| Ref | Part Number | Description |
|---|
| B |
530024756 |
Decal- Fan Housing Price: $5.99 |
| 1 |
3211-18 |
Screw Price: Call Us |
| 2 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 2 |
530001626 |
Washer - Flywheel Price: $3.33 |
| 3 |
3-1305 |
DISCONTINUED Price: Call Us |
| 3 |
530023817 |
Spring- Starter Dog Price: $1.99 |
| 4 |
5-1724 |
DISCONTINUED Price: Call Us |
| 4 |
530015123 |
Washer - Starter Pulley Price: $1.99 |
| 5 |
3-1303 |
DISCONTINUED Price: Call Us |
| 5 |
530001726 |
Screw - 32 x 5/16- Hex Hd.-Disc Mounting (also Air Baffle & Clamp Head) Price: $1.99 |
| 6 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 6 |
530010674 |
Pulley - Starter Price: $3.33 |
| 7 |
3210-8 |
SCREW-HH Price: $1.02 |
| 7 |
530024329 |
Bushing Recoil Spring Price: $1.99 |
| 8 |
5-1765 |
DISCONTINUED Price: Call Us |
| 8 |
545008008 |
KIT STARTER SPRING This part replaces 530042051. Price: $9.99 |
| 9 |
3210-10 |
DISCONTINUED Price: Call Us |
| 9 |
530042053 |
Disc. Recoil Spring - Outer Price: $4.99 |
| 10 |
5-1771 |
DISCONTINUED Price: Call Us |
| 10 |
530015364 |
Screw - 10-24 x 1 Oval Hd. Fan Housing - (Top Front) Price: $1.99 |
| 11 |
5-1763 |
DISCONTINUED Price: Call Us |
| 11 |
530015365 |
Screw - 10-24 x 1-3/8 Fan Housing (Lower Front) Price: $1.99 |
| 12 |
5-1775 |
DISCONTINUED Price: Call Us |
| 13 |
5-1780 |
DISCONTINUED Price: Call Us |
| 14 |
5-1774 |
DISCONTINUED Price: Call Us |
| 15 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 15 |
530024232 |
Air Baffle Price: $5.99 |
| 16 |
5-0875 |
DISCONTINUED Price: Call Us |
| 16 |
530042054 |
Disc Recoil Spring - Inner Price: $11.99 |
| 17 |
3211-15 |
SCREW-HH Price: $7.99 |
| 17 |
530042056 |
Handle Starter Rope Price: $1.20 |
| 18 |
5-1826 |
DISCONTINUED Price: Call Us |
| 18 |
530042052 |
Rope Starter (Bulk 9128) Price: $3.33 |
| 19 |
5-1950 |
DISCONTINUED Price: Call Us |
| 19 |
530012034 |
Fan Housing Assembly Price: $3.28 |
| 20 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 20 |
530015366 |
Screw - 10-24 x 3-9/64 - Fan Housing (Rear) Price: $1.99 |
| 21 |
5-1777 |
DISCONTINUED Price: Call Us |
| 21 |
530024476 |
Spur Price: $11.99 |
| 22 |
3211-11 |
SCREW-HH Price: $2.24 |
| 22 |
530015434 |
Screw - 10-24 x 9/16 - Hex Hd. - Spur Price: $1.99 |
| 23 |
3211-23 |
Screw Price: Call Us |
| 24 |
5-1762 |
DISCONTINUED Price: Call Us |
| 24 |
530030039 |
Kit-Bar Stud Replmnt. (5/16") Price: $14.99 |
| 25 |
5-1760 |
DISCONTINUED Price: Call Us |
| 26 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 27 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 27 |
530032051 |
Bearing - Crankshaft Price: $3.08 |
| 28 |
5-1761 |
DISCONTINUED Price: Call Us |
| 28 |
530015354 |
Thrust Washer- Crankshaft Price: $3.99 |
| 29 |
3217-6 |
NUT-HEX Price: $1.19 |
| 30 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 30 |
530015425 |
Screw - 10-24 x 7/8 - Module Mnt. Price: $0.99 |
| 31 |
5-1773 |
DISCONTINUED Price: Call Us |
| 32 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 32 |
530024334 |
Clamp - High Tension Lead - Crankcase Price: $1.99 |
| 33 |
5-1776 |
DISCONTINUED Price: Call Us |
| 34 |
3219-2 |
NUT-HEX Price: $0.37 |
| 35 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 35 |
530023661 |
Clamp- Module Lead Price: $1.99 |
| 36 |
5-1772 |
DISCONTINUED Price: Call Us |
| 36 |
530015238 |
Screw - 10-24 x 11/16 - Fit. Hd. Crankcase Price: $1.99 |
| 37 |
5-1764 |
DISCONTINUED Price: Call Us |
| 38 |
3220-2 |
NUT-JAM Price: $0.50 |
| 39 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 40 |
5-1723 |
DISCONTINUED Price: Call Us |
| 41 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 41 |
530002582 |
Switch- Plate and Nut This part replaces 530023575. Price: $6.69 |
| 42 |
282-4 |
SHACKLE Price: $32.98 |
| 42 |
530024858 |
Plate - Ignition Switch Price: $3.33 |
| 43 |
3219-3 |
NUT-HEX Price: $0.34 |
| 43 |
530023732 |
Switch - Toggle Price: $3.33 |
| 44 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 44 |
530039099 |
Before Serial #35474495 Price: $3.33 |
| 44 |
530039115 |
Serial #35474496 Price: $3.33 |
| 45 |
3220-3 |
NUT-HJ Price: $0.28 |
| 45 |
530002595 |
Key - Flywheel Price: $1.99 |
| 46 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 47 |
3-3515 |
DISCONTINUED Price: Call Us |
| 47 |
530024756 |
Rings - Piston Price: $5.99 |
| 48 |
23-3860 |
DISCONTINUED This part replaces 3-8139. Price: Call Us |
| 48 |
530015368 |
Screw - 10-24 x 3/8-Fil. Hd. Choke Bracket Price: $3.33 |
| 49 |
5-1766 |
DISCONTINUED Price: Call Us |
| 49 |
530010347 |
Bracket & Bushing Assembly - Choke Price: $3.99 |
| 50 |
5-1738 |
DISCONTINUED Price: Call Us |
| 51 |
530015195 |
Clip - High Tension Lead Cylinder Price: $1.99 |
| 52 |
3295-6 |
DISCONTINUED Price: Call Us |
| 52 |
530001624 |
Cylinder Screw- 1/4-20 x 1/8 Price: $1.99 |
| 53 |
5-0842 |
Lining Price: Call Us |
| 54 |
3217-7 |
NUT-HEX Price: $0.28 |
| 54 |
530039096 |
High Tension Lead Price: $3.33 |
| 55 |
3-1310 |
DISCONTINUED Price: $2.00 |
| 55 |
530039071 |
Connector - Spark Plug Price: $0.40 |
| 56 |
323-8 |
SCREW-HH Price: $1.20 |
| 56 |
530039097 |
Boot- Spark Plug Price: $3.99 |
| 57 |
3-1311 |
DISCONTINUED Price: Call Us |
| 57 |
530030073 |
Spark Plug Price: Call Us |
| 58 |
3-4450 |
DISCONTINUED Price: Call Us |
| 58 |
530012069 |
Cylinder Price: $109.99 |
| 59 |
530024388 |
Back Plate - Muffler Price: $6.99 |
| 60 |
530024387 |
Muffler Body Price: $11.99 |
| 61 |
530015374 |
Screw - 1/4-24 x 1/2 - Hex Hd Muffler Body to Cylinder Price: $1.99 |
| 62 |
530024384 |
Diffuser - Muffler Price: $4.99 |
| 63 |
530024385 |
Screen - Spark Arrestor Price: $4.99 |
| 64 |
530024391 |
Muffler Cover Price: $4.99 |
| 65 |
530024392 |
Shield Muffler Price: $0.80 |
| 66 |
530015375 |
Screw - 1/4-20 x 2-1/2 - Hex Cap Muffler Cover Price: $1.99 |
