| Ref | Part Number | Description |
|---|
| 1 |
117-7586 |
CONNECTING ROD ASM This part replaces 98-9552. Price: $547.99 |
| 2 |
7070E |
KEY 1/4 X 2.5 Price: Call Us |
| 2 |
98-9642 |
CRANKSHAFT ASM Price: $4,332.74 |
| 3 |
7563R |
WASHER T Price: Call Us |
| 3 |
98-9514 |
CIRCLIP-PIN, PISTON Price: $2.79 |
| 4 |
98-9513 |
PIN-PISTON Price: $13.17 |
| 5 |
73680600 |
SUB= 73690600 Price: Call Us |
| 5 |
98-9551 |
PISTON RING ASM (STD) Price: $220.34 |
| 5 |
98-9619 |
PISTON RING ASM (0.5MM) Price: $96.35 |
| 6 |
112-8415 |
PISTON ASM This part replaces 98-9470. Price: $456.30 |
| 6 |
76020412 |
COTTER PIN Price: Call Us |
| 6 |
98-9550 |
PISTON (STD) Price: $274.67 |
| 7 |
127-0416 |
METAL-SIDE (+0.2MM) This part replaces 98-9414. Price: $21.04 |
| 7 |
140507 |
HUB WHEEL ASM Price: Call Us |
| 7 |
98-9413 |
BEARING-THRUST (STD) Price: $16.90 |
| 7 |
98-9415 |
BEARING-THRUST (0.4MM) Price: $9.77 |
| 8 |
127-0437 |
METAL-SIDE (+0.2MM) This part replaces 98-9689. Price: $18.42 |
| 8 |
127-0438 |
METAL-SIDE (+0.40MM) This part replaces 98-9690. Price: $12.65 |
| 8 |
98-9688 |
BEARING-THRUST (STD) Price: $16.90 |
| 9 |
115-4121 |
METAL-CRANKSHAFT (STD) This part replaces 98-9556. Price: $86.06 |
| 9 |
140080 |
BOLT.HUB.WHL.REAR Price: Call Us |
| 9 |
98-9526 |
BEARING-MAIN (0.2MM) Price: $64.36 |
| 9 |
98-9527 |
BEARING-MAIN (0.4MM) Price: $63.74 |
| 10 |
127-0433 |
METAL-CRANKSHAFT (-0.2MM) This part replaces 98-9530. Price: $60.46 |
| 10 |
98-9524 |
METAL-CRANKSHAFT (STD SET) This part replaces 98-9555. Price: $62.26 |
| 10 |
98-9531 |
BEARING-MAIN (0.4MM) Price: $39.97 |
| 11 |
112-7005 |
BEARING-MAIN (STD) This part replaces 98-9554. Price: $66.99 |
| 11 |
98-9528 |
BEARING-MAIN (-0.2MM) Price: $15.04 |
| 11 |
98-9529 |
BEARING-MAIN (0.4MM) Price: $40.04 |
| 12 |
98-9373 |
O-RING Price: $3.11 |
| 15 |
19131316 |
WASHER Price: Call Us |
| 17 |
140921 |
SPRING ROD BRAKE Price: Call Us |
| 20 |
73940800 |
SUB= 73360800 Price: Call Us |
| 22 |
140498 |
SHAFT ARM ASM Price: Call Us |
| 23 |
121274X |
KNOB.DUCKHEAD.1/2 Price: Call Us |
| 28 |
73350600 |
NUT Price: Call Us |
| 29 |
140494 |
ROD BRAKE Price: Call Us |
| 30 |
19131316 |
WASHER Price: Call Us |
| 32 |
73220700 |
NUT Price: Call Us |
| 33 |
12000053 |
E RING HYT Price: Call Us |
| 34 |
71673 |
PLUNGER CAP T Price: Call Us |
| 35 |
137648 |
ROD BRAKE PART GT Price: Call Us |
| 36 |
149412 |
SPRING.GRND.DRIVE Price: Call Us |
| 37 |
121749X |
WASHER Price: Call Us |
| 38 |
150035 |
BUSHING.NYLINER Price: Call Us |
| 39 |
74321016 |
SCREW Price: Call Us |
| 40 |
5304J |
ACT-SWITCH T Price: Call Us |
| 41 |
73631000 |
SUB= 69180 Price: Call Us |
| 42 |
8883R |
PEDAL COVER T Price: Call Us |
| 43 |
74760412 |
BOLT LT Price: Call Us |
| 44 |
104601X |
BRKT SWITCH GT Price: Call Us |
| 45 |
73800400 |
NUT Price: Call Us |
| 46 |
145170 |
RETAINER.SPRING Price: Call Us |
| 47 |
138228 |
ROD.CLUTCH Price: Call Us |
| 48 |
72110614 |
BOLT Price: Call Us |
| 49 |
19131413 |
WASHER Price: Call Us |
| 50 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 51 |
73800600 |
NUT Price: Call Us |
| 52 |
139123 |
PULLEY.IDLER.V.GR Price: Call Us |
| 53 |
207J |
WASHER T Price: Call Us |
| 54 |
138390 |
ARM.ASM.IDLER.CLU Price: Call Us |
| 56 |
140218 |
BELT-V 84.5 Price: Call Us |
| 58 |
74760724 |
BOLT Price: Call Us |
| 61 |
140488 |
PULLEY TRANSAXLE Price: Call Us |
| 64 |
154752 |
SHAFT-BRAKE/CLUTC Price: Call Us |
| 65 |
67609 |
AXLE BOLT Price: Call Us |
| 66 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 67 |
19131312 |
WASHER Price: Call Us |
| 68 |
5142H |
ROLL PIN STD Price: Call Us |
| 69 |
123800X |
WASHER Price: Call Us |
| 70 |
151146 |
SUB= 164892 Price: Call Us |
| 72 |
73800500 |
NUT Price: Call Us |
| 73 |
74780548 |
BOLT FIN HEX 5/16 Price: Call Us |
| 74 |
142432 |
SCREW HEXWSH H-L Price: Call Us |
| 75 |
73800700 |
NUT.7/16 Price: Call Us |
| 76 |
140481 |
BRACKET TRAN VGTH Price: Call Us |
| 77 |
74760716 |
BOLT Price: Call Us |
| 78 |
19111212 |
WASHER Price: Call Us |
| 79 |
72110505 |
BOLT Price: Call Us |
| 80 |
140484 |
BRACKET TORQUE RH Price: Call Us |
| 81 |
17490612 |
SCREW Price: Call Us |
| 82 |
150586 |
BRACKET.MTG.FAN Price: Call Us |
| 83 |
140479 |
STRAP TORQUE MID Price: Call Us |
| 84 |
140490 |
SPACER Price: Call Us |
| 85 |
17541020 |
SCREW YTV Price: Call Us |
| 87 |
140491 |
ADAPTER FAN Price: Call Us |
| 88 |
140492 |
SUB= 161592 Price: Call Us |
| 89 |
73680700 |
NUT GTV Price: Call Us |
| 90 |
140489 |
KEEPER BELT Price: Call Us |
| 91 |
17490644 |
SCREW.HXWSH.3/8 Price: Call Us |
| 92 |
74760520 |
BOLT Price: Call Us |
| 93 |
140502 |
LINK ASM SHIFT Price: Call Us |
| 94 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 95 |
23200528 |
SCREW SET 5/16 Price: Call Us |
| 96 |
141103 |
WASHER NICKEL PLT Price: Call Us |
| 97 |
126874X |
BEARING THRUST Price: Call Us |
| 98 |
141004 |
BRACKET SHIFT Price: Call Us |
| 99 |
17490624 |
SCREW LT Price: Call Us |
| 100 |
126881X |
WASHER COMPRESSIN Price: Call Us |
| 101 |
59285 |
WASHER Price: Call Us |
| 102 |
73560500 |
NUT HEX NYLOCK Price: Call Us |
| 103 |
73350500 |
JAM NUT TI Price: Call Us |
| 104 |
140480 |
BRACKET IDLER Price: Call Us |
| 105 |
17580408 |
SCREW CRT Price: Call Us |
| 106 |
142918 |
O-RING.ASM.70110 Price: Call Us |
| 108 |
142917 |
CAP.VENT.70109 Price: Call Us |
| 109 |
140929 |
SPRING BRAKE Price: Call Us |
| 110 |
88652 |
HINGE SCREW Price: Call Us |
