSHING-CASTOR Price: $5.82 |
| 22 | MA-08401035529 | SEAL, OIL Not Available Price: |
| 23 | 92-4755-03 | REAR AXLE ASM This part replaces 92-4755. Price: $1,618.24 |
| 23 | MA-10302123000 | NUT M25 Not Available Price: |
| 24 | 86-6560 | WASHER-THRUST Price: $29.68 |
| 24 | MA-10302126AG1 | HOLDER-ARM MFD Not Available Price: |
| 25 | 92-4779-03 | LH MOTOR HOUSING ASM This part replaces 92-4779. Price: $969.47 |
| 25 | MA-08300200250 | O-RING Not Available Price: |
| 26 | 92-4749-03 | HUB-WHEEL This part replaces 92-4749. Price: $96.67 |
| 26 | MA-F1540110030 | BOLT W/WASHER Not Available Price: |
| 27 | 69-9880 | TIRE (23X10.5-12) 6-PLY Price: $189.93 |
| 27 | MA-10212141000 | THRUST BEARING Not Available Price: |
| 28 | 217-116 | WHEEL Price: $258.19 |
| 29 | 83-2720 | BOLT-LUG Price: $3.69 |
| 30 | 99-3139 | NUT This part replaces 11-5800. Price: $16.11 |
| 31 | 3272-13 | PIN-COTTER Price: $0.25 |
| 32 | 5108 | VALVE This part replaces 232-27. Price: $6.29 |
| 33 | 3296-23 | NUT-LOCK, NI Price: $0.52 |
| 34 | 110-6141-03 | RH TIE ROD END ASM This part replaces 2116-4. Price: $148.18 |
| 35 | 302-33 | FITTING-GREASE Price: $2.31 |
| 36 | 2412-7 | CLAMP ASM Price: $23.32 |
| 37 | 324-9 | SCREW-HH Price: $1.76 |
| 38 | 110-9719-03 | TIE ROD ASM This part replaces 82-9260. Price: $380.21 |
| 39 | 32146-7 | NUT-LOCK, INSERT Price: Call Us |
| 40 | 32136-2 | NUT-SHH Price: $3.55 |
| 41 | 11-5790 | KEY-SQUARE Price: $17.50 |
| 42 | 3274-5 | SCREW-HSH Price: $4.00 |
| 43 | 58-6520 | DECAL-GREASE Price: $2.57 |
| 44 | 302-11 | FITTING-LUBE, 45 DEG Price: $1.56 |
| 45 | 82-9210 | SHAFT-PIVOT Price: $187.73 |
| 46 | 60-3670 | PIN Price: $12.56 |
| 47 | 92-5664 | HOSE ASM Price: $276.42 |
| 48 | 94-8272 | TRACTION HOSE ASM Price: $114.06 |
| 49 | 3296-25 | NUT-LOCK, NI Price: $1.34 |
| 50 | 11-0440 | DISCONTINUED This part replaces 7-2111. Price: Call Us |
