| Ref | Part Number | Description |
|---|
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532127428. Price: $142.99 |
| 2 |
532140551 |
Bracket Pivot Seat 8 720 Price: $3.99 |
| 3 |
874780616 |
Bolt Fin Hex 3/8-16 Unc x 1 Gr. 5 This part replaces 874760616. Price: $3.99 |
| 4 |
819131610 |
Washer 13/32 X 1 X 10 Ga Price: $3.99 |
| 5 |
532140407 |
Clip Push-In Price: $3.99 |
| 6 |
873680600 |
Nut Crownlock 3/8-16 Unc Price: $1.99 |
| 7 |
539110300 |
SRPING.SEAT This part replaces 532124181. Price: $2.99 |
| 8 |
817000616 |
Screw 3/8-16 x 1-1/2 Smgml Tap/R Z This part replaces 817490616. Price: $3.99 |
| 9 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131614. Price: $3.99 |
| 10 |
131-6557 |
ALTERNATOR ASM This part replaces 98-9474. Price: $443.05 |
| 10 |
532195530 |
PAN, SEAT This part replaces 532140552. Price: $14.99 |
| 12 |
532174648 |
Bracket Mounting Switch This part replaces 532121246. Price: $4.99 |
| 13 |
532121248 |
Bushing Snap Blk Nyl 50 ld Price: $3.99 |
| 14 |
872050411 |
Bolt Rdhd Sht Nk 1/4-20x1-3/8 Price: $2.99 |
| 15 |
532134300 |
Spacer Split 28x 96 Yel Zinc Price: $3.99 |
| 16 |
532121250 |
Spring Cprsn 1 27 Blk Pnt Price: $3.99 |
| 17 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 20 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 21 |
532139888 |
Bolt Shoulder 5/16-18 Unc Blkz Price: $2.99 |
| 22 |
873800500 |
Nut Hex Lock W/Ins 5/16-18 Price: $2.69 |
| 24 |
819171912 |
Washer 17/32 X 1-3/16 X 12 Ga. Price: $3.99 |
| 25 |
532127018 |
Bolt Shoulder 5/16-18 X 62 Price: $3.99 |
| 30 |
98-7708 |
NUT Price: $7.76 |
| 40 |
98-7709 |
COLLAR Price: $8.79 |
| 50 |
107-0136 |
ROTOR ASM Price: $268.62 |
| 60 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 70 |
107-0138 |
BEARING-BALL Price: $48.37 |
| 80 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 90 |
107-0139 |
DRIVE END FRAME ASM Price: $446.71 |
| 100 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 110 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 120 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 130 |
133-2811 |
BEARING This part replaces 107-0137. Price: $46.67 |
| 140 |
107-9087 |
FRAME-END Price: $183.56 |
| 150 |
107-0140 |
COVER-END Price: $34.95 |
| 160 |
98-7721 |
RECTIFIER ASM This part replaces 98-9476. Price: $486.45 |
| 170 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 180 |
107-0141 |
BRUSH HOLDER ASM Price: $107.10 |
| 190 |
98-7724 |
BRUSH Price: $12.41 |
| 200 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 210 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 220 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 230 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 240 |
98-7729 |
BOLT Price: $2.35 |
| 250 |
98-7730 |
NUT Price: $1.31 |
| 260 |
98-7731 |
BOLT Price: $3.94 |
| 270 |
98-7732 |
NUT Price: $1.45 |
