| Ref | Part Number | Description |
|---|
| 1 |
48-7960 |
NUT This part replaces 33015-00. Price: $1.40 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 2 |
98-7096 |
DISCONTINUED Price: Call Us |
| 3 |
105-7835 |
SEAL This part replaces 71-4760. Price: $2.76 |
| 4 |
71-4740-03 |
RH TIE ROD END ASM This part replaces 71-4740. Price: $163.79 |
| 5 |
302-55 |
FITTING-GREASE Price: $3.09 |
| 6 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 7 |
323-9 |
SCREW-HH Price: $1.29 |
| 8 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 9 |
33106-035 |
SCREW-HHF Price: $8.35 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
93-5142 |
PIN-PIVOT, AXLE Price: $238.83 |
| 11 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 12 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 12 |
532405472 |
RP_PULLEY ENGINE Price: $34.99 |
| 13 |
17-6019 |
AXLE PIVOT ASM This part replaces 95-4411-03. Price: $354.34 |
| 14 |
93-4510 |
BUSHING-CASTER Price: $6.97 |
| 15 |
104-0193 |
TIE ROD ASM This part replaces 104-0100-03. Price: $539.80 |
| 15 |
599306004 |
FUEL TANK, 3GAL, 2.25"NECK, 20 This part replaces 532420722. Price: $199.99 |
| 16 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 17 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 18 |
33108-035 |
SCREW-HHF Price: $24.13 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 This part replaces 532430213. Price: $37.99 |
| 19 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 20 |
32136-13 |
NUT-SHH Price: $2.85 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
95-2647 |
SEAL-HUB Price: $32.24 |
| 22 |
254-92 |
CONE-BEARING, OUTER This part replaces 95-2646. Price: $15.84 |
| 23 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 24 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 25 |
3220-7 |
NUT-JAM Price: $4.09 |
| 26 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 27 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
74-5560 |
TIRE (20X8-10) 6-PLY Price: $118.04 |
| 28 |
95-2625 |
TIRE (18X8.5-10) 4-PLY Price: $104.27 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
100-1357 |
RIM Price: $215.78 |
| 30 |
217-122 |
DISCONTINUED Price: Call Us |
| 31 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 32 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 33 |
21-2820 |
HUB Price: $269.34 |
| 34 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 35 |
98-7095 |
LH SPINDLE KIT Price: $939.33 |
| 36 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
62-2170 |
WASHER-THRUST Price: $4.48 |
| 38 |
93-5503 |
PIN-PIVOT, SPINDLE Price: $108.53 |
| 39 |
104-0191 |
STEERING CYLINDER ASM This part replaces 93-5502. Price: $814.09 |
| 40 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 41 |
108-1340-03 |
ROD END-BALL JOINT This part replaces 92-5072. Price: $163.94 |
| 42 |
3210-7 |
SCREW-HH Price: $0.61 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
33108-035 |
SCREW-HHF Price: $24.13 |
| 44 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 45 |
33026-00 |
NUT-HEX Price: $1.02 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
93-5121-03 |
AXLE-REAR ASM Price: $930.14 |
| 47 |
33115-040 |
SCREW-HH Price: $1.22 |
| 48 |
104-0101-03 |
TUBE & CLAMP ASM Price: $264.08 |
| 49 |
93-5983-03 |
PLATE-WEIGHT Price: $109.56 |
| 50 |
33106-060 |
SCREW-HHF Price: $9.91 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
