| Ref | Part Number | Description |
|---|
| 1 |
00463000 |
BREATHER, DIPSTICK Price: $32.95 |
| 1 |
38-2470 |
DISCONTINUED Price: Call Us |
| 1 |
462069 |
Key, Assembly w/Fob Price: Call Us |
| 2 |
03857000 |
AXLE, SPLITTER Price: $68.45 |
| 2 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 2 |
484565 |
Hour Meter, Inductive Price: Call Us |
| 3 |
03857500 |
LOCK, BEAM Price: $13.45 |
| 3 |
32104-114 |
SCREW THD 1/4 20 5/8 Price: $5.17 |
| 3 |
485833 |
Switch, PTO - 10 Amp Price: Call Us |
| 4 |
04852351 |
PIN, .373 X 7.30 X 2X.109 THRU Price: $22.95 |
| 4 |
483976 |
Choke Control (excludes EFI models) Price: Call Us |
| 4 |
68-7320 |
DISCONTINUED This part replaces 27-4390. Price: Call Us |
| 5 |
04969759 |
WMT-FENDER-RH Price: $145.95 |
| 5 |
48017-04 |
Nut, 5/8-32 Special Price: Call Us |
| 5 |
67-1710 |
DECAL-WARNING This part replaces 28-3290. Price: $7.83 |
| 6 |
04011-14 |
Screw, Self-Tapping 1/4-20 x 3/4 Price: Call Us |
| 6 |
04969859 |
WMT-FENDER-LH Price: $145.95 |
| 7 |
05901806 |
BLT, HEX .31-18X2.25 G5 ZCC This part replaces 05963700. Price: $1.45 |
| 7 |
38-4020 |
SEAT MTG WA Price: $170.51 |
| 7 |
462985 |
Instrument Panel w/Decal - SVRII36 Price: Call Us |
| 8 |
06200232 |
BLT,RHSN .31-18X.75 G5 ZCC This part replaces 06215700. Price: $2.45 |
| 8 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 8 |
48017-03 |
LOCK WASHER, 5/8" INTERNAL TOOTH Price: Call Us |
| 9 |
06401012 |
WSHR,FLT .563X1.375X.109 ZCC This part replaces 06442000. Price: $2.45 |
| 9 |
48798 |
KEY SWITCH(INCLUDES MOUNTING HARDWARE) Price: Call Us |
| 9 |
68-7330 |
DECAL - CAUTION This part replaces 27-4620. Price: $16.56 |
| 10 |
04003-43 |
Bolt, Carriage #10-24 x 1/2" Price: Call Us |
| 10 |
06513100 |
NUT-SL 1.0-14 Price: $5.45 |
| 10 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 11 |
06500826 |
NUT,LK-CTR .31-18 GA ZCC This part replaces 06529800. Price: $1.45 |
| 11 |
321-4 |
SCREW-HH Price: $0.99 |
| 11 |
483975 |
Throttle Control, SVR Price: Call Us |
| 12 |
04021-26 |
Nut, Elastic Stop #10-24 Price: Call Us |
| 12 |
06500904 |
NUT-LK-TOP-FLG .312-18 GF ZCC This part replaces 06543100. Price: $0.95 |
| 12 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 13 |
06700215 |
PIN, HAIR-#7 .094X2.31 ZC120 This part replaces 06712900. Price: $5.95 |
| 13 |
44-9050 |
HOSE Price: $70.98 |
| 13 |
486768 |
Wire Harness, SVRII-32A/36A Price: Call Us |
| 14 |
3217-6 |
NUT-HEX Price: $1.19 |
| 14 |
427269 |
Bracket, Neutral Switch Price: Call Us |
| 15 |
06700223 |
PIN, HAIR #225 .072X1.09 This part replaces 06714800. Price: $0.45 |
| 15 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 15 |
481545 |
Switch, Interlock (see below) Price: Call Us |
| 16 |
04010-12 |
Screw, Hex-Slotted Washer Head #10 32 x 3/4" Price: Call Us |
| 16 |
06944800 |
CLIP, SPRING Price: $0.95 |
| 16 |
27-7180 |
CAP Price: $70.51 |
| 17 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 17 |
07101210 |
ASM,TIRE/WHEEL 4.8/4-8 P47GRAY Price: $109.95 |
| 17 |
44-8950-03 |
AIR CLEANER TUBE This part replaces 44-8950. Price: $53.15 |
| 18 |
08325900 |
SPRG, COMP .058X.65X2.13 WLD15 Price: $7.95 |
| 18 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 18 |
427481 |
Switch Bracket, OPC Switch -SVRII-36 Price: Call Us |
| 19 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 19 |
484497 |
Switch, Double Pole OPC - SVRII-36 Price: Call Us |
| 19 |
51700400 |
REAR STAND W/DECALS (ARIENS) Price: $85.95 |
| 20 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 20 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 20 |
51705300 |
CHASSIS W/SAFETY DECALS-27T-CE Price: Call Us |
| 21 |
3258-19 |
SCREW Price: $0.42 |
| 21 |
462166 |
Clutch w/Tag GT2.5-FE02 (48 / 52) Price: Call Us |
| 22 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 22 |
483958 |
Diode, 600V 6 Amp Price: Call Us |
| 23 |
322-3 |
SCREW-HH Price: $0.79 |
| 23 |
422373 |
Plate, Threaded Price: Call Us |
| 24 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 24 |
48029-24 |
Battery Cable, 39" Black (26EFI) - Kohler Price: Call Us |
| 25 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 25 |
48029-30 |
Battery Cable, 44" Red w/Braid (26EFI) - Kohler Price: Call Us |
| 26 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 27 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 27 |
48126 |
RUBBER BOOT Price: Call Us |
| 28 |
04001-01 |
BOLT, HEX HEAD, 1/4-20 X 3/4 GR.5 Price: Call Us |
| 28 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 29 |
04020-02 |
Nut, 1/4 - 20 Hex Price: Call Us |
| 29 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 30 |
323-5 |
SCREW-HH Price: $0.41 |
| 30 |
483642 |
Double Fuse Assy. Price: Call Us |
| 31 |
37-9770 |
DISCONTINUED Price: Call Us |
| 32 |
321-2 |
SCREW-HH Price: $2.79 |
| 32 |
482588 |
Clip, Fuse Holder Price: Call Us |
| 33 |
38-3170 |
DISCONTINUED Price: Call Us |
| 33 |
48298 |
FUSE, 20 AMP BLADE TYPE AUTOMOTIVE Price: Call Us |
| 34 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 34 |
483629 |
Fuse Holder Assembly Price: Call Us |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
485678 |
Wire Harness Adapter, Kawasaki FX & FT Price: Call Us |
| 36 |
3217-5 |
NUT-HEX Price: $0.25 |
| 37 |
29-6930 |
DISCONTINUED-SEE PB#936 Price: Call Us |
| 38 |
3-6685 |
SPRING Price: $10.99 |
| 39 |
27-9870 |
PIN-SWITCH, SEAT Price: $31.55 |
| 40 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 41 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 42 |
37-9590 |
DISCONTINUED Price: Call Us |
| 43 |
32121-50 |
PIN-SPRING Price: $1.21 |
