| Ref | Part Number | Description |
|---|
| 1 |
532404349 |
KIT.BOX.BATTERY.REAR.BOOT.POS This part replaces 532156417. Price: $24.99 |
| 2 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 3 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 5 |
532127115 |
PLATE This part replaces 532125142. Price: $5.78 |
| 6 |
532109596 |
HOSE CLAMP T Price: $3.99 |
| 7 |
532124144 |
PAD FOOTREST Price: $2.96 |
| 8 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 9 |
532126996 |
CONSOLE SHT CONTR Price: $6.38 |
| 10 |
115-3018 |
NOZZLE HOLDER KIT Price: $440.14 |
| 10 |
532139783 |
BAR, SHIFT LOCK Price: $3.99 |
| 11 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 12 |
532145190 |
FRAME Price: $89.40 |
| 13 |
532109238 |
TUBE BATTERY DRAIN Price: $5.46 |
| 15 |
873640400 |
Nut, Keps Blk Hex 1/4-20 UNC Price: $2.99 |
| 16 |
532146613 |
KIT/CLUTCH BRAKE ACTUATOR This part replaces 532141736. Price: $6.80 |
| 17 |
532140782 |
DRAWBAR Price: $26.91 |
| 18 |
532126470 |
CLIP,INSULATOR Price: $3.99 |
| 19 |
532141393 |
FENDER/FOOTREST Price: $106.71 |
| 20 |
596135301 |
Washers This part replaces 819091413. Price: $2.99 |
| 20 |
99-8301 |
NUT Price: $8.64 |
| 25 |
817190516 |
Screw Hex Wsh Thdroll 5/16-18 x 1 Price: $2.42 |
| 30 |
99-8302 |
WASHER-ADJUSTING Price: $7.16 |
| 40 |
99-8303 |
SPRING-NOZZLE Price: $11.49 |
| 50 |
99-8304 |
SPACER-DISTANCE Price: $29.26 |
| 60 |
99-8305 |
ROD-PUSH Price: $60.67 |
| 70 |
99-8306 |
NUT-NOZZLE Price: $34.65 |
| 80 |
99-8307 |
WASHER-PLAIN Price: $8.84 |
| 90 |
115-3020 |
PIECE-NOZZLE Price: $150.73 |
| 100 |
99-8309 |
ADJUSTING WASHER ASM Price: $56.19 |
| 110 |
99-8310 |
WASHER-ADJUST (0.10MM) Price: $2.74 |
| 110 |
99-8311 |
WASHER-ADJUST (0.20MM) Price: $3.56 |
| 110 |
99-8312 |
WASHER-ADJUST (0.30MM) Price: $2.74 |
| 110 |
99-8313 |
WASHER-ADJUST (0.40MM) Price: $2.74 |
| 110 |
99-8314 |
WASHER-ADJUST (0.50MM) Price: $1.91 |
| 110 |
99-8315 |
WASHER-ADJUST (0.52MM) Price: $1.91 |
| 110 |
99-8316 |
WASHER-ADJUST (0.54MM) Price: $1.91 |
| 110 |
99-8317 |
WASHER-ADJUST (0.56MM) Price: $1.91 |
| 110 |
99-8318 |
WASHER-ADJUST (0.58MM) Price: $1.91 |
| 110 |
99-8319 |
WASHER-ADJUST (0.80MM) Price: $1.91 |
| 120 |
98-7676 |
GASKET Price: $2.73 |
