| Ref | Part Number | Description |
|---|
| 1 |
3219-3 |
NUT-HEX Price: $0.34 |
| 2 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 2 |
463494 |
HOOD ASSY W/ DECALS, STTII-BV/CH This part replaces 463492. Price: Call Us |
| 3 |
04009-07 |
Bolt, Shoulder 5/16-18 x 1/2" Price: Call Us |
| 3 |
5-1468-01 |
PNEU. WHEEL HUB This part replaces 5-1468. Price: $101.29 |
| 4 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 4 |
424633 |
Latch, Hood Price: Call Us |
| 5 |
483507 |
Spring, Hood Latch Price: Call Us |
| 5 |
5-1470 |
SCREW-HH Price: $0.61 |
| 6 |
3217-6 |
NUT-HEX Price: $1.19 |
| 6 |
424634 |
Lock, Hood Latch Price: Call Us |
| 7 |
04040-05 |
Flatwasher, 3/8 (.406 x .812 x .065) Price: Call Us |
| 7 |
12-9460 |
DISC HALF Price: $73.84 |
| 8 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" (Kohler EFI) Price: Call Us |
| 8 |
12-9390 |
TIRE (16X4-12) 4 PLY SEMI-PNEUMATIC Price: $77.30 |
| 9 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 9 |
322-2 |
SCREW-HH Price: $0.69 |
| 10 |
429112 |
Guard, Muffler Price: Call Us |
| 11 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 12 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 14 |
483471 |
Disc, Anti-Friction Price: Call Us |
| 15 |
43740 |
Spacer, Hood Price: Call Us |
| 16 |
04041-11 |
Flatwasher, 3/8-.406 x 1-1-1/2 x 7 Gauge Price: Call Us |
| 17 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 18 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 19 |
483017 |
Oil Drain, 35BV & 37BV-EFI - Briggs & Stratton Price: Call Us |
| 20 |
453380 |
Plate Weldment, Engine Mounting Price: Call Us |
| 21 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 22 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 23 |
04001-17 |
Bolt, Hex Head 5/16-18 x 2-1/2" (x3) (35BV & 37BV-EFI) Price: Call Us |
| 24 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 25 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 26 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 27 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 28 |
427071 |
Cover, Rear Price: Call Us |
| 29 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 30 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 31 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 32 |
427301 |
Guard, Fuel Pump Price: Call Us |
