| Ref | Part Number | Description |
|---|
| 1 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 2 |
149723 |
Muffler Side Price: Call Us |
| 2 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 3 |
353-781 |
FITTING-HYD, 90 Price: $24.44 |
| 4 |
32128-20 |
NUT-HF Price: $0.99 |
| 5 |
321-4 |
SCREW-HH Price: $0.99 |
| 6 |
98-7612 |
FILTER-FUEL Price: $10.48 |
| 7 |
32128-33 |
NUT-HF Price: $0.25 |
| 8 |
121361X |
Pulley V-Idler Price: Call Us |
| 8 |
353-783 |
FITTING-STR Price: $29.05 |
| 9 |
177748 |
Keeper Asm. Belt Engine VGT Price: Call Us |
| 9 |
98-9305 |
WATER / FUEL FILTER ASM Price: $116.51 |
| 10 |
175287 |
Bushing Price: Call Us |
| 11 |
104-5215 |
PUMP-FUEL, ELECTRIC Price: $264.12 |
| 11 |
179335 |
Clutch Electric Price: Call Us |
| 12 |
143996 |
Pulley Engine VGT Elect Clutch Price: Call Us |
| 12 |
66-8800 |
RELAY Price: $87.56 |
| 13 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 14 |
110-3259 |
HOSE-FUEL This part replaces 99-9681. Price: $33.03 |
| 15 |
109-0274 |
HOSE-FUEL This part replaces 63-9640. Price: $12.99 |
| 15 |
179115 |
Tank Fuel Rear 5.0 Price: Call Us |
| 16 |
115-0608-03 |
BRACKET-PUMP, FUEL This part replaces 105-2561-03. Price: $57.99 |
| 18 |
179124X428 |
Cap Asm. Fuel Price: Call Us |
| 18 |
2412-147 |
CLAMP-R Price: $2.51 |
| 20 |
175437X428 |
Control Throttle Price: Call Us |
| 21 |
171875 |
Screw Hw Hd Hi-Lo #13-16 x 3/4 Price: Call Us |
| 22 |
175440X428 |
Control Choke Price: Call Us |
| 24 |
11050600 |
Washer Ext Tooth 3/8 Price: Call Us |
| 25 |
73920600 |
Nut Keps 3/8-24 Unf Price: Call Us |
| 26 |
3645J |
Bushing Price: Call Us |
| 27 |
139277 |
Stem Tank Fuel Price: Call Us |
| 28 |
7834R |
Fuel Line Price: Call Us |
| 29 |
137180 |
Spark Arrester Kit Price: Call Us |
| 31 |
145006 |
Clip Price: Call Us |
| 37 |
123487X |
Clamp Hose Price: Call Us |
| 39 |
17490636 |
Screw TT 3/8-16 x 2-1/4 UNC Price: Call Us |
| 40 |
17490664 |
Screw TT 3/8-16 x 4 UNC Price: Call Us |
| 41 |
126197X |
Washer 1-1/2 OD X 15/32 ID X .250 Price: Call Us |
| 42 |
10040700 |
Washer Lock 7/16 Price: Call Us |
| 43 |
179953 |
Bolt Hex 7/16-20 x 3.75 Gr. 5 Price: Call Us |
| 45 |
73510400 |
Nut Keps Hex 1/4-20 Price: Call Us |
| 47 |
175288 |
Spacer Price: Call Us |
| 62 |
146629 |
Shield Heat Muffler CV-Intek Price: Call Us |
| 69 |
165391 |
Gasket Price: Call Us |
| 70 |
176069 |
Tube Exhaust LH Price: Call Us |
| 71 |
176070 |
Tube Exhaust RH Price: Call Us |
| 74 |
162295 |
Elbow Street Brass Price: Call Us |
| 79 |
183906 |
Screw Socket Head 5/16-18 x 1 Price: Call Us |
| 81 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 82 |
181654 |
Plug Oil Drain Easy Price: Call Us |
| 83 |
171877 |
Bolt 5/16-18unc X 1-3/4 W/Sems Price: Call Us |
