| Ref | Part Number | Description |
|---|
| 1 |
532423469 |
WHEEL STEERING Price: $32.99 |
| 3 |
132-3468 |
DUCT-A/C Price: $1,135.16 |
| 4 |
132-3488 |
PANEL-FAN Price: $664.03 |
| 6 |
132-3531-03 |
SEAL-FRONT Price: $33.28 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
132-3532-03 |
SEAL-REAR Price: $27.57 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
132-3533-03 |
SEAL-SIDE, LEFT Price: $25.48 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
132-3534-03 |
SEAL-SIDE, RIGHT Price: $31.14 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
104-7201 |
NUT-HF Price: $0.69 |
| 11 |
121-8457 |
FILTER-AIR Price: $34.12 |
| 12 |
107069 |
CLIP Price: $1.79 |
| 13 |
126-5846 |
KNOB-T Price: $9.75 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
125-9825-03 |
COVER-AIR, FRESH Price: $80.77 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3230-9 |
SCREW-CARR Price: $0.68 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 18 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 19 |
32115-15 |
PUSHNUT-RETAINER, BOLT This part replaces 106-8737. Price: $0.99 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
130-5871 |
BRACKET-WIPER Price: $42.69 |
| 21 |
125-7452 |
WIPER MOTOR ASM Price: $435.07 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
125-7453 |
ARM-WIPER Price: $121.52 |
| 23 |
125-7454 |
BLADE-WIPER Price: $49.61 |
| 24 |
120-4654 |
SCREW-HHF Price: $0.34 |
| 25 |
32105-15 |
SCREW-HWH Price: $1.79 |
| 26 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 28 |
117-5976 |
KNOB-HANDLE Price: $2.17 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
130-5661 |
TUBE-SLEEVE Price: $37.14 |
| 30 |
3229-30 |
SCREW-CARR Price: $1.39 |
| 31 |
130-5854 |
BRACE-SEAL Price: $4.07 |
| 32 |
363-8245 |
SCREW-TAP Price: $0.66 |
| 33 |
132-3608 |
SEAL-EDGE Price: $2.50 |
| 34 |
132-3609 |
SEAL-STRIP Price: $4.11 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
