| Ref | Part Number | Description |
|---|
| 1 |
731-11421 |
Cleanout Tool Mount This part replaces 731-2635. Price: $9.83 |
| 2 |
931-2643 |
Chute Cleanout Tool This part replaces 731-2643. Price: $16.68 |
| 4 |
736-0188 |
Fl-Wash. .76 I.D x 1.49 O.D. Price: $3.75 |
| 6 |
741-0493C |
FLANGE BUSHING This part replaces 741-0493A. Price: $3.86 |
| 7 |
941-0245 |
Hex Flange Bearing, .75 ID This part replaces 741-0245. Price: $9.07 |
| 8 |
784-5618A-0637 |
Hex Bearing Housing, 1.0 This part replaces 784-0399. Price: $11.45 |
| 9 |
712-0429 |
Lock Nut 5/16-18 Thd. Price: $3.56 |
| 10 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 11 |
736-0242 |
Bell Washer Price: $3.75 |
| 12 |
05931A |
Housing Price: $9.73 |
| 14 |
705-5226 |
Reinforcement Chute Price: $8.69 |
| 15 |
710-0451 |
Carriage Bolt 5/16-18 x .75 Price: $3.53 |
| 16 |
710-0459A |
Hex Cap Screw 3/8-24 x 1.50 Price: $6.50 |
| 17 |
710-0604A |
Hex Wash. TT Screw 5/16-18 Price: $3.96 |
| 18 |
710-0703 |
Carriage Screw 1/4-20 x .75 Price: $3.66 |
| 19 |
710-0890A |
Shear Bolt 5/16-18 x 1.5 Price: $1.58 |
| 20 |
712-0116 |
Lock Jam 3/8-24 Price: $3.95 |
| 21 |
712-0324 |
Hex Lock Nut 1/4-20 Price: $3.38 |
| 22 |
712-0798 |
Hex Nut 3/8-16 Price: $3.86 |
| 23 |
712-3009 |
Hex Lock Nut, 5/16-18 This part replaces 712-3068. Price: $5.99 |
| 24 |
715-0114 |
Pin Price: $8.68 |
| 25 |
731-1379D |
Adapter Chute This part replaces 731-1379C. Price: $57.72 |
| 26 |
932-0611 |
Extension Spring, .38 OD x 3.6 This part replaces 732-0611. Price: $6.92 |
| 27 |
936-0119 |
LOCK WASHER 5/16 This part replaces 736-0119. Price: $4.29 |
| 28 |
936-0167 |
FLAT WASHER This part replaces 736-0167. Price: $6.01 |
| 29 |
736-0463 |
FL-Wash .25 x .63 x .05 Price: $3.91 |
| 30 |
738-0281 |
Shld. Screw Price: $9.16 |
| 31 |
941-0309 |
Flange Ball Bearing, .75 x 1.85 This part replaces 741-0309. Price: $69.59 |
| 32 |
756-0178 |
Flat Idler Price: $17.64 |
| 33 |
984-0064-0637 |
Auger Idler Brkt. This part replaces 784-5632B. Price: $28.67 |
| 34 |
736-0320 |
Fl.-Wash. .38 I.D. x 1.38 O.D. Price: $6.01 |
| 35 |
784-5038B-0637 |
Slide Shoe This part replaces 784-5038B. Price: $24.49 |
| 36 |
710-0276 |
Carriage Screw 5/16-18 Price: $3.68 |
| 37 |
784-5647-0637 |
Chute Crank Bracket This part replaces 784-5647. Price: $12.51 |
| 38 |
684-04182-0637 |
Spiral Assembly: RH 26" This part replaces 605-5192A. Price: $165.01 |
| 39 |
790-00121-0637 |
Shave Plate, 26" This part replaces 784-5579A. Price: $33.66 |
| 40 |
946-0897 |
Auger Cable This part replaces 746-0897. Price: $23.09 |
| 41 |
736-0169 |
L-Wash. 3/8 Price: $3.33 |
