| Ref | Part Number | Description |
|---|
| 1 |
24-318-11 |
HEAD ASSEMBLY Price: Call Us |
| 1 |
24-782-05 |
MINIBLOCK Price: Call Us |
| 1 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 2 |
24-294-03 |
FITTING Price: Call Us |
| 2 |
24-755-76 |
KIT, VALVE COVER, BREATHER Price: Call Us |
| 2 |
98-4517 |
AIR CLEANER ASM Price: $272.15 |
| 3 |
24-067-05 |
CONNECTING ROD Price: Call Us |
| 3 |
25-313-02 |
GROMMET, RUBBER Price: Call Us |
| 3 |
93-6692 |
DISCONTINUED Price: Call Us |
| 3A |
24-067-06 |
CONNECTING ROD Price: Call Us |
| 4 |
12-380-03 |
PIN, DOWEL LOCATING Price: Call Us |
| 4 |
24-033-03 |
KIT, BREATHER COVER W/GASKET Price: Call Us |
| 4 |
48-7430 |
PRECLEANER Price: $50.85 |
| 5 |
24-041-23 |
GASKET, BREATHER Price: Call Us |
| 5 |
52-139-09 |
PLUG, CUP Price: Call Us |
| 5 |
98-4578-03 |
BRACKET-FILTER, FUEL Price: $35.38 |
| 6 |
24-096-15 |
COVER, BREATHER Price: Call Us |
| 6 |
24-874-01 |
PISTON WITH RING SET Price: Call Us |
| 6 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 6A |
24-874-02 |
PISTON WITH RING SET Price: Call Us |
| 6B |
24-874-03 |
PISTON WITH RING SET Price: Call Us |
| 7 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 7 |
24-108-01 |
RING SET Price: Call Us |
| 7 |
M-0645020 |
SCREW HEX FLANGE Price: Call Us |
| 7A |
24-108-02 |
RING SET Price: Call Us |
| 7B |
24-108-03 |
RING SET Price: Call Us |
| 8 |
24-018-01 |
RETAINER, PISTON PIN Price: Call Us |
| 8 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 9 |
12-422-10 |
SHIM, CAMSHAFT, YELLOW Price: Call Us |
| 9 |
32128-33 |
NUT-HF Price: $0.25 |
| 9 |
X-426-9 |
CLAMP, HOSE Price: Call Us |
| 9A |
12-422-09 |
SHIM, CAMSHAFT,RED Price: Call Us |
| 9B |
12-422-13 |
SHIM, CAMSHAFT, BLACK Price: Call Us |
| 9C |
12-422-07 |
SHIM, CAMSHAFT, WHITE Price: Call Us |
| 9D |
12-422-08 |
SHIM, CAMSHAFT, BLUE Price: Call Us |
| 9E |
12-422-11 |
SHIM, CAMSHAFT, GREEN Price: Call Us |
| 9F |
12-422-12 |
SHIM, CAMSHAFT, GREY Price: Call Us |
| 10 |
24-010-03 |
CAMSHAFT Price: Call Us |
| 10 |
24-326-14 |
HOSE, BREATHER Price: Call Us |
| 10 |
98-4525 |
BRACKET-CLEANER, AIR Price: $52.87 |
| 11 |
12-755-03 |
KIT, RETAINER Price: Call Us |
| 11 |
24-144-01 |
SHAFT, GOVERNOR CROSS Price: Call Us |
| 11 |
322-4 |
SCREW-HH Price: $0.35 |
| 12 |
12-173-01 |
CAP, VALVE SPRING Price: Call Us |
| 12 |
66-2750 |
DISCONTINUED Price: Call Us |
| 12 |
M-0631005 |
WASHER, PLAIN Price: Call Us |
| 13 |
104-0086 |
CABLE-BATTERY, POSITIVE Price: $78.07 |
| 13 |
12-032-01 |
SEAL ,GOVERNOR CROSS SHAFT Price: Call Us |
| 13 |
24-089-02 |
SPRING, VALVE Price: Call Us |
| 14 |
235011 |
RETAINER, SPRING Price: Call Us |
| 14 |
323-9 |
SCREW-HH Price: $1.29 |
| 14 |
X-25-102 |
WASHER Price: Call Us |
| 15 |
12-380-04 |
PIN Price: Call Us |
| 15 |
24-016-01 |
VALVE, EXHAUST, STANDARD SIZE Price: Call Us |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15A |
24-016-02 |
VALVE, EXHAUST, .25 OVERSIZE Price: Call Us |
| 16 |
24-017-01 |
VALVE, INTAKE, STANDARD SIZE Price: Call Us |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
M-0545010 |
SCREW, MOUNTING Price: Call Us |
| 16A |
24-017-02 |
VALVE, INTAKE, .25 OVERSIZE Price: Call Us |
| 17 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 17 |
24-018-04 |
RETAINER, REED Price: Call Us |
| 17 |
24-032-05 |
SEAL, VALVE STEM Price: Call Us |
| 18 |
24-294-06 |
FITTING Price: Call Us |
| 18 |
24-402-05 |
REED, BREATHER Price: Call Us |
| 18 |
94-7343 |
BASE-BATTERY Price: $118.61 |
| 19 |
24-032-01 |
SEAL, OIL, FRONT Price: Call Us |
| 19 |
24-326-13 |
HOSE, BREATHER Price: Call Us |
| 19 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 20 |
12-153-01 |
O-RING, LOWER OIL FILL TUBE Price: Call Us |
| 20 |
12-351-01 |
LIFTER, VALVE Price: Call Us |
| 20 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 21 |
12-123-04 |
TUBE, OIL FILL Price: Call Us |
| 21 |
24-411-05 |
ROD, PUSH Price: Call Us |
| 21 |
32128-20 |
NUT-HF Price: $0.99 |
| 22 |
24-041-08 |
GASKET, CYLINDER HEAD Price: Call Us |
| 22 |
24-126-19 |
BRACKET, OIL FILL TUBE Price: Call Us |
| 22 |
98-4576-03 |
BRACKET-RESERVOIR, WATER Price: $43.21 |
| 23 |
24-318-12 |
HEAD ASSEMBLY Price: Call Us |
| 23 |
321-5 |
SCREW-HH Price: $0.22 |
| 23 |
M-0545016 |
SCREW Price: Call Us |
| 24 |
12-153-02 |
O-RING, UPPER OIL FILL TUBE Price: Call Us |
| 24 |
24-755-66 |
KIT, VALVE TRAIN Price: Call Us |
| 24 |
93-9164 |
INDICATOR-MINI Price: $55.24 |
| 25 |
24-038-04 |
DIPSTICK ASSEMBLY Price: Call Us |
| 25 |
25-186-01 |
ARM, ROCKER Price: Call Us |
| 25 |
98-4518-03 |
BRACKET-CLEANER, AIR Price: $75.61 |
| 26 |
24-599-01 |
PIVOT, ROCKER ARM Price: Call Us |
| 26 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 27 |
94-1416 |
ADAPTER-INDICATOR Price: $11.87 |
| 27 |
M-0640034 |
SCREW, ROCKER ARM Price: Call Us |
| 28 |
24-755-74 |
KIT, VALVE COVER, PLAIN Price: Call Us |
| 28 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 29 |
24-153-12 |
O-RING Price: Call Us |
| 29 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 30 |
24-086-32 |
SCREW Price: Call Us |
| 30 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 31 |
12-086-16 |
SCREW Price: Call Us |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 32 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 33 |
24-755-57 |
KIT, BREATHER SEPARATOR Price: Call Us |
| 33 |
98-4509 |
HOSE-CLEANER, AIR Price: $97.00 |
| 34 |
24-112-12 |
SPACER Price: Call Us |
| 34 |
98-9305 |
WATER / FUEL FILTER ASM Price: $116.51 |
| 35 |
24-126-44 |
BRACKET, BREATHER SEPARATOR Price: Call Us |
| 35 |
353-783 |
FITTING-STR Price: $29.05 |
| 36 |
25-313-02 |
GROMMET, RUBBER Price: Call Us |
| 36 |
322-6 |
SCREW-HH Price: $0.45 |
| 37 |
24-445-02 |
STRAP, BREATHER SEPARATOR Price: Call Us |
| 37 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 38 |
110-4107 |
HOSE-FUEL This part replaces 95-4275. Price: $7.77 |
| 38 |
M-0545016 |
SCREW Price: Call Us |
| 39 |
2412-108 |
CLAMP-WORM Price: $1.29 |
