| Ref | Part Number | Description |
|---|
| 1 |
60-6190 |
O-RING Price: $3.76 |
| 2 |
530016153 |
Screw Price: $1.99 |
| 2 |
95-6050 |
PIN-DOWEL Price: $2.59 |
| 3 |
530059006 |
Reflector-Tape Price: $1.99 |
| 3 |
60-6250 |
WASHER Price: $9.70 |
| 4 |
530039198 |
Module - Ignition Price: $29.99 |
| 4 |
76-7010 |
RING-RETAINING This part replaces 60-6260. Price: $3.66 |
| 5 |
530016432 |
Screw Price: $1.99 |
| 5 |
60-6270 |
RING Price: $2.40 |
| 6 |
530047442 |
Strap-Ground Price: $1.99 |
| 6 |
60-6330 |
SCREW Price: $6.91 |
| 7 |
530057943 |
Assy-Wire Harness Price: $5.99 |
| 8 |
530058687 |
Cover-Air Filter Price: $4.99 |
| 9 |
530057925 |
Filter-Air Price: $0.99 |
| 10 |
530016425 |
Screw Price: $1.99 |
| 10 |
60-6120 |
COVER-SEAL Price: $17.87 |
| 11 |
530057892 |
Housing-Air Filter Price: $4.99 |
| 11 |
60-6010 |
COVER-TRUNNION Price: $11.26 |
| 12 |
545070601 |
Carb-Zama W-26B This part replaces 530035590. Price: $27.99 |
| 12 |
99-8702 |
O-RING COVER Price: $64.56 |
| 13 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 13 |
60-5990 |
RACE Price: $51.48 |
| 14 |
530047721 |
Bulb-Purge "snap-in" Price: $3.99 |
| 14 |
60-6110 |
BEARING Price: $47.19 |
| 15 |
60-6130 |
GASKET Price: $19.03 |
| 16 |
530071894 |
Gasket-cyl. o-ring (kit) Price: $6.99 |
| 16 |
76-6950 |
RACE-THRUST This part replaces 60-6160. Price: $25.65 |
| 17 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.69 |
| 17 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 18 |
60-6230 |
SCREW-HH Price: $4.80 |
| 19 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 19 |
60-6220 |
SCREW-HH Price: $5.33 |
| 20 |
105-3331 |
SEAL-SHAFT This part replaces 60-6300. Price: $35.63 |
| 21 |
104-4861 |
SEAL-SHAFT This part replaces 42-2720. Price: $28.44 |
| 21 |
530057942 |
Backplate-Muffler Price: $5.99 |
| 22 |
530071894 |
Gasket-Muffler (kit) Price: $6.99 |
| 22 |
68-6460 |
RELIEF VALVE KIT Price: $545.19 |
| 23 |
530071886 |
Kit-Spark Arrestor Price: $9.99 |
| 23 |
99-8703 |
HOUSING ASM Price: $819.08 |
| 24 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 25 |
545015301 |
Insert-Left (black) Cyl. This part replaces 530057885. Price: $2.99 |
| 25 |
99-8705 |
BACKPLATE ASM Price: $1,560.57 |
| 26 |
545112901 |
Assy-Crankshaft/Rod This part replaces 530012537. Price: $46.99 |
| 26 |
99-8704 |
PLATE-VALVE Price: $457.47 |
| 27 |
530016417 |
Bolt Price: $1.99 |
| 27 |
60-6140 |
SHAFT Price: $420.62 |
| 28 |
530057941 |
Cap-Crankcase Price: $5.99 |
| 28 |
60-6020 |
CAMPLATE Price: $784.96 |
| 29 |
530056363 |
Assy-Bearing/Seal Price: $11.99 |
| 29 |
60-6200 |
ADAPTER Price: $537.89 |
| 30 |
99-8706 |
GEROTOR-INNER Price: $153.64 |
| 31 |
107-4445 |
DISCONTINUED This part replaces 99-8707. Price: $568.49 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 32 |
60-6280 |
PLUG Price: $24.83 |
| 33 |
545015401 |
Insert-Right (gray) Cyl. This part replaces 530057886. Price: $2.99 |
| 34 |
530071894 |
Seal-Adaptor (kit) Price: $6.99 |
| 34 |
60-6320 |
KEY Price: $5.45 |
| 35 |
530016426 |
Screw Price: $1.99 |
| 35 |
99-8708 |
O-RING Price: $21.71 |
| 36 |
530071894 |
Gasket-Carb. (kit) Price: $6.99 |
| 36 |
60-6240 |
WASHER Price: $15.20 |
| 37 |
530057926 |
Tube-Intake Price: $1.99 |
| 37 |
60-6310 |
KEY Price: $8.97 |
| 38 |
3256-73 |
WASHER-FLAT Price: $1.31 |
| 38 |
530057909 |
Wire-Throttle Price: $1.99 |
| 39 |
530016101 |
Nut-Carb. Price: $1.99 |
| 39 |
95-6056 |
SEAL KIT Price: $111.09 |
| 41 |
530031163 |
Wrench-Bar Price: $4.99 |
