| Ref | Part Number | Description |
|---|
| 1 |
703-05441A |
Bracket, Muffler Mounting Price: $48.35 |
| 2 |
710-0227 |
Screw, Hex Wash. Hd. Tapp #8-18 x .5 Price: $3.90 |
| 3 |
710-04248 |
Screw, Hex Cap, 7/16-20 x 4.0 GR5 Price: $10.13 |
| 4 |
710-04261 |
Screw, Hex Wash. Hd. Tapp #12-16 x .5 Price: $5.45 |
| 5 |
710-0599 |
Screw, Hex Wash. Hd. Tapp 1/4-20 x .5 Price: $3.86 |
| 6 |
710-0654A |
Screw, Hex Wash. Hd. Tapp Sems 3/8-16 x 1.0 Price: $3.75 |
| 7 |
710-0726 |
Screw, Hex Wash. Hd. Tapp 5/16-12 x .75 Price: $3.82 |
| 8 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 9 |
710-3217 |
Screw, Truss Hd. Mach. #8-32 x .375 Price: $5.94 |
| 10 |
712-0142 |
Nut, Hex, #8-32 Price: $3.90 |
| 11 |
712-0271 |
Nut, Hex Sems, 1/4-20 ‘ Price: $3.78 |
| 12 |
712-0429 |
Nut, Hex Insert Lock, 5/16-18 GR5 Price: $3.56 |
| 13 |
712-3005 |
Nut, Hex Jam, 3/8-16 GR2 Price: $5.99 |
| 15 |
726-0197 |
Tie, Clutch Wire Price: $3.22 |
| 16 |
726-0205 |
Clamp, Hose Price: $3.71 |
| 17 |
731-04914 |
Knob, Throttle Control Price: $11.56 |
| 18 |
736-0148 |
Washer, External Tooth Lock, 3/8 Price: $3.19 |
| 19 |
736-0171 |
Washer, Lock, 7/16 Price: $3.86 |
| 20 |
736-0300 |
Washer, Flat, .406 x .875 x .059 Price: $3.93 |
| 21 |
736-04131 |
Washer, Flat, .438 x 1.75 x .25 Price: $14.01 |
| 23 |
946-04214 |
Choke Cable This part replaces 746-04214. Price: $44.62 |
| 24 |
747-04228A |
FUEL TANK MOUNTING WIRE Not Available Price: |
| 25 |
751-0564B |
Deflector, Muffler Price: $12.14 |
| 26 |
951-0616B |
MUFFLER (DUAL INLET) This part replaces 751-0616A. Price: $143.87 |
| 27 |
751-10057D |
Fuel Tank This part replaces 751-10057C. Price: $271.40 |
| 28 |
751-10253 |
Pipe, Exhaust LH Price: $63.72 |
| 29 |
751-10254 |
Pipe, Exhaust RH Price: $82.97 |
| 30 |
751-10291D |
OIL DRAIN HOSE W/VIBRA SEAL This part replaces 751-10291. Price: $46.52 |
| 31 |
751-10349-13 |
Hose, Fuel Line Price: $15.58 |
| 32 |
951-3124E |
Fuel Cap This part replaces 751-3124B. Price: $31.79 |
