| Ref | Part Number | Description |
|---|
| 2 |
N/A |
CASE |
| 3 |
716-0101 |
Retaining Ring-external This part replaces 9500. Price: $3.37 |
| 4 |
1008-1 |
PULLEY-TRANS MACH 2 BELT Price: Call Us |
| 4A |
690-120-0067 |
BLADE - 21" x 7/16" Not Available This part replaces 1008. Price: |
| 4B |
1484 |
PULLEY-TRANS-MACH Price: Call Us |
| 5 |
GW-9301 |
Key, 3/16 sq. x 1 This part replaces 9301. Price: $3.46 |
| 6 |
GW-9322099 |
PIN -roll (spirol, 5/16" x 1-1/2" long, wheel hub to shaft This part replaces 9322. Price: $6.86 |
| 7 |
9713 |
BOLT-HH 3/8-16X1.5 FTH ZP Price: Call Us |
| 8 |
9913 |
WASHER-LK .375 @ DEPL Price: $1.89 |
| 9 |
9710 |
SCR-HH 3/8-16X1.0 G5 ZP Price: Call Us |
| 10 |
9913 |
WASHER-LK .375 @ DEPL Price: $1.89 |
| 11 |
9903 |
WASHER-1.0X.438X.104 ZP Price: Call Us |
| 12 |
1077 |
BRKT-FRONT HOOD WELD Price: Call Us |
| 13 |
GW-1920 |
BLOCK - belt adjustment, 3-7/8" long This part replaces 1920. Price: $53.19 |
| 13A |
1133-1A |
BLOCK-BELT ADJUST MACH Price: Call Us |
| 14 |
9802 |
NUT-HEX 3/8-16 ZP Price: Call Us |
| 15 |
1519 |
HOOD W/DECALS HI&II Price: Call Us |
| 16 |
GW-9119 |
KNOB -handlebar height adjustment This part replaces 9119. Price: $10.22 |
| 17 |
1900864 |
Depth Regulator This part replaces 1117A. Price: $75.79 |
| 18 |
1076 |
KIT-REAR HOOD BRKT Price: Call Us |
| 19 |
9723 |
SCR-RH 1/4-20 X .75 ZP Price: Call Us |
| 20 |
9910 |
WASHER-LK .25 ZP Price: Call Us |
| 21 |
9800 |
NUT-HEX 1/4-20 ZP Price: Call Us |
| 22 |
GW-1113-1099 |
BUSHING - spacer, 19/64" (.300") long, yoke link to retaining plug This part replaces 1113-1. Price: $4.53 |
| 23 |
4763 |
BAR-DRAG PNT RED Price: Call Us |
| 24 |
9703 |
SCR-HHC 5/16-18X.75 GR 5 ZP Price: Call Us |
| 25 |
9912 |
WASHER-LK .312 ZP Price: $19.56 |
| 26 |
9801 |
NUT-HEX 5/16-18 ZP Price: Call Us |
| 27 |
GW-1119 |
PLUNGER Not Available This part replaces 1119. Price: |
| 28 |
GW-1120 |
SPRING .406 x 1.25 Not Available This part replaces 1120. Price: |
| 29 |
1105620 |
PLUG-SQ HEAD 1/4-18 NPT This part replaces 9726. Price: $3.66 |
| 30 |
N/A |
BOLO TINE ASSEMBLY, RIGHT |
| 31 |
GW-9301 |
Key, 3/16 sq. x 1 This part replaces 9301. Price: $3.46 |
| 32 |
N/A |
SEE TINE ASSEMBLIES, PAGES 18 & 19 |
| 33 |
9145 |
CAP-HUB BLK PLASTIC Price: Call Us |
| 34 |
736-04187 |
SHIM - engine pulley, 1/16" thick This part replaces 1138-1. Price: $4.36 |
| 35 |
9902 |
WASHER-FLAT 5/16 SAE Price: Call Us |
| 37 |
1239 |
DECAL-HOOD Price: Call Us |
| 38 |
1238 |
DECAL-HORSE LOGO OPC Price: Call Us |
