| Ref | Part Number | Description |
|---|
| 1 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 1 |
575438001 |
DECK SVC W/DECALS 42 YTH ORNGE Price: $1,599.99 |
| 2 |
539112170 |
MANDREL.DECK.ASSEMBLY Price: $69.99 |
| 2 |
92-2349 |
TUBE-VALVE TO COOLER Price: $61.15 |
| 3 |
237-22 |
O-RING Price: $2.43 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 539107520. Price: $3.99 |
| 4 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 4 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 539107630. Price: $3.99 |
| 5 |
237-42 |
O-RING Price: $2.78 |
| 5 |
596134801 |
Nuts This part replaces 539107590. Price: $1.00 |
| 6 |
539112078 |
BLADE, 14 5/8" Price: $19.99 |
| 6 |
85-8900 |
DISCONTINUED Price: Call Us |
| 7 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 7 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 539107522. Price: $6.99 |
| 8 |
3290-360 |
SCREW-HH Price: $4.34 |
| 8 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 9 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 9 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 10 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 10 |
88-8480 |
BRACKET-PIVOT Price: $17.24 |
| 11 |
3296-8 |
NUT-HEX Price: $1.29 |
| 11 |
539110731 |
DISCHARGE CHUTE 42" This part replaces 532110731. Price: $49.99 |
| 12 |
237-78 |
O-RING Price: $3.85 |
| 12 |
596646001 |
Springs This part replaces 532110735. Price: $3.99 |
| 13 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 13 |
595935501 |
Pins This part replaces 532110736. Price: $2.99 |
| 14 |
237-21 |
O-RING Price: $0.70 |
| 14 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 15 |
539112413 |
CONFINEMENT.PLATE.42".BLACK Price: $27.99 |
| 15 |
85-9570 |
HOSE-HYD Price: $66.91 |
| 16 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 16 |
85-9580 |
HOSE-HYD Price: $73.59 |
| 17 |
340-86 |
FITTING-TEE Price: $35.23 |
| 17 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 18 |
575224501 |
BUSHING, IDLER Price: $27.99 |
| 18 |
85-9600 |
DISCONTINUED Price: Call Us |
| 19 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 19 |
85-0380 |
TUBE-MOTOR TO VALVE Price: $60.31 |
| 20 |
43-1950 |
HYD CONTROL VALVE ASM Price: $695.34 |
| 20 |
539108271 |
HCS 3/8-16 X 3-1/2 GR5 ZD Price: $4.99 |
| 21 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 21 |
85-9470 |
DISCONTINUED Price: Call Us |
| 22 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 22 |
85-7760 |
DISCONTINUED Price: Call Us |
| 23 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 23 |
85-9420 |
DISCONTINUED Price: Call Us |
| 24 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 24 |
85-9390 |
DISCONTINUED Price: Call Us |
| 25 |
237-79 |
O-RING Price: $5.46 |
| 25 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 26 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 26 |
532178515 |
WASHER Price: $5.99 |
| 27 |
237-30 |
O-RING Price: $2.50 |
| 27 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 28 |
322-3 |
SCREW-HH Price: $0.79 |
| 28 |
574827102 |
ARM, IDLER, BLK Price: $27.99 |
| 29 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 29 |
539990923 |
RHSNB 3/8-16X1-3/4 Price: $2.99 |
| 30 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 30 |
85-9360 |
TUBE-FRONT MOTOR Price: $95.76 |
| 31 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 31 |
85-9410 |
TUBE-RH REAR MOTOR Price: $102.12 |
| 32 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 32 |
85-9400 |
DISCONTINUED Price: Call Us |
| 33 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
| 33 |
92-2348 |
TUBE - PUMP, RH Price: $65.42 |
| 34 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 34 |
85-9370 |
TUBE-FRONT MOTOR Price: $113.66 |
| 35 |
575224702 |
SHIELD.BELT.LH.ORANGE Price: $29.99 |
| 35 |
85-9720 |
FITTING-STR, ORIFICE Price: $119.77 |
| 36 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 36 |
575967102 |
SHIELD, BELT, RH 42 ORG This part replaces 575500302. Price: $29.99 |
| 37 |
2412-138 |
R-CLAMP Price: $1.36 |
| 37 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 38 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 40 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 41 |
596434404 |
Bolts This part replaces 539107608. Price: $4.99 |
| 42 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 43 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 44 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 45 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 46 |
574845601 |
BELT, 42" FAB DECK Price: $79.99 |
| 47 |
581724301 |
DECAL.DECK.6MIL.EURO.NOSTEP This part replaces 539105743. Price: $3.99 |
| 48 |
539113224 |
DECAL, CAUTION Price: $4.99 |
| 49 |
531229002 |
DECAL.DECK.BELT.ROUTING.48/54 This part replaces 532198785. Price: $1.99 |
| 50 |
531165901 |
SERVICE KIT GUARD This part replaces 575224301. Price: $4.99 |
| 51 |
575224401 |
PULLEY, MANDREL 4.08 OP Price: $29.99 |
| 52 |
596435201 |
Bolts This part replaces 539104870. Price: $2.99 |
| 53 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 54 |
539108461 |
BOLT 1/4-20 X 1/2 HWST Price: $2.99 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 56 |
596645601 |
Springs This part replaces 539106850. Price: $8.99 |
| 57 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 58 |
539112050 |
BEARING, BALL Price: $5.99 |
| 59 |
575416201 |
PULLEY, COLLECTION 42 Price: $49.99 |
| 60 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
