| Ref | Part Number | Description |
|---|
| 1 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 2 |
2412-133 |
CLAMP-R Price: $3.19 |
| 3 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 3 |
77-3780 |
PIN ASM-LYNCH Price: $15.06 |
| 4 |
3290-282 |
RIVET-BLIND Price: $0.28 |
| 4 |
532169916 |
HANDLE.BAGGER.W/LVRS.BLK.CRD Price: $9.99 |
| 5 |
3256-49 |
WASHER-PLAIN Price: $0.33 |
| 5 |
874981024 |
SCREW.PAN.HEAD Price: $4.99 |
| 6 |
532750029 |
SCREW This part replaces 874981032. Price: $4.99 |
| 6 |
76-9930 |
FOAM-CENTER Price: $7.40 |
| 7 |
82-4900 |
FOAM-SEAT, REAR Price: $71.75 |
| 7 |
873401000 |
NUT Price: $6.99 |
| 8 |
532441543 |
COVER.PNT.BGR.CRD.WSLOTS.MS668 This part replaces 532181095. Price: $199.99 |
| 8 |
76-9440 |
ROD-PROP, SEAT Price: $65.18 |
| 9 |
32128-33 |
NUT-HF Price: $0.25 |
| 9 |
872140418 |
BOLT Price: $7.99 |
| 10 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 10 |
583110201 |
TUBE.SUPPORT.BAGGER.CRD This part replaces 532181282. Price: $59.99 |
| 11 |
218-461 |
NUT-HH Price: $2.50 |
| 11 |
532165719 |
BRACKET.SUPPORT.UPPER.BAG.CRD Price: $9.99 |
| 12 |
583173701 |
BRKT.PIVOT.LH.CRD This part replaces 532188848. Price: $7.99 |
| 12 |
92-2569 |
DISCONTINUED Price: Call Us |
| 13 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 13 |
874760612 |
BOLT Price: $3.99 |
| 14 |
43-8610 |
GUIDE Price: $23.35 |
| 14 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 15 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 15 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 16 |
237-30 |
O-RING Price: $2.50 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 17 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 18 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 19 |
237-7 |
O-RING Price: $8.82 |
| 19 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 20 |
237-136 |
GROMMET Price: $3.52 |
| 20 |
532188847 |
BRKT.PIVOT.RH.CRD Price: $7.99 |
| 21 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 21 |
532406180 |
BAGGER.ASM.CRD.2007 Price: $129.99 |
| 22 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 22 |
532428236 |
BRACKET.BAGGER.SD.ELECTRIC.CRD Price: $9.99 |
| 23 |
137-8085 |
SPRING-SEAT, COMPRESSION This part replaces 88-1420. Price: $8.86 |
| 24 |
532165783 |
TUBE.PIVOT.BAG.CRD.BLACK Price: $22.99 |
| 25 |
583211601 |
TUBE.FRONT.BAGGER.CRD This part replaces 532193705. Price: $84.99 |
| 26 |
321-4 |
SCREW-HH Price: $0.99 |
| 27 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 28 |
63-7590 |
RELAY Price: $78.15 |
| 29 |
2412-74 |
R-CLAMP Price: $2.37 |
| 30 |
37-2690 |
CAPACITOR Price: $155.98 |
| 31 |
116749 |
HORN This part replaces 48-4590. Price: $130.99 |
| 32 |
74-8910 |
DISCONTINUED Price: Call Us |
| 33 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 33 |
532428683 |
MULCHING.PLUG.107.CRD.(2 2) Price: $37.99 |
| 34 |
532165570 |
HANDLE.MULCHER.92.CRD (2 2) Price: $44.99 |
| 34 |
76-9480 |
SLEEVE-PIVOT, SEAT Price: $4.64 |
| 35 |
532165572 |
PIN Price: $12.99 |
| 36 |
325-9 |
SCREW-HH Price: $1.87 |
| 36 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 37 |
532175401 |
Plug Support Bagger CRD Price: Call Us |
| 37 |
76-9460-03 |
DISCONTINUED This part replaces 76-9460. Price: Call Us |
| 38 |
322-2 |
SCREW-HH Price: $0.69 |
| 38 |
872010520 |
BOLT.5/16-18X2.5 Price: $4.99 |
| 39 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 39 |
532416257 |
SEAL.BAGGER.CRD Price: $29.99 |
| 40 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 41 |
532169683 |
BRKT.VERT.ADJ.BAGGER.CRD Price: $4.99 |
| 41 |
80-7730 |
SPACER Price: $1.97 |
| 46 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 47 |
583211501 |
TUBE.UPPER.BAGGER.CRD This part replaces 532193704. Price: $279.99 |
| 49 |
583208201 |
BAR.SPREADER.BAGGER.CRD This part replaces 532193305. Price: $12.99 |
| 50 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 51 |
529846601 |
SERVICE KIT LATCH.SPRING.BAGGE This part replaces 532199903. Price: $1.99 |
| 53 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 54 |
872110407 |
BOLT.CARRIAGE.1/4-20 X 7/8 This part replaces 872140406. Price: $3.99 |
| 57 |
872110622 |
BOLT This part replaces 872140622. Price: $3.99 |
| 59 |
532430422 |
Price: Call Us |
| 60 |
532004929 |
RIVET TI Price: $5.99 |
| 61 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 62 |
532428239 |
Price: Call Us |
| 63 |
532428238 |
Price: Call Us |
| 64 |
532429664 |
Price: Call Us |
| 65 |
532429665 |
Price: Call Us |
| 66 |
532430424 |
Price: Call Us |
| 69 |
575180801 |
MEGA-FIRE ELECTR This part replaces 532435611. Price: $2.99 |
| 70 |
583506001 |
RIVET.POP.125X.750 This part replaces 532435603. Price: $3.99 |
