| Ref | Part Number | Description |
|---|
| 1 |
104-7201 |
NUT-HF Price: $0.69 |
| 2 |
119-1403-03 |
PEDAL-BRAKE Price: $112.59 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
5-0652 |
SPACER Price: $5.35 |
| 4 |
115-8060 |
CLEVIS-DOUBLE Price: $15.64 |
| 5 |
115-8059 |
YOKE-CABLE Price: $11.28 |
| 6 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 7 |
117-3214 |
CABLE-BRAKE Price: $119.83 |
| 8 |
119-1407 |
PEDAL-PARK Price: $24.62 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 9 |
99-7140 |
SPRING-TORSION Price: $21.98 |
| 10 |
323-12 |
SCREW-HH Price: $1.14 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
532405472 |
RP_PULLEY ENGINE This part replaces 586728901. Price: $34.99 |
| 13 |
119-1406 |
DETENT-BRAKE Price: $36.40 |
| 14 |
119-1405 |
ROD-BRAKE PAWL Price: $24.23 |
| 15 |
119-1414 |
PIN-COTTER, LOCKING Price: $0.54 |
| 15 |
597954502 |
FUEL TANKS This part replaces 532433004. Price: $109.99 |
| 16 |
119-1415 |
PIN-COTTER, LOCKING Price: $0.22 |
| 17 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 18 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 18 |
532438596 |
CAP.2.25'.VENTED.TETHER .EPA Price: $29.99 |
| 19 |
3290-221 |
WASHER-SPRING Price: $3.12 |
| 20 |
119-1388 |
PIN-BRAKE Price: $39.02 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
323-6 |
SCREW-HH Price: $0.66 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
52-2891 |
BUSHING-FLANGED, NYLON Price: $3.19 |
| 24 |
323-7 |
SCREW-HH Price: $0.65 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 Price: $24.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
