| Ref | Part Number | Description |
|---|
| 1 |
322-3 |
SCREW-HH Price: $0.79 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
532123583 |
SQUARE KEY Price: $2.99 |
| 3 |
3290-366 |
DISCONTINUED Price: Call Us |
| 4 |
3255-10 |
WASHER-LOCK / EXT Price: $0.25 |
| 5 |
21-2180 |
DISCONTINUED Price: Call Us |
| 6 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 7 |
321-4 |
SCREW-HH Price: $0.99 |
| 8 |
21-0340 |
DISCONTINUED Price: Call Us |
| 9 |
93-5398 |
SCREW-HH This part replaces 21-0330. Price: $3.22 |
| 10 |
32103-12 |
NUT-WING Price: $1.15 |
| 11 |
21-2220 |
DISCONTINUED Price: Call Us |
| 12 |
21-2240 |
DISCONTINUED Price: Call Us |
| 13 |
21-2360 |
DISCONTINUED Price: Call Us |
| 14 |
218-219 |
DISCONTINUED Price: Call Us |
| 15 |
21-2490 |
DISCONTINUED Price: Call Us |
| 16 |
322-2 |
SCREW-HH Price: $0.69 |
| 18 |
21-2450 |
DISCONTINUED Price: Call Us |
| 19 |
224-1 |
DISCONTINUED Price: Call Us |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 21 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 22 |
2412-98 |
CLAMP-HOSE This part replaces 2412-33. Price: $1.39 |
| 22 |
532421063 |
ROD.SHIFT.LT.TEX.VARIATOR Price: $29.99 |
| 23 |
109-0282 |
HOSE-FUEL This part replaces 21-2480. Price: $7.39 |
| 23 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $8.99 |
| 24 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 25 |
3217-7 |
NUT-HEX Price: $0.28 |
| 26 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 27 |
95-1823 |
WASHER This part replaces 3-3391. Price: $29.18 |
| 28 |
21-2300 |
ENGINE MOUNT Price: $195.59 |
| 29 |
21-0130 |
RUBBER MOUNT Price: $69.69 |
| 30 |
323-11 |
SCREW-HH Price: $1.08 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 32 |
21-0350 |
DISCONTINUED Price: Call Us |
| 33 |
21-2310 |
ENG MT BRKT *B Price: $63.43 |
| 33 |
812000001 |
E-RING LT Price: $2.99 |
| 34 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 35 |
3217-6 |
NUT-HEX Price: $1.19 |
| 35 |
532197722 |
ROD.BRAKE.PARKING.LT.T Price: $8.99 |
| 36 |
21-2350 |
DISCONTINUED Price: Call Us |
| 37 |
32128-19 |
NUT-HF Price: $0.99 |
| 37 |
532121749 |
WASHER Price: $1.99 |
| 38 |
2412-10 |
CLAMP-R Price: $2.78 |
| 39 |
322-4 |
SCREW-HH Price: $0.35 |
| 40 |
21-2290 |
DISCONTINUED Price: $2.00 |
| 41 |
323-8 |
SCREW-HH Price: $1.20 |
| 42 |
21-2260 |
DISCONTINUED Price: Call Us |
| 42 |
532008883 |
PEDAL COVER This part replaces 532124872. Price: $3.99 |
| 43 |
21-0370 |
DISCONTINUED Price: Call Us |
| 44 |
21-0360 |
NUT-HEX Price: $1.76 |
| 45 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 46 |
3290-134 |
SCREW Price: $0.27 |
| 47 |
21-2320 |
DISCONTINUED Price: Call Us |
| 48 |
21-0410 |
DISCONTINUED Price: Call Us |
| 49 |
21-0420 |
DISCONTINUED Price: Call Us |
| 49 |
872110614 |
BOLT Price: $3.99 |
| 50 |
21-0050 |
Engine Price: Call Us |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $9.99 |
| 51 |
38-7430 |
DISCONTINUED This part replaces 21-5790. Price: Call Us |
| 51 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 52 |
21-5800 |
DISCONTINUED Price: Call Us |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $9.99 |
| 53 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 54 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 55 |
3217-5 |
NUT-HEX Price: $0.25 |
| 56 |
21-8540 |
DISCONTINUED Price: Call Us |
| 56 |
532197253 |
BELT.DRIVE.MOWER.TEX.42" Price: $27.99 |
| 57 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 58 |
2412-41 |
CLAMP-R Price: $4.82 |
| 59 |
21-5630 |
DISCONTINUED Price: Call Us |
| 60 |
3219-14 |
NUT-HEX Price: $0.25 |
| 61 |
3253-12 |
WASHER-LOCK/SP Price: $0.25 |
| 62 |
21-5640 |
JOINT-BALL Price: $27.80 |
| 63 |
21-5620 |
DISCONTINUED Price: Call Us |
| 64 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 64 |
532196200 |
SHAFT.ASM.PEDAL.BRAKE. Price: $22.99 |
| 65 |
3211-2 |
SCREW-HH Price: $2.17 |
| 66 |
21-5690 |
DISCONTINUED Price: Call Us |
| 67 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 68 |
23-8670 |
DISCONTINUED This part replaces 21-5680. Price: Call Us |
| 70 |
532440323 |
CONSOLE.AUTO.VARIATOR.BLACK Price: $14.99 |
| 73 |
874490544 |
BOLT HEX 5/16-18 GR 5 Price: $2.99 |
| 74 |
532142432 |
SCREW.HI-LO.CONSOLE Price: $3.99 |
| 99 |
532427340 |
ROD.BYPASS.VARIATOR Price: $8.99 |
| 116 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 131 |
876020308 |
Pin, Cotter 3/32 x 1/2 (AYP part number) This part replaces 876020312. Price: $1.99 |
| 143 |
817490508 |
SCREW LT Price: $3.99 |
| 160 |
532169484 |
RETAINER CLIP Price: $4.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $7.99 |
| 165 |
532196212 |
BUSHING.SHAFT.BRAKE.HAND Price: $2.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $2.99 |
| 167 |
532405257 |
LATCH.BRAKE.SPRING Price: $2.99 |
| 172 |
583974201 |
STRAP.TORQUE.VARIATOR This part replaces 532415664. Price: $1.99 |
| 174 |
532197289 |
NUT.PUSH.500.2006 Price: $2.99 |
| 175 |
532415677 |
SHAFT.ASM.SHIFT.VARIATOR Price: $29.99 |
| 176 |
532196214 |
ARM.CLEVIS.ROD.SHIFT Price: $4.99 |
| 178 |
532197456 |
SPRING.SHIFT.GT2006 Price: $2.99 |
| 184 |
532441504 |
HANDLE.PARKING.BRAKE.LTTEX.667 Price: $5.99 |
| 185 |
872110622 |
BOLT Price: $0.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $3.99 |
| 187 |
532413524 |
WASHER.13/32 X 1 X 1/2.11GUARD This part replaces 819133210. Price: $2.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $1.99 |
| 189 |
532194317 |
BELLCRANK.GROUND.DRIVE.TEX. Price: $3.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $4.99 |
| 203 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 205 |
532121748 |
WASHER Price: $1.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $2.99 |
| 232 |
874780716 |
BOLT FIN HEX 7/16-14 X 1 Price: $2.99 |
| 233 |
532405296 |
WASHER SERRATED Price: $3.99 |
| 295 |
532420306 |
PIN.CLEVIS.183 Price: $2.99 |
| 296 |
532420471 |
SCREW.THDROL.5/16-18 Price: $2.99 |
| 297 |
532420223 |
NUT.PUSH.1/4 Price: $2.99 |
| 298 |
532415694 |
PIN.CLEVIS.CBL.BRK.VARIATOR.TX Price: $2.99 |
| 299 |
532415683 |
BRACKET.MOUNT.IDLERS Price: $6.99 |
| 300 |
532415680 |
PULLEY.IDLER.V-GROOVE Price: $17.99 |
| 301 |
532415680 |
PULLEY.IDLER.V-GROOVE Price: $17.99 |
| 302 |
581583601 |
KIT.IDLER.2.INCH This part replaces 532415666. Price: $17.99 |
| 303 |
872110618 |
BOLT CARRIAGE Price: $2.99 |
