| Ref | Part Number | Description |
|---|
| 1 |
127-3107 |
GASKET-MANIFOLD, INTAKE Price: $21.63 |
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 2 |
127-3135 |
INTAKE MANIFOLD ASM Price: $518.40 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $37.99 |
| 3 |
127-3134 |
MANIFOLD-INTAKE Price: $263.05 |
| 4 |
127-3180 |
STUD Price: $3.41 |
| 5 |
127-3031 |
SENSOR-TEMP, AIR Price: $1,039.57 |
| 6 |
125-7220 |
BOLT Price: $4.99 |
| 7 |
127-3152 |
DUCT-SUCTION Price: $220.31 |
| 8 |
127-3096 |
JOINT-RUBBER Price: $332.63 |
| 9 |
127-3153 |
JOINT-RUBBER Price: $108.13 |
| 9 |
532193641 |
DASH This part replaces 532195420. Price: $47.99 |
| 10 |
125-7189 |
CLAMP-HOSE Price: $4.61 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
127-3170 |
CLAMP-HOSE Price: $23.69 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $9.99 |
| 12 |
125-7190 |
CLAMP-HOSE Price: $12.29 |
| 13 |
127-3171 |
CLAMP-HOSE Price: $6.48 |
| 13 |
532181719 |
PANEL DASH RH Price: $8.99 |
| 14 |
127-3034 |
GASKET-COLLECTOR Price: $9.66 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 15 |
127-3093 |
INTAKE COLLECTOR ASM Price: $584.00 |
| 16 |
127-3092 |
COLLECTOR-INTAKE Price: $203.81 |
| 17 |
127-3139 |
VALVE-REED Price: $187.29 |
| 18 |
127-3080 |
JOINT-HOSE Price: $52.33 |
| 19 |
127-3081 |
JOINT-HOSE Price: $79.17 |
| 20 |
127-3166 |
WASHER-SEAL Price: $6.77 |
| 20 |
532162026 |
PLATE BATTERY Price: $6.99 |
| 21 |
127-3168 |
SCREW Price: $2.67 |
| 22 |
127-3181 |
STUD Price: $3.97 |
| 23 |
127-3045 |
SPACER-VALVE, E G R Price: $34.81 |
| 24 |
127-3046 |
GASKET-E G R Price: $4.88 |
| 25 |
125-7220 |
BOLT Price: $4.99 |
| 26 |
127-3178 |
BOLT Price: Call Us |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 27 |
127-3182 |
STUD Price: $2.86 |
| 28 |
125-7229 |
NUT Price: $3.12 |
| 29 |
127-3035 |
BEND-INLET Price: Call Us |
| 30 |
127-3036 |
BODY-THROTTLE Price: $1,205.87 |
| 30 |
532192814 |
FENDER.W/CUPHOLDER.ORANGE This part replaces 532194806. Price: $219.99 |
| 31 |
127-3037 |
GASKET-THROTTLE Price: $2.87 |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 32 |
125-7209 |
BOLT Price: $2.74 |
| 33 |
125-7211 |
BOLT Price: $3.48 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 39 |
532407807 |
BRACKET PIVOT This part replaces 532174714. Price: $27.99 |
| 58 |
532151171 |
AIR DUCT This part replaces 532184463. Price: $46.99 |
| 60 |
872140606 |
Bolt - Rd. Hd. Sq. Neckiage 3/8 16 x 3/4 Price: $4.99 |
| 64 |
532174997 |
DASH LOWER Price: $24.99 |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 90 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 159 |
532191120 |
CUPHOLDER.RIGHT.GREY This part replaces 532192404. Price: $8.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 217 |
532179132 |
CONSOLE FUEL WINDOW GRAY This part replaces 532185436. Price: $7.99 |
| 278 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 280 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
