| Ref | Part Number | Description |
|---|
| 1 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 1 |
66-6370 |
LIFT ARM ASM Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
532142033 |
AXLE ASSY Price: $59.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 3 |
532135227 |
SPINDLE LH Price: $15.39 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
532135228 |
SPINDLE RH Price: $12.97 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 9 |
66-7150 |
ARM-PUSH, RH Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 10 |
532130468 |
LINK.DRAG.SOL.BALL JT.20.064 Price: $64.99 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
873610600 |
NUT Price: $2.99 |
| 12 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 14 |
46-8840-01 |
SPRING-LIFT ARM This part replaces 46-8840. Price: $35.71 |
| 14 |
874011056 |
Bolt Hex 5/8-11 Unc X 3-1/2 Price: $4.99 |
| 15 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 15 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 16 |
256-126 |
BUSHING Price: $9.36 |
| 16 |
532132624 |
AXLE PIN Price: $2.42 |
| 17 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 17 |
532156544 |
STEERING SHAFT This part replaces 532128762. Price: $64.99 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 18 |
93-7040-01 |
SUPPORT-REINFORCEMENT This part replaces 93-7040. Price: $85.37 |
| 19 |
324-4 |
SCREW-HH Price: $0.95 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 20 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 20 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 21 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 21 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 22 |
324-11 |
SCREW-HH Price: $3.05 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $3.99 |
| 23 |
21-3750 |
SUPPORT PLT Price: $14.42 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 24 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 24 |
532109816 |
NYLINER T (7283A) Price: $4.99 |
| 25 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 25 |
531152201 |
SERVICE KIT BRACKET BRKT This part replaces 532124036. Price: $12.99 |
| 26 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 27 |
32128-42 |
NUT-HF Price: $0.98 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 28 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 29 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 29 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 30 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 31 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 32 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $79.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 33 |
86-8100-01 |
BALL JOINT ASM This part replaces 86-8100. Price: $137.53 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 35 |
873610500 |
This part replaces 873810500. Price: $2.15 |
| 36 |
3-1365 |
CHAIN Price: $72.97 |
| 36 |
532145207 |
BUSHING STRG 3/4 Price: $4.99 |
| 37 |
68-3270 |
BUMPER-RUBBER Price: $37.99 |
| 37 |
817541008 |
SCREW Price: $3.99 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 38 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 39 |
5-2942 |
SHACKLE Price: $16.99 |
| 39 |
532100712 |
WASHER Price: $2.42 |
| 40 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 40 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 41 |
93-7650-01 |
LEVER-LOCKING This part replaces 93-7650. Price: $33.03 |
| 42 |
93-7644 |
PIN-HITCH, COTTERLESS Price: $9.14 |
| 43 |
28-8070 |
LANYARD Price: $13.85 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
