| Ref | Part Number | Description |
|---|
| 1 |
304-46 |
DRAINCOCK Price: $7.55 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532172393. Price: $119.99 |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
119-2028 |
RADIATOR AND OIL COOLER ASM Price: $1,787.22 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
121-3556-0P |
SHROUD-FAN, UPPER This part replaces 121-3556-03. Price: $127.39 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
121-3552-0P |
SHROUD-FAN, LOWER This part replaces 121-3552-03. Price: $184.71 |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 10 |
120-3530-0P |
BRACKET-RADIATOR, BOTTOM This part replaces 120-3530-03. Price: $78.45 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
121-3557-0P |
BRACKET-RESEVOIR This part replaces 121-3557-03. Price: $26.66 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 17 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180641. Price: $59.99 |
| 20 |
95-8702-0P |
SHIELD-RADIATOR, LOWER This part replaces 95-8702-03. Price: $47.95 |
| 21 |
99-3497 |
MAGNET Price: $20.22 |
| 23 |
121-3558 |
HOSE-RADIATOR, UPPER Price: $46.41 |
| 24 |
121-3574 |
HOSE-RADIATOR, LOWER Price: $45.90 |
| 25 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 26 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 27 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 28 |
92-7536 |
HOSE-HYD Price: $196.76 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 33 |
99-7435 |
RELAY Price: $32.43 |
| 34 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
109-0274 |
HOSE-FUEL Price: $12.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
121-3609 |
TUBE-HYD Price: $143.00 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
819182411 |
Washer 9/16 ID x 1 1/2 OD 11 Ga. Zin Price: $4.99 |
| 40 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 41 |
93-6681 |
DECAL-WARNING, FAN Price: $11.51 |
| 42 |
32128-20 |
NUT-HF Price: $0.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
120-3529-03 |
BRACKET-RADIATOR, TOP Price: $62.39 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
120-3531-0P |
BRACKET-RADIATOR, LH This part replaces 120-3531-03. Price: $54.92 |
| 44 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180640. Price: $59.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 51 |
873540400 |
NUT.CROWNLOCK.1/4-28 Price: $4.99 |
| 54 |
871130420 |
Bolt Hex 1/4-28 unf x 1-1/4 Gr. 8 Price: $4.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
