| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 1 |
9194R |
DRILLED RIVET RT Price: Call Us |
| 2 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
74760520 |
BOLT Price: Call Us |
| 3 |
282-2 |
YOKE Price: $30.04 |
| 3 |
74760512 |
BOLT Price: Call Us |
| 4 |
283-61 |
PIN-YOKE Price: $1.56 |
| 4 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 5 |
10040500 |
LOCKWASHER Price: Call Us |
| 5 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 6 |
47-5320-01 |
LEVER Price: $84.02 |
| 6 |
73800600 |
NUT Price: Call Us |
| 7 |
44-0870 |
CAM SHAFT ASM Price: $213.32 |
| 7 |
4921H |
SPRING.RETAINER Price: Call Us |
| 8 |
1952J |
SUB= 1952J500 Price: Call Us |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 9 |
122233X |
SUB= 2582J Price: Call Us |
| 9 |
27-2320 |
BEARING Price: $15.22 |
| 10 |
326J |
SUB= 4929H Price: Call Us |
| 10 |
57-6220 |
LINK-CONNECTING Price: $6.01 |
| 11 |
233-48 |
KNOB Price: $10.92 |
| 11 |
74780628 |
BOLT Price: Call Us |
| 12 |
74760524 |
BOLT.HEX.5/16-1.5 Price: Call Us |
| 12 |
93-9934 |
TRACTION HANDLE ASM Price: $86.68 |
| 13 |
1951J |
SUB= 1951J500 Price: Call Us |
| 13 |
283-57 |
PIN-CLEVIS Price: $1.15 |
| 14 |
120958X |
WASHER Price: Call Us |
| 14 |
49-6220 |
BRACKET-ARM, CONTROL Price: $28.06 |
| 15 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 15 |
5388J |
STAKE SPRING TI Price: Call Us |
| 16 |
121117X |
BOLT SHOULDER Price: Call Us |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 17 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 17 |
9188R |
SUB= 107644X Price: Call Us |
| 18 |
19131311 |
WASHER Price: Call Us |
| 18 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 19 |
49-6250 |
BRACKET-PIVOT Price: $22.09 |
| 19 |
9190R |
SUB= 9190R500 Price: Call Us |
| 20 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 20 |
73680600 |
SUB= 73690600 Price: Call Us |
| 21 |
3211-2 |
SCREW-HH Price: $2.17 |
| 21 |
74760516 |
SUB= 77394 Price: Call Us |
| 22 |
49-6260 |
PIVOT ASM Price: $79.73 |
| 23 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 24 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 25 |
83-0540-01 |
TRACTION PEDAL ASM Price: $70.97 |
| 26 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 27 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 28 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 29 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 30 |
32128-20 |
NUT-HF Price: $0.99 |
| 31 |
2411-42 |
JOINT-BALL, LH Price: $19.07 |
| 32 |
83-0630 |
ARM-PIVOT, TRACTION Price: $25.47 |
| 33 |
3220-20 |
NUT-JAM Price: $0.92 |
| 34 |
83-0580 |
ROD-CONTROL, TRACTION Price: $53.72 |
| 35 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 36 |
2411-43 |
JOINT-BALL Price: $21.40 |
| 37 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 38 |
12-3270 |
SCREW Price: $3.09 |
| 39 |
49-6290 |
PIVOT SHAFT ASM Price: $25.43 |
| 40 |
32121-51 |
PIN-ROLL Price: $0.70 |
| 41 |
93-9936 |
BRACKET-RETURN, TRACTION Price: $6.79 |
| 42 |
93-9937 |
TRACTION CABLE ASM Price: $28.43 |
| 43 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 44 |
3272-10 |
PIN-COTTER Price: $0.25 |
