| Ref | Part Number | Description |
|---|
| 4 |
903-05143C |
LATCH HANDLE This part replaces 903-05143A. Price: $148.39 |
| 7 |
910-0224 |
HEX SCREW AB-TAP #10-16 X 0.500 Price: $3.19 |
| 8 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 9 |
710-0514 |
SCREW 3/8-16 X 1 GR5 Price: $3.78 |
| 10 |
710-0859 |
HEX SCREW-3/8-16X2.5 GR5 Price: $5.99 |
| 11 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 12 |
710-3279 |
SCREW 3/8-16X4.25 GR5 Price: $7.31 |
| 13 |
711-06216A |
LIFT PIN Price: $27.95 |
| 14 |
711-06284 |
LIFT LINK FERRULE Price: $9.75 |
| 15 |
711-0635 |
SPRING INSERT Price: $39.15 |
| 16 |
711-0642A |
LIFT HANDLE BUTTON Price: $6.90 |
| 17 |
712-0266A |
JAM LOCK NUT Price: $3.43 |
| 18 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 19 |
712-04217 |
FLANGE LOCK NUT Price: $3.75 |
| 20 |
712-05045A |
NUT 5/8-11 Price: $3.70 |
| 21 |
712-05046 |
HEX NUT NYLOK 1/2-13 Price: $3.74 |
| 22 |
712-3015 |
Nut, 5/8 Jam Type 5 This part replaces 912-3015. Price: $4.02 |
| 23 |
712-3048 |
Nut, Hex Jam, 1/2-13 GR5 This part replaces 912-3048. Price: $4.08 |
| 24 |
714-0211 |
COTTER PIN Price: $3.82 |
| 25 |
714-0470 |
Cotter Pin, 1/8 x 1.25 This part replaces 914-0470. Price: $3.90 |
| 27 |
731-09683 |
DECK LIFT BRACKET Price: $11.27 |
| 28 |
731-09707 |
DECK LIFT BRACKET (LH) Price: $11.27 |
| 29 |
731-3158 |
LIFT HANDLE GRIP Price: $15.37 |
| 30 |
732-05096 |
EXTENSION SPRING 1.485 OD X 17.58 Price: $30.09 |
| 31 |
732-3097 |
COMPRESSION SPRING Price: $12.51 |
| 32 |
736-0262 |
FLAT WASHER .385X.870X.090 Price: $3.66 |
| 33 |
736-05070 |
FLAT WASHER Price: $3.70 |
| 34 |
738-04278 |
SHOULDER SCREW 1/4-20X.50 19PSH" Price: $5.99 |
| 35 |
741-05075A |
FLANGE BEARING Price: $4.64 |
| 36 |
747-05725A |
DECK FRONT HANGER ROD Price: $49.33 |
| 37 |
747-06259A |
LIFT ADJUSTMENT LINK Price: $16.91 |
| 38 |
747-06355 |
LOCK ROD Price: $28.22 |
