| Ref | Part Number | Description |
|---|
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 2 |
401140 |
Drawbar Price: Call Us |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
195102X428 |
Dash Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
175260X505 |
Hood Price: Call Us |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
17060612 |
Screw 3/8-16 x .75 Price: Call Us |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 18 |
175289X428 |
Grille Price: Call Us |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 36 |
17060512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 37 |
400009X505 |
Fender Price: Call Us |
| 58 |
194314 |
Bracket Fender Price: Call Us |
| 68 |
17490508 |
Screw Thdrol 5/16-18 x 1/2 Price: Call Us |
| 99 |
401996 |
Rod Bypass Asm. Price: Call Us |
| 102 |
4497H |
Retainer Spring 1" Price: Call Us |
| 122 |
192512 |
Screw WSHD Hex 10-32 x 5/8 Price: Call Us |
| 130 |
191611 |
Screw 10 x 3/4 Single Lead-Hex Price: Call Us |
| 139 |
171873 |
Bolt Shoulder 5/16-18 Price: Call Us |
| 148 |
164655 |
Bumper Price: Call Us |
| 150 |
175352 |
Duct Heat Hood Price: Call Us |
| 152 |
194329 |
Shield Browning/Debris Price: Call Us |
| 157 |
161840 |
Lens Bar Price: Call Us |
| 159 |
17000612 |
Screw Hexwsh Thdrol 3/8-16 x 3/4 Price: Call Us |
| 161 |
193097X428 |
Console Fuel Window Price: Call Us |
| 162 |
142432 |
Screw Hex Wsh Hi-Lo 1/4 x 1/2 Price: Call Us |
| 165 |
194330 |
Bracket Support Tank Price: Call Us |
| 175 |
193236 |
Crossmember Price: Call Us |
| 176 |
400776 |
Screw #10-24 x 5/8 Rnd Qudrx Price: Call Us |
| 177 |
195227 |
Bushing Steering Price: Call Us |
| 178 |
195651 |
Cargo Asm. Net Price: Call Us |
| 180 |
194260 |
Chassis Price: Call Us |
| 181 |
193102X428 |
Bushing Mtg. Fender Crgo. Price: Call Us |
| 182 |
192551 |
Dash Lower Price: Call Us |
| 183 |
74780520 |
Bolt Fin Hex 5/16-18 unc x 1-1/4 Price: Call Us |
| 184 |
195780 |
Spacer Fender Price: Call Us |
| 188 |
194316 |
Bracket Pickoff Hood Price: Call Us |
| 194 |
73900500 |
Nut Lock Hex Flange 5/16-18 Price: Call Us |
| 196 |
193098X428 |
Console Asm. Deck Lift Price: Call Us |
| 198 |
197300X505 |
Indicator Deck Lift Price: Call Us |
| 199 |
196377 |
Plate Deck Lift Price: Call Us |
| 205 |
169847X428 |
Skirt Hood RH Price: Call Us |
| 206 |
169848X428 |
Skirt Hood LH Price: Call Us |
| 219 |
195161 |
Stud Fastener Price: Call Us |
