| Ref | Part Number | Description |
| 1 |
532404349 |
KIT.BOX.BATTERY.REAR.BOOT.POS This part replaces 532129965. Price: $24.99 |
| 2 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 3 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 4 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 5 |
532127115 |
PLATE This part replaces 532125142. Price: $5.78 |
| 6 |
532109596 |
HOSE CLAMP T Price: $3.99 |
| 7 |
532126700 |
FOOTREST PAD Price: $30.08 |
| 8 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 9 |
532140919 |
CONSOLE SHIFT CTL Price: $12.77 |
| 11 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 12 |
532140784 |
FRAME ASSY NLA Price: $101.93 |
| 13 |
532109238 |
TUBE BATTERY DRAIN Price: $5.46 |
| 14 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 15 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 16 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 17 |
532140782 |
DRAWBAR Price: $26.91 |
| 18 |
532126470 |
CLIP,INSULATOR Price: $3.99 |
| 19 |
532140956 |
FENDER This part replaces 532141366. Price: $108.31 |
| 20 |
596135301 |
Washers This part replaces 819091413. Price: $2.99 |
| 21 |
532140297 |
BRACKET DEPTH Price: $2.70 |
| 22 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 23 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 25 |
593337201 |
SCREW HEXAGON HEAD WITH COLLAR This part replaces 817490516. Price: $2.99 |
| 30 |
532124238 |
CAP SPRING Price: $4.99 |
