| Ref | Part Number | Description |
|---|
| 1 |
539101165 |
FILTER HEAD Price: $37.99 |
| 1 |
95-8526 |
BUSHING-PLASTIC Price: $4.22 |
| 2 |
539102606 |
HYDRAULIC OIL FILTER Price: $22.99 |
| 2 |
95-8527-0P |
LINK-SCISSOR This part replaces 95-8527-03. Price: $26.57 |
| 3 |
539101202 |
HYDRAULIC CAP Price: $19.99 |
| 3 |
95-8883 |
MOUNT-SCISSOR Price: $199.50 |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 4 |
539132147 |
HG_PUMP, 10CC W/O FAN OR RTN This part replaces 539107749. Price: $1,099.99 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
539105024 |
OIL TANK Price: $249.99 |
| 6 |
95-8521-03 |
FRAME-SCISSOR Price: $306.17 |
| 7 |
121-3654 |
CYLINDER-HYD This part replaces 95-8512. Price: $815.81 |
| 7 |
539101237 |
FITTING, STRAIGHT F6400-8-8-0 Price: $7.99 |
| 8 |
539103316 |
STRAIGHT FITG Price: $9.99 |
| 8 |
95-8603 |
SPACER Price: $8.43 |
| 9 |
539101238 |
ELBOW, F6801-6-6-0 90 DEGREE Price: $12.99 |
| 9 |
87-5330 |
WASHER Price: $1.78 |
| 10 |
324-6 |
SCREW-HH Price: $0.81 |
| 10 |
539106896 |
HYDRAULIC HOSE Price: $37.99 |
| 11 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 11 |
539104722 |
HOSE 7" Price: $19.99 |
| 12 |
125-1914 |
PIN-PIVOT Price: $27.84 |
| 12 |
539106895 |
TEE ASSEMBLY Price: $39.99 |
| 13 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 13 |
539106897 |
TEE ASSEMBLY Price: $49.99 |
| 14 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 14 |
539102396 |
FITTING Price: $11.99 |
| 15 |
46-6350 |
SPACER Price: $25.99 |
| 15 |
539105168 |
NUT 9/16-18 JIC CAP Price: $2.99 |
| 16 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 16 |
99-3505 |
SCISSORS LINK ASM Price: $30.03 |
| 17 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 17 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 18 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 19 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 20 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 21 |
539103115 |
O RING Price: $2.99 |
| 22 |
539103116 |
O RING Price: $2.99 |
| 23 |
539103117 |
O RING Price: $2.99 |
| 24 |
539103118 |
O RING Price: $2.99 |
| 25 |
539103119 |
O RING Price: $3.99 |
| 26 |
539101176 |
PULLEY Price: $37.99 |
| 27 |
510201401 |
BELT, PUMP This part replaces 539106887. Price: $34.99 |
| 28 |
539101177 |
KEY 5 MM SQ X 25 MM Price: $4.99 |
| 29 |
539102717 |
SCREW 5/16C X 5/8 SQ HEAD Price: $2.99 |
| 30 |
539104382 |
PUMP LEVER Price: $39.99 |
| 32 |
539130532 |
KIT, IDLER ARM W/PULLEY, PUMP This part replaces 539104408. Price: $149.99 |
| 33 |
539103256 |
SPRING Price: $9.99 |
| 34 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 35 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 36 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
