| Ref | Part Number | Description |
|---|
| 1 |
4459J |
SUB= 6554J Price: Call Us |
| 1 |
903-04180 |
MUFFLER SHIELD Not Available This part replaces 603-04180. Price: |
| 2 |
132673 |
PIN.CLEVIS.SHEAR Price: Call Us |
| 2 |
703-05123-0637 |
PLATE (LH) BAFFLE (POWDER BLACK) Not Available Price: |
| 3 |
730-05124-0637 |
Plate, Baffle, RH Price: Call Us |
| 4 |
3146R |
RETAINER.SPRING Price: Call Us |
| 4 |
703-05211-0637 |
AIR BAFFLE PLATE(POWDER BLACK) Not Available Price: |
| 5 |
132727 |
HUB&PLATE ASM LH Price: Call Us |
| 5 |
703-05215-0637 |
ENGINE MOUNTING PLATE (POWDER BLACK) Not Available Price: |
| 6 |
73610600 |
SUB= 7810H Price: Call Us |
| 6 |
910-0195 |
HEX SCREW 1/4-28 x .62 Not Available This part replaces 710-0195. Price: |
| 7 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 7 |
710-0237 |
Screw, Hex Cap, 5/16-24 x .625 GR5 Price: $3.93 |
| 8 |
710-0357 |
SCREW-SQ HD SET 3/8-16 x .50 CUP Not Available Price: |
| 8 |
74610616 |
BOLT Price: Call Us |
| 9 |
4460J |
SUB= 6555J Price: Call Us |
| 9 |
710-0539 |
Screw, Hex Cap, 3/8-24 x 1.75 GR5 Price: $3.95 |
| 10 |
132728 |
HUB&PLATE ASM RH Price: Call Us |
| 10 |
710-0599 |
Screw, Hex Wash Hd Tapp 1/4-20 x .5 Price: $3.86 |
| 11 |
710-0607 |
Screw, Hex Wash Hd Tapp 5/16-18 x .5 Price: $6.06 |
| 12 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 13 |
710-1260A |
Screw, Hex Wash Hd Tapp 5/16-18 x .75 Price: $3.34 |
| 14 |
710-1376 |
Screw, Hex Cap, M8-1.25 x 16 GR8 Price: $6.06 |
| 15 |
710-3015 |
Screw, Hex Cap, 1/4-20 x .75 Price: $3.65 |
| 16 |
710-3038 |
Screw, Hex Cap, 5/16-18 x .875 GR5 Price: $4.17 |
| 17 |
712-0324 |
Nut, Hex Insert Lock, 1/4-20 GR8 Price: $3.38 |
| 18 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 19 |
712-3054 |
Nut, Hex Lock, 3/8-24 GRB Price: $3.90 |
| 20 |
917-04112 |
DRIVE SHAFT ASSEMBLY This part replaces 717-04112. Price: $614.44 |
| 21 |
918-04068 |
FLYWHEEL BUSHING Not Available This part replaces 718-04068. Price: |
| 22 |
918-04069 |
FLYWHEEL Not Available This part replaces 718-04069. Price: |
| 23 |
723-3061 |
Seal, Heat Baffle Price: $1.95 |
| 24 |
725-0157 |
Tie, Cable Price: $3.46 |
| 25 |
725-3281 |
POITIVE BATTERY CABLE Not Available Price: |
| 26 |
725-3282 |
NEGATIVE BATTERY CABLE Not Available Price: |
| 27 |
726-0205 |
Clamp, Hose Price: $3.71 |
| 28 |
735-0226 |
Grommet Price: $9.09 |
| 29 |
746-04015 |
Cable, Choke Control Not Available Price: |
| 30 |
946-04061 |
THROTTLE CABLE 29.37" Not Available This part replaces 746-04061. Price: |
| 31 |
751-10002A |
Muffler Not Available This part replaces 751-10002. Price: |
| 32 |
751-10054 |
Sleeve, Fuel Line Price: $69.14 |
| 33 |
951-10055 |
FUEL LINE FITTING Not Available This part replaces 751-10055. Price: |
| 34 |
751-3130 |
FUEL LINE (BULK) Not Available Price: |
| 35 |
951-10517A |
Drain, Oil This part replaces 751-3140. Price: $22.67 |
| 36 |
751-3142 |
Cap, Drain Price: $3.81 |
| 37 |
KH-730115 |
COMPLETE ENGINE Not Available Price: |
| 38 |
KH-25-072-24-S |
Stud, M8 - 1.25 x 33MM This part replaces KH-25-072-04. Price: $3.78 |
| 39 |
KH-25-041-17-S |
EXHAUST MANIFOLD GASKET This part replaces KH-24-041-02. Price: $2.43 |
| 40 |
712-3086 |
Nut, Hex, M8 x 1.25 Price: $3.86 |
| 41 |
714-0118 |
Key, Square, 1/4 x 1.5 Price: $6.06 |
| 42 |
2405013S1C |
FLTR-FUEL KOHLER This part replaces KH-24-050-09-S. Price: $15.89 |
| 43 |
KM-49040-2065 |
Pump, Fuel Price: $192.81 |
| 44 |
726-0230 |
Cable Tie This part replaces 726-0209. Price: $23.95 |
| 45 |
703-05456 |
COVER, FLYWHEEL Not Available Price: |
| 46 |
710-0514 |
Screw, Hex Cap, 3/8-16 x 1.0 GR5 Price: $3.78 |
| 47 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
