| Ref | Part Number | Description |
|---|
| 1 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 1 |
530035017 |
Screw - Pump Cover Price: $0.99 |
| 2 |
32140-32 |
SCREW-HH Price: $1.19 |
| 2 |
530035154 |
Pump Cover Ass'y (Inc. # 4) WA-79 Price: $3.33 |
| 2 |
530035191 |
Pump Cover Ass'y (Inc. # 4) WA-149 Price: $3.99 |
| 3 |
38-1950 |
PIVOT SHAFT WA Price: $177.36 |
| 3 |
530035135 |
Diaphragm - Pump (WA-79) Price: $3.33 |
| 4 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 4 |
530035156 |
Screw - Idle Adjustment Price: $1.99 |
| 5 |
3210-3 |
SCREW-HH Price: $5.29 |
| 5 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 5 |
530035009 |
Gasket - Pump WA-79 Price: $1.99 |
| 6 |
3220-1 |
NUT-JAM Price: $0.99 |
| 6 |
530035178 |
Screen - Inlet Price: $1.99 |
| 7 |
329-4 |
SCREW-HH Price: $0.79 |
| 7 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 7 |
530035152 |
Diaphragm - Pump WA-79 Price: $5.99 |
| 8 |
18-1720 |
BALL JOINT Price: $50.30 |
| 8 |
530035133 |
Valve - Throttle Price: $3.33 |
| 9 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 9 |
530035007 |
Clip - Throttle Shaft Price: Call Us |
| 10 |
38-1970 |
PIVOT ARM WA Price: $255.60 |
| 10 |
530035138 |
Spring - Throttle Return Price: Call Us |
| 11 |
3219-1 |
NUT-HEX Price: $0.47 |
| 11 |
530035015 |
Screw - Throttle Valve Price: $1.99 |
| 12 |
19-3400 |
DISCONTINUED Price: Call Us |
| 12 |
530035132 |
Shaft Assembly - Throttle Price: Call Us |
| 13 |
19-3430 |
DISCONTINUED Price: Call Us |
| 13 |
530035023 |
Spring - Idle Needle Price: $0.99 |
| 14 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 14 |
530035141 |
Needle - Idle Price: $2.99 |
| 15 |
256-244 |
BUSHING Price: $5.77 |
| 15 |
530035188 |
WT-141 - T1 This part replaces 530035139. Price: $1.99 |
| 16 |
19-3850 |
DISCONTINUED Price: Call Us |
| 16 |
530035008 |
Valve - Inlet Needle Price: $3.33 |
| 17 |
505520127 |
Metering Lever This part replaces 530035031. Price: $3.99 |
| 18 |
530035036 |
Spring - Hi Speed Needle Price: Call Us |
| 19 |
501782201 |
H-NEEDLE This part replaces 530035142. Price: $6.30 |
| 20 |
505520125 |
Pin This part replaces 530035028. Price: $1.99 |
| 21 |
530035016 |
Screw - Metering Lever Pin Price: $2.99 |
| 22 |
501781301 |
GASKET This part replaces 530035147. Price: $0.45 |
| 23 |
530035042 |
Plate - Circuit Price: $3.33 |
| 24 |
530035137 |
Screw - Circuit Plate Price: $3.33 |
| 25 |
530035151 |
Gasket - Metering Diaphragm Price: $1.99 |
| 26 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 27 |
530035153 |
Screw - Assembly - Metering Cover & Throttle Shaft Clip Price: $3.33 |
| 28 |
530035149 |
Cover - Metering Diaphragm Price: $3.33 |
| 30 |
530035145 |
Kit - Carb. Gasket/Diaphragm WA-79 Price: $14.99 |
