| Ref | Part Number | Description |
|---|
| 1 |
539109754 |
BLADE MULCH 14-7/8" Price: $14.99 |
| 1 |
539109755 |
BLADE MULCH 21" Price: $22.99 |
| 1 |
539109756 |
BLADE MULCH 16-1/4" Price: $19.99 |
| 1 |
539109757 |
BLADE MULCH 18" Price: $19.99 |
| 1 |
93-7836 |
DECAL-PEDAL, TRACTION This part replaces 27-7320. Price: $14.38 |
| 2 |
539110700 |
MULCH BAFFLE, LEFT, 42 Price: $89.99 |
| 2 |
539110705 |
BAFFLE WLDMT 42" LH Price: $109.99 |
| 2 |
539110710 |
BAFFLE WLDMT, 52" L.H. Price: $119.99 |
| 2 |
539110715 |
BAFFLE WLDMT, 61" L.H. MULCH Price: $179.99 |
| 2 |
70-2200 |
DECAL Price: $5.09 |
| 3 |
539110702 |
BAFFLE WLDMT, 42" R.H. MULCH Price: $99.99 |
| 3 |
539110707 |
BAFFLE WLDMT 48 RH Price: $74.99 |
| 3 |
539110712 |
BAFFLE WLDMT, 52" R.H. MULCH Price: $169.99 |
| 3 |
539110717 |
BAFFLE WLDMT 61" R.H. MULCH Price: $109.99 |
| 3 |
66-6390 |
DECAL-CAUTION Price: $27.63 |
| 4 |
21-2660-01 |
PLATE-SIDE This part replaces 21-2660. Price: $299.86 |
| 4 |
539110704 |
MULCH CAP 42" Price: $74.99 |
| 4 |
539110709 |
MULCH CAP 48 Price: $54.99 |
| 4 |
539110714 |
MULCH CAP 52 Price: $59.99 |
| 4 |
539110719 |
MULCH CAP 61 Price: $54.99 |
| 5 |
32128-21 |
NUT-HF Price: $0.39 |
| 5 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 6 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 6 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 7 |
3217-6 |
NUT-HEX Price: $1.19 |
| 7 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 8 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 10 |
24-6390 |
STUD-HOLDDOWN, BATTERY Price: $19.83 |
| 11 |
32103-2 |
NUT-WING Price: $0.68 |
| 12 |
28-1280 |
DISCONTINUED Price: Call Us |
| 13 |
70-1180 |
DISCONTINUED Price: Call Us |
| 14 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 16 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 17 |
3290-144 |
SCREW-SHWH Price: $0.47 |
| 18 |
27-7290 |
DECAL-PTO Price: $17.38 |
| 19 |
38-4550-03 |
COVER-INSTRUMENTS This part replaces 38-4550. Price: $448.71 |
| 20 |
92-7802 |
DECAL-INSTR., START This part replaces 43-4290. Price: $22.12 |
| 21 |
92-7800 |
BATTERY COVER ASM This part replaces 24-9740. Price: $65.49 |
| 22 |
39-8020 |
TRIM-COVER, INSTRUMENT Price: $15.23 |
| 23 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 24 |
24-6420-03 |
HOLDDOWN-BATTERY This part replaces 24-6420. Price: $55.90 |
| 25 |
2412-61 |
TINNERMAN CLIP Price: $4.93 |
| 26 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 27 |
2412-4 |
CLAMP-R Price: $4.22 |
| 28 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 29 |
37-9650 |
TRIM-BOX, TOOL Price: $19.76 |
| 30 |
67-1710 |
DECAL-WARNING Price: $7.83 |
| 31 |
49-2280 |
DECAL Price: $22.38 |
| 32 |
43-4300 |
TRIM-FRAME, REAR Price: $13.54 |
| 33 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 34 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 35 |
2412-74 |
R-CLAMP Price: $2.37 |
| 36 |
93-3183 |
TOOL BOX ASM This part replaces 38-4530. Price: $240.67 |
| 37 |
32128-20 |
NUT-HF Price: $0.99 |
| 38 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 39 |
32128-33 |
NUT-HF Price: $0.25 |
| 40 |
82-9970 |
DISCONTINUED Price: Call Us |
| 41 |
72-3690 |
DISCONTINUED Price: Call Us |
| 42 |
93-7830 |
DECAL-TORQUE This part replaces 67-1720. Price: $23.91 |
| 43 |
68-8610-01 |
EXTENSION-FENDER This part replaces 68-8610. Price: $186.20 |
| 44 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 45 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 46 |
21-2770 |
PAD-FLOOR PLATE, RH Price: $96.81 |
| 47 |
21-2760 |
PAD-PLATE FLOOR, LH Price: $96.42 |
| 48 |
88-0070-01 |
PLATE-FLOOR This part replaces 77-3210. Price: $169.68 |
| 49 |
75-0810 |
CAUTION DECAL Price: $15.36 |
| 50 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 51 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 539111350 |
539111350 |
MULCH KITS 42" Price: $149.95 |
| 539111351 |
539111351 |
MULCH KITS 48" Price: $169.95 |
| 539111352 |
539111352 |
MULCH KITS 52" Price: $179.95 |
