| Ref | Part Number | Description |
|---|
| 1 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 1 |
795118 |
Cylinder Assembly Price: Call Us |
| 2 |
499585 |
Bushing/Seal Kit (Magneto Side) Price: Call Us |
| 2 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 3 |
63-6430-03 |
FRAME-REAR This part replaces 63-6430. Price: $757.78 |
| 4 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 4 |
796230 |
Sump-Engine Price: Call Us |
| 5 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 5 |
796231 |
Head-Cylinder (Cylinder #1) Price: Call Us |
| 5A |
796232 |
Head-Cylinder (Cylinder #2) Price: Call Us |
| 6 |
325-5 |
SCREW-HH Price: $1.20 |
| 7 |
63-6770-03 |
PIN-MASKED This part replaces 63-6770. Price: $145.71 |
| 8 |
321-4 |
SCREW-HH Price: $0.99 |
| 8 |
792185 |
Breather Assembly Price: Call Us |
| 9 |
67-1750 |
BUSHING Price: $0.92 |
| 10 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 10 |
697551 |
Screw (Breather Assembly) Price: Call Us |
| 11 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 11 |
792184 |
Tube-Breather Price: Call Us |
| 12 |
321-2 |
SCREW-HH Price: $2.79 |
| 13 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 13 |
793988 |
Screw (Cylinder Head) Price: Call Us |
| 14 |
66-2990 |
CAP-SPINDLE Price: $13.27 |
| 15 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 15 |
690946 |
Plug-Oil Drain Price: Call Us |
| 16 |
256-121 |
WASHER-THRUST Price: $4.55 |
| 16 |
796540 |
Crankshaft Price: Call Us |
| 17 |
76-4510 |
DISCONTINUED Price: Call Us |
| 18 |
231-105 |
TIRE-RIBBED Price: $62.56 |
| 19 |
217-118 |
WHEEL Price: $247.15 |
| 20 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 21 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 22 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 22 |
694966 |
Screw (Crankcase Cover/Sump) Price: Call Us |
| 23 |
32136-5 |
NUT-HEX, SLOTTED Price: $2.71 |
| 23 |
691054 |
Flywheel Price: Call Us |
| 24 |
222698S |
Key-Flywheel Price: Call Us |
| 24 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 25 |
793647 |
Piston Assembly (Standard) Price: Call Us |
| 25 |
793648 |
Piston Assembly (020" Oversize) Price: Call Us |
| 26 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 26 |
791787 |
Ring Set (Standard) Price: Call Us |
| 26 |
791792 |
Ring Set (.020" Oversize) Price: Call Us |
| 27 |
253-129 |
SEAL Price: $21.73 |
| 27 |
690975 |
Lock-Piston Pin Price: Call Us |
| 28 |
100-6598 |
PIVOT-STEERING This part replaces 76-4810. Price: $314.27 |
| 28 |
696581 |
Pin-Piston Price: Call Us |
| 29 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 29 |
699699 |
Rod-Connecting Price: Call Us |
| 30 |
99-5687 |
LH SOCKET ASM This part replaces 21-0150. Price: $126.28 |
| 31 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 32 |
63-6880 |
TIE ROD-STEERING Price: $50.74 |
| 32 |
690976 |
Screw (Connecting Rod) Price: Call Us |
| 33 |
3220-5 |
NUT-JAM Price: $0.65 |
| 33 |
697576 |
Valve-Exhaust Price: Call Us |
| 34 |
792200 |
Valve-Intake Price: Call Us |
| 34 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 35 |
694865 |
Spring-Valve (Intake) Price: Call Us |
| 35 |
76-4520 |
DISCONTINUED Price: Call Us |
| 36 |
67-7300 |
SCREW-HH Price: $81.39 |
| 36 |
694865 |
Spring-Valve (Exhaust) Price: Call Us |
| 37 |
76-3000-03 |
REAR AXLE ASM This part replaces 76-3000. Price: $1,003.02 |
| 38 |
32153-6 |
NUT-LOCK Price: $3.46 |
| 39 |
67-7250 |
SPACER-RING Price: $3.32 |
| 40 |
115-4525 |
CYLINDER ASM This part replaces 76-2070. Price: $1,342.36 |
| 40 |
690964 |
Retainer-Valve Price: Call Us |
| 41 |
328-25 |
SCREW-HH Price: $4.07 |
| 42 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 42 |
499586 |
Keeper-Valve Price: Call Us |
| 43 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 44 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 45 |
237-78 |
O-RING Price: $3.85 |
| 45 |
690977 |
Tappet-Valve Price: Call Us |
| 46 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 46 |
792555 |
Camshaft Price: Call Us |
| 47 |
237-21 |
O-RING Price: $0.70 |
| 48 |
5-1226 |
WASHER Price: $3.90 |
| 48 |
698172 |
Short Block Price: Call Us |
| 49 |
32128-45 |
NUT-HHF Price: $7.67 |
| 50 |
302-62 |
FITTING-GREASE Price: $1.34 |
| 50 |
695241 |
Manifold-Intake Price: Call Us |
| 51 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 52 |
67-9410 |
WASHER Price: $2.04 |
| 53 |
32151-77 |
RING-RETAINING, EXTERNAL Price: $4.07 |
| 53 |
690951 |
Stud (Carburetor) Price: Call Us |
| 54 |
699816 |
Screw (Intake Manifold) Price: Call Us |
| 54 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 55 |
76-2970 |
BUSHING-STRAIGHT Price: $9.02 |
| 73 |
494439 |
Screen-Rotating Price: Call Us |
| 74 |
698425 |
Screw (Rotating Screen) Price: Call Us |
| 75 |
691056 |
Washer (Flywheel) Price: Call Us |
| 95 |
690718 |
Screw (Throttle Valve) Price: Call Us |
| 98 |
699721 |
Kit-Idle Speed Price: Call Us |
| 108 |
699723 |
Valve-Choke Price: Call Us |
| 117 |
791501 |
Jet-Main (Standard) (Left) Price: Call Us |
| 117A |
791502 |
Jet-Main (Standard) (Right) Price: Call Us |
| 118 |
695415 |
Jet-Main (High Altitude) (Left) Price: Call Us |
| 118A |
843099 |
Jet-Main (High Altitude) (Right) Price: Call Us |
| 121 |
792455 |
Kit-Carburetor Overhaul Price: Call Us |
| 125 |
796259 |
Carburetor Price: Call Us |
| 130 |
690993 |
Valve-Throttle Price: Call Us |
| 131 |
499805 |
Kit-Throttle Shaft Price: Call Us |
| 133 |
699724 |
Float-Carburetor Price: Call Us |
| 135 |
699729 |
Tube-Fuel Transfer Price: Call Us |
| 141 |
796228 |
Kit-Choke Shaft Price: Call Us |
| 142 |
699726 |
Nozzle-Carburetor Price: Call Us |
| 146 |
690979 |
Key-Timing Price: Call Us |
| 150 |
690995 |
Gasket-Nozzle Price: Call Us |
| 160 |
699727 |
Retainer-Solenoid (Brass) Price: Call Us |
| 163 |
691001 |
Gasket-Air Cleaner Price: Call Us |
| 177 |
691031 |
Seal-O Ring (Dipstick) Price: Call Us |
| 186 |
796532 |
Hose-Connector (Oil Drain Hose) Price: Call Us |
| 187 |
791766 |
Line-Fuel (Cut to Required Length) Price: Call Us |
| 188 |
697551 |
Screw (Control Bracket) Price: Call Us |
| 192 |
690083 |
Adjuster-Rocker Arm Price: Call Us |
| 197 |
697820 |
Screw (Back Plate) Price: Call Us |
| 209 |
796224 |
Spring-Governor (Yellow/Black) Price: Call Us |
| 211 |
796225 |
Spring-Governed Idle (Orange) Price: Call Us |
| 212 |
695238 |
Link-Throttle Price: Call Us |
| 216 |
796229 |
Link-Choke Price: Call Us |
| 217 |
695409 |
Spring-Choke Return Price: Call Us |
| 219 |
793338 |
Gear-Governor Price: Call Us |
| 220 |
690412 |
Washer (Governor Gear) Price: Call Us |
| 221 |
841026 |
Cup-Governor Price: Call Us |
| 222 |
796226 |
Bracket-Control Price: Call Us |
| 227 |
796223 |
Lever-Governor Control Price: Call Us |
| 231 |
690718 |
Screw (Choke Valve) Price: Call Us |
| 240 |
691035 |
Filter-Fuel Price: Call Us |
| 250 |
690957 |
Retainer-Breather Price: Call Us |
| 252 |
690956 |
Collector-Oil Price: Call Us |
| 265 |
691024 |
Clamp-Casing Price: Call Us |
| 267 |
792629 |
Screw (Casing Clamp) Price: Call Us |
| 276 |
794271 |
Washer-Sealing (Aluminum) Price: Call Us |
| 278 |
792651 |
Washer (Governor Control Lever) Price: Call Us |
| 287 |
691108 |
Screw (Dipstick Tube) Price: Call Us |
| 304 |
796597 |
Housing-Blower Price: Call Us |
| 305 |
691005 |
Screw (Blower Housing) Price: Call Us |
| 305A |
698336 |
Screw (Blower Housing) Price: Call Us |
| 309 |
497595 |
Motor-Starter Price: Call Us |
| 310 |
690323 |
Screw (Starter Motor) Price: Call Us |
| 332 |
691059 |
Nut (Flywheel) Price: Call Us |
| 333 |
691060 |
Armature-Magneto Price: Call Us |
| 334 |
691061 |
Screw (Magneto Armature) Price: Call Us |
| 337 |
491055S |
Plug-Spark Price: Call Us |
| 358 |
694012 |
Gasket Set-Engine Price: Call Us |
| 385 |
697551 |
Screw (Fuel Pump) Price: Call Us |
| 387 |
808656 |
Pump-Fuel Price: Call Us |
| 404 |
690442 |
Washer (Governor Crank) Price: Call Us |
| 415 |
794903 |
Plug (Oil Pressure Switch Hole) Price: Call Us |
| 415A |
690283 |
Plug (Intake Manifold) Price: Call Us |
| 418 |
795912 |
Plate-Carburetor Price: Call Us |
| 431 |
790816 |
Elbow-Intake Price: Call Us |
| 445 |
499486S |
Filter-Air Cleaner Cartridge Price: Call Us |
| 447 |
691003 |
Screw (Air Guide Cover) (Long) Price: Call Us |
| 447A |
697551 |
Screw (Air Guide Cover) (Short) Price: Call Us |
| 462 |
691261 |
Washer (Starter Cable) Price: Call Us |
| 467 |
691008 |
Knob-Air Cleaner Price: Call Us |
| 474 |
696459 |
Alternator Price: Call Us |
| 505 |
691029 |
Nut (Governor Control Lever) Price: Call Us |
| 510 |
696541 |
Drive-Starter Price: Call Us |
| 512 |
796530 |
Hose-Oil Drain Price: Call Us |
| 513 |
692024 |
Clutch-Drive Price: Call Us |
| 523 |
691036 |
Dipstick Price: Call Us |
| 525 |
691037 |
Tube-Dipstick Price: Call Us |
| 552 |
690552 |
Bushing-Governor Crank Price: Call Us |
| 552A |
690553 |
Bushing-Governor Crank Price: Call Us |
| 562 |
690311 |
Screw (Governor Control Lever) Price: Call Us |
| 573 |
790444 |
Plate-Back Price: Call Us |
| 601 |
791850 |
Hose-Clamp (Green) Price: Call Us |
| 601A |
691038 |
Hose-Clamp (Black) Price: Call Us |
| 615 |
698290 |
Retainer-Governor Shaft Price: Call Us |
| 616 |
691045 |
Crank-Governor Price: Call Us |
| 628 |
697551 |
Screw (Fuel Pump Bracket) Price: Call Us |
| 633 |
699813 |
Seal-Choke/Throttle Shaft (Choke Shaft) Price: Call Us |
| 635 |
66538S |
Boot-Spark Plug Price: Call Us |
| 654 |
690958 |
Nut (Carburetor) Price: Call Us |
| 668 |
691215 |
Spacer (Rotating Screen) Price: Call Us |
| 672 |
690234 |
Gasket-Carburetor Plate Price: Call Us |
| 697 |
690372 |
Screw (Drive Cap) Price: Call Us |
| 703 |
691010 |
Clip Price: Call Us |
| 718 |
690959 |
Pin-Locating Price: Call Us |
| 742 |
690328 |
Retainer-E Ring Price: Call Us |
| 750 |
796208 |
Screw (Oil Pump Cover) Price: Call Us |
| 783 |
695708 |
Gear-Pinion Price: Call Us |
| 788 |
793145 |
Bracket-Fuel Pump Price: Call Us |
| 789 |
698330 |
Harness-Wiring Price: Call Us |
| 798 |
697890 |
Screw (Rocker Arm) Price: Call Us |
| 801 |
691283 |
Cap-Drive Price: Call Us |
| 802 |
691286 |
Cap-End Price: Call Us |
| 847 |
499602 |
Dipstick/Tube Assembly Price: Call Us |
| 851 |
493880S |
Terminal-Spark Plug Price: Call Us |
| 865 |
691012 |
Cover-Air Guide (Cylinder #1) Price: Call Us |
| 865A |
796541 |
Cover-Air Guide (Cylinder #2) Price: Call Us |
| 865B |
691015 |
Cover-Air Guide (Cylinder #3) Price: Call Us |
| 877 |
790544 |
Wire/Connector-Alternator Price: Call Us |
| 914 |
691127 |
Screw (Rocker Cover) Price: Call Us |
| 918 |
793147 |
Hose-Vacuum Price: Call Us |
| 947 |
699728 |
Solenoid-Fuel Price: Call Us |
| 965 |
796221 |
Cover-Oil Pump Price: Call Us |
| 967 |
273638S |
Filter-Pre Cleaner Price: Call Us |
| 968 |
791242 |
Cover-Air Cleaner Price: Call Us |
| 975 |
499810 |
Bowl-Fuel Price: Call Us |
| 1000 |
791959 |
Pivot-Rocker Arm Price: Call Us |
| 1005 |
791236 |
Fan-Flywheel Price: Call Us |
| 1013 |
690954 |
Nipple-Oil Filter Price: Call Us |
| 1017 |
796214 |
Screen-Oil Pump Price: Call Us |
| 1023 |
793146 |
Cover-Rocker (Cylinder #1) Price: Call Us |
| 1023A |
499600 |
Cover-Rocker (Cylinder #2) Price: Call Us |
| 1024 |
796220 |
Pump-Oil Price: Call Us |
| 1026 |
690981 |
Rod-Push (Steel) Price: Call Us |
| 1026A |
690982 |
Rod-Push (Aluminum) Price: Call Us |
| 1027 |
492932S |
Filter-Oil Price: Call Us |
| 1029 |
690972 |
Arm-Rocker Price: Call Us |
| 1051 |
691265 |
Ring-Retaining Price: Call Us |
| 1054 |
280275 |
Tie-Cable Price: Call Us |
| 1058 |
276245 |
Operator's Manual Price: Call Us |
| 1059 |
698516 |
Kit-Screw/Washer Price: Call Us |
| 1070 |
791680 |
Screw (Flywheel Fan) Price: Call Us |
| 1090 |
691293 |
Retainer-Brush Price: Call Us |
| 1095 |
694013 |
Gasket Set-Valve Price: Call Us |
| 1119 |
691183 |
Screw (Alternator) Price: Call Us |
| 1124 |
690988 |
Seal-O Ring (Fuel Transfer Tube) Price: Call Us |
| 1126 |
690991 |
Screw (Fuel Transfer Tube) Price: Call Us |
| 1127 |
690992 |
Screw (Float Bowl) Price: Call Us |
| 1128 |
690990 |
Screw (Carburetor Nozzle) Price: Call Us |
| 1329 |
44L7770037 |
Replacement Engine Price: Call Us |
| 1330 |
273521 |
Repair Manual Price: Call Us |
| 1342 |
699731 |
Extension-Fuel Transfer Tube Price: Call Us |
