| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 1 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 2 |
104-9325 |
SPEEDOMETER KIT,RM5000 SERIES This part replaces 85-4420. Price: $449.92 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
3290-489 |
KNOB Price: $46.30 |
| 4 |
218-498 |
NUT-LOCK Price: $0.68 |
| 5 |
74-5950 |
LATCH-SWELL This part replaces 249-48. Price: $21.28 |
| 6 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
98-9308 |
GAUGE-TEMPERATURE This part replaces 63-7430. Price: $112.90 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 10 |
218-446 |
NUT-HEX Price: $6.09 |
| 11 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 12 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 13 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 14 |
75-0591 |
DISCONTINUED Price: Call Us |
| 15 |
75-6270-03 |
COVER-BOX, CONTROL This part replaces 75-6270. Price: $87.82 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 16 |
75-1010 |
SWITCH-REEL Price: $84.90 |
| 17 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 18 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 19 |
27-2360 |
SWITCH Price: $46.56 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 23 |
85-4450 |
BRKT-FUSE BLOCK Price: $29.51 |
| 24 |
75-5740-03 |
BOX-CONTROL ASM This part replaces 75-5740. Price: $261.87 |
| 25 |
85-4480 |
KNOB Price: $16.02 |
| 26 |
321-39 |
SCREW-HH Price: $0.42 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
75-4710 |
HARNESS- WARNING LIGHTS Price: $55.53 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 30 |
218-535 |
NUT-HEX Price: $0.34 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 33 |
321-15 |
SCREW-HH Price: $0.61 |
| 34 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 35 |
322-3 |
SCREW-HH Price: $0.79 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 37 |
98-2195 |
JOYSTICK This part replaces 75-3420. Price: $520.10 |
| 38 |
111332 |
SWITCH This part replaces 218-590. Price: $10.99 |
| 39 |
3290-93 |
SCREW-HEAD, PAN Price: $0.25 |
| 40 |
3290-488 |
DISCONTINUED Price: Call Us |
| 41 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 42 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 43 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 45 |
3273-26 |
SCREW-HSH Price: $0.41 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 46 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 47 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 50 |
85-4460 |
HOC SELECTOR DECAL Price: $7.84 |
| 53 |
2412-126 |
R-CLAMP This part replaces 2142-126. Price: $2.51 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 54 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 55 |
32128-33 |
NUT-HF Price: $0.25 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 56 |
92-8752 |
WIRE HARNESS ASSY Price: $1,303.23 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
