| Ref | Part Number | Description |
|---|
| 1 |
585039802 |
GUARD.ENGINE.HUSQ.RZ.X498 Price: $29.99 |
| 1 |
603-04062-0637 |
CYLINDER LIFT ARM PIN Not Available Price: |
| 2 |
589283402 |
FRAME.TUBE.RZ.MAIN.WELD.RH.ORG Price: $79.99 |
| 2 |
903-0964 |
CENTER LINK ASSEMBLY- Not Available This part replaces 603-0964. Price: |
| 3 |
589283302 |
FRAME.TUBE.RZ.MAIN.WELD.LH.ORG Price: $79.99 |
| 3 |
603-0965 |
LINK ASSEMBLY-LOWER HI Not Available Price: |
| 4 |
584991002 |
TUBE.PNT.FRAME.RER.HUSQ.23".RZ Price: $74.99 |
| 4 |
903-0970 |
FIXED LIFT LINK ASSEMBLY Not Available This part replaces 603-0970. Price: |
| 5 |
603-0971A-0637 |
HITCH BRACKET ASSEMBLY MOUNTING (POWDER BLACK) Not Available This part replaces 603-0971-0637. Price: |
| 6 |
586703801 |
COVER.FOOTREST.REFRESH.ASM This part replaces 585522401. Price: $54.99 |
| 6 |
603-0972-0637 |
LIFT CYLINDER MOUNTING PIN (POWDER BLACK) Not Available Price: |
| 7 |
903-0973 |
ADJUSTABLE LINK ASSEMBLY Not Available This part replaces 603-0973. Price: |
| 8 |
585989301 |
GROMMET.BUMPER Price: $3.99 |
| 8 |
603-0977 |
CHECK CHAIN ASSEMBLY Not Available Price: |
| 9 |
585523104 |
CROSS.PNT.MEMBER.BLK Price: $84.99 |
| 9 |
919-3095 |
UPPER HITCH ARM (LH) Not Available This part replaces 619-3095. Price: |
| 10 |
585523204 |
SKID.PLATE.PNT.RZ.REF.SIVER Price: $32.99 |
| 10 |
919-3096 |
UPPER HITCH ARM (RH) Not Available This part replaces 619-3096. Price: |
| 11 |
585331602 |
COVER.RAIL.RH.RZ.X668 Price: $37.99 |
| 11 |
703-4137-0637 |
REAR PTO SHIELD Not Available Price: |
| 12 |
585331502 |
COVER.RAIL.LH.RZ.X668 Price: $37.99 |
| 12 |
703-4143-0637 |
CHECK CHAIN BRACKET Not Available Price: |
| 13 |
597783101 |
GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 13 |
710-04186 |
Screw, Hex Cap Lock, 1/2-13 x 1.25 GR5 Price: $6.17 |
| 14 |
593842101 |
Bushings This part replaces 532195263. Price: $4.99 |
| 14 |
710-0514 |
Screw, Hex Cap, 3/8-16 x 1.0 GR5 Price: $3.78 |
| 15 |
521938102 |
Links This part replaces 521938101. Price: $12.99 |
| 15 |
710-0599 |
Screw, Hex Wash. Hd. Tapp 1/4-20 x .5 Price: $3.86 |
| 16 |
580501302 |
FENDER.SUPPORT.PNT.X431 Price: $32.99 |
| 16 |
710-3168 |
Screw, Carriage, 3/8-16 x 1.0 Price: $3.61 |
| 17 |
593118304 |
SUPPORT RZ REFRESH RH CONSOLE This part replaces 585523404. Price: $17.99 |
| 17 |
710-3296 |
Screw, Hex Cap, 1/4-20 x .75 GR5 Price: $3.85 |
| 18 |
585523604 |
SUPPORT.PNT.LH.CONSOLE.FRONT Price: $34.99 |
| 18 |
711-0469 |
Spacer, .75 x 1.25 x .5 Price: $7.14 |
| 19 |
585474302 |
BRKT ROD.BYPASS.EZT.X431 Price: $8.99 |
| 19 |
711-0679A |
Pin, Clevis, 3/8 x 2.015 This part replaces 711-0599. Price: $12.40 |
| 20 |
596434801 |
Bolts This part replaces 874780536. Price: $2.99 |
| 20 |
711-1105 |
Pin, Klik Price: $10.43 |
| 21 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 21 |
711-1733 |
CLEVIS PIN 19MM x 84MM Not Available Price: |
| 22 |
596564405 |
Bolts This part replaces 874780648. Price: $2.99 |
| 22 |
911-1743 |
HITCH LIFT ARM PIN Not Available This part replaces 711-1743. Price: |
| 23 |
585940001 |
BOLT.CARRIAGE.5/16-18.7/16 Price: $2.99 |
| 23 |
911-1750 |
ROCK SHAFT Not Available This part replaces 711-1750. Price: |
| 24 |
577117702 |
Hardware This part replaces 577117701. Price: $3.99 |
| 24 |
911-1753 |
CHECK CHAIN CLEVIS Not Available This part replaces 711-1753. Price: |
| 25 |
586654302 |
Bolts This part replaces 586654301. Price: $1.99 |
| 25 |
911-1761 |
CLEVIS PIN .75 Not Available This part replaces 711-1761. Price: |
| 26 |
586881101 |
BOLT.5/16-18.THRD.ROLL.SHOULDR Price: $2.99 |
| 26 |
712-0301 |
Nut, Hex Jam, 3/4-10 GR5 Price: $7.26 |
| 27 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 27 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 28 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
714-0117 |
Pin, Internal Cotter Price: $3.85 |
| 29 |
585938101 |
NUT ACORN,FLANGED,5/16-18 Price: $2.99 |
| 29 |
714-0142 |
COTTER PIN-3/16 DIA x 1.50 Not Available Price: |
| 30 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 30 |
714-0149B |
Pin, Internal Cotter Price: $3.95 |
| 31 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 31 |
715-0121 |
Pin, Spirol, 1/4 x 2.0 Price: $5.95 |
| 32 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 32 |
916-04004 |
SNAP RING Not Available This part replaces 716-04004. Price: |
| 33 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
| 33 |
917-3532A |
HITCH LIFT CYLINDER Not Available This part replaces 717-3532. Price: |
| 34 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 34 |
736-0255 |
Washer, Belleville, .51 x 1.14 x .04 Price: $4.02 |
| 35 |
583400601 |
PALNUT.5/16" This part replaces 532423063. Price: $2.99 |
| 35 |
736-0315 |
Washer, Flat, .76 x 1.5 x .12 Price: $5.94 |
| 36 |
936-0364 |
WASHER Not Available This part replaces 736-0364. Price: |
| 37 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 38 |
738-0143 |
SHOULDER SCREW .498 DIA x .340 Price: $3.93 |
| 39 |
941-04084 |
SLEEVE BEARING 1.2 Not Available This part replaces 741-04084. Price: |
