| Ref | Part Number | Description |
|---|
| 1 |
93-4032 |
SHAFT-JACK Price: $245.00 |
| 2 |
68-3220 |
KEY-STOCK Price: $4.60 |
| 3 |
79-2000 |
KEY-SQUARE This part replaces 13-6330. Price: $3.69 |
| 4 |
3243-6 |
SCREW-SET, SQH Price: $4.23 |
| 5 |
3218-3 |
NUT-JAM Price: $0.25 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
596321701 |
Screws Price: $2.99 |
| 8 |
13-6260 |
ADJUSTING SCREW ASM Price: $77.62 |
| 9 |
13-5520 |
SPACER-SCREW, ADJUSTING Price: $23.41 |
| 10 |
324-7 |
SCREW-HH Price: $1.79 |
| 11 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 12 |
32128-49 |
NUT-HHF Price: $1.04 |
| 12 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 13 |
325-20 |
SCREW-HH Price: $6.29 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL Price: $49.99 |
| 14 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 15 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
13-0100 |
PIVOT-LINK, RAKE LIFT Price: $61.98 |
| 17 |
3219-3 |
NUT-HEX Price: $0.34 |
| 18 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 19 |
1-633131 |
YOKE-LINKAGE, BRAKE This part replaces 282-22. Price: $14.99 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
108-0930 |
LIFTING BELL CRANK-RH This part replaces 93-4440. Price: $337.37 |
| 21 |
596040501 |
Hardware Price: $2.99 |
| 22 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 23 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
56-6210 |
BEARING Price: $90.04 |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
3217-8 |
NUT-HEX Price: $1.34 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
13-2680 |
BUSHING Price: $217.68 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 28 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 29 |
322-7 |
SCREW-HH Price: $0.89 |
| 29 |
595297001 |
Rods Price: $4.99 |
| 32 |
13-0600 |
IDLER ASM Price: $783.75 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 33 |
596134801 |
Nuts Price: $1.00 |
| 33 |
93-7706 |
TUBE-SPACER Price: $30.07 |
| 34 |
3218-5 |
NUT-JAM Price: $0.27 |
| 34 |
596136101 |
GSPW Bolts Price: $2.99 |
| 35 |
3244-21 |
SCREW-SQH Price: $10.59 |
| 36 |
250-5 |
TIE-CABLE Price: $5.19 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 37 |
3-5967-01 |
BATTERY SUPPORT This part replaces 3-5967. Price: $117.43 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 Price: $2.99 |
| 38 |
106-5190 |
BATTERY This part replaces 55-7290. Price: $170.85 |
| 38 |
589676103 |
KEEPER 42 MANDREL BELT FOR 6.2 This part replaces 589676102. Price: $6.99 |
| 39 |
3-3175-01 |
BATTERY COVER This part replaces 3-3175. Price: $292.58 |
| 40 |
119-6807 |
DECAL-WARNING This part replaces 61-5950. Price: $7.37 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
13-0480 |
SPRING Price: $30.51 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 42 |
13-3990-01 |
HANDLE-TRIP This part replaces 13-3990. Price: $189.07 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 43 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 44 |
108-0928 |
LIFTING BELL CRANK-LH This part replaces 13-5500. Price: $337.37 |
| 45 |
13-0050 |
SPRING-EXTENSION Price: $93.83 |
| 46 |
13-5530 |
ROD-ADJUST, SPRING Price: $67.42 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
13-6790 |
BATTERY CABLE Price: $115.82 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 48 |
3-8135 |
EXTENSION SPRING Price: $29.29 |
| 49 |
323-5 |
SCREW-HH Price: $0.41 |
| 50 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 51 |
5-0678 |
BATTERY CLAMP ROD Price: $35.64 |
| 52 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 53 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 54 |
3217-5 |
NUT-HEX Price: $0.25 |
| 55 |
13-4490-01 |
DISCONTINUED This part replaces 13-4490. Price: Call Us |
| 55 |
531171201 |
SERVICE KIT IDLER.ARM.42" This part replaces 532437110. Price: $5.99 |
| 56 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 58 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 60 |
324-10 |
SCREW-HH Price: $1.97 |
| 60 |
597074201 |
ARMS This part replaces 532197261. Price: $12.99 |
| 61 |
93-4409-01 |
TONGUE WA This part replaces 93-4409. Price: $481.19 |
| 62 |
327-6 |
SCREW-HH Price: $12.99 |
| 62 |
596136301 |
Bolts Price: $2.99 |
| 63 |
322-7 |
SCREW-HH Price: $0.89 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $14.99 |
| 64 |
13-2670-01 |
SHEAVE This part replaces 13-2670. Price: $1,182.76 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC Price: $11.99 |
| 65 |
63-5210-01 |
DRIVE SIDE SPDL WA This part replaces 63-5210. Price: $150.53 |
| 66 |
56-6230 |
BEARING-ROLLER Price: $72.34 |
| 67 |
140-2208 |
PULLEY-DRIVE This part replaces 93-4033. Price: $163.75 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
13-3710 |
WASHER Price: $3.05 |
| 69 |
321-4 |
SCREW-HH Price: $0.99 |
| 69 |
596136401 |
Bolts Price: $2.99 |
| 70 |
3290-211 |
WASHER-SPRING Price: $4.89 |
| 70 |
532199972 |
CLUTCH.ASM.MANUAL.YT.PREDATORQ Price: $49.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW Price: $9.99 |
| 119 |
596134901 |
GSPH Price: $2.99 |
| 144 |
531169801 |
SERVICE KIT BELT KEEPER This part replaces 532199204. Price: $4.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401971 |
RETURN SPRING Price: $4.99 |
| 189 |
596135701 |
GSPW Nuts Price: $2.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 254 |
585316805 |
PLATES.RENFRC.42DECK.PT431FRNT Price: $11.99 |
| 255 |
585317005 |
PLATES.RENFRCE.42DECK.X431SIDE Price: $11.99 |
| 256 |
592807801 |
BOLT CUP HEAD SQUARE NECK 1/4- Price: $2.99 |
| 257 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 532416405 |
COUPLING.QUICK |
CONNECT Price: $8.99 532416405 |
