| Ref | Part Number | Description |
|---|
| 1 |
539130394 |
FUEL CAP, GENERIC This part replaces 539104962. Price: $27.99 |
| 1 |
94-1259 |
GEAR CASE ASM This part replaces 75-4920. Price: $982.40 |
| 2 |
539104410 |
FUEL TANK RT Price: $279.99 |
| 2 |
67-2580 |
CASE GASKET Price: $29.62 |
| 3 |
539102502 |
STUD, 5/16C Price: $8.99 |
| 3 |
67-2340 |
BOLT W/WASHER Price: $2.19 |
| 4 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 4 |
67-2310 |
PLATE Price: $88.82 |
| 5 |
539102845 |
SPRING Price: $2.99 |
| 5 |
67-2320 |
PLATE GASKET Price: $27.26 |
| 6 |
42-9440 |
BOLT/WASHER Price: $4.52 |
| 6 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 7 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 7 |
67-2560 |
BOLT W/WASHER Price: $1.89 |
| 8 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 8 |
67-2550 |
OIL PUMP HOUSING Price: $158.75 |
| 9 |
539102650 |
HOSE BARB 90 DEGREE Price: $4.99 |
| 9 |
67-2540 |
DISCONTINUED Price: Call Us |
| 10 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 10 |
67-2530 |
DISCONTINUED Price: Call Us |
| 11 |
539115707 |
HOSE 1/4 X 21.5" This part replaces 539102680. Price: $6.99 |
| 11 |
67-2470 |
DISCONTINUED Price: Call Us |
| 12 |
42-9260 |
DRAIN PLUG Price: $29.62 |
| 12 |
539102681 |
FUEL LINE, ENGINE Price: $11.91 |
| 13 |
42-7290 |
GASKET-PLUG Price: $7.56 |
| 13 |
539102679 |
FUEL VALVE Price: $49.99 |
| 14 |
539102070 |
KNOB, THREE PRONG Price: $4.99 |
| 14 |
67-2480 |
OIL PAN GASKET Price: $25.87 |
| 15 |
42-9490 |
SCREW - CAP Price: $0.30 |
| 15 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 16 |
539977778 |
ANTI-SKID PAD Price: $3.99 |
| 16 |
67-2390 |
PLUG This part replaces 42-7210. Price: $5.06 |
| 17 |
539103242 |
FOOT PLATE RED WSL This part replaces 539104590. Price: $67.99 |
| 17 |
67-2630 |
O-RING Price: $3.84 |
| 18 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 18 |
67-2600 |
BOLT Price: $2.41 |
| 19 |
539102593 |
WASHER, 3/8 DISC SPRING SPEC Price: $2.99 |
| 19 |
67-2610 |
BOLT Price: $3.64 |
| 20 |
539105120 |
FRAME W/DECALS KOHLER Price: $1,068.89 |
| 20 |
539105121 |
FRAME W/DECALS KAWASAKI Price: $1,068.89 |
| 20 |
67-2590 |
OIL SEAL Price: $13.61 |
| 21 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 21 |
67-2620 |
BOLT Price: $1.89 |
| 22 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 22 |
67-2500 |
PLUNGER Price: $22.88 |
| 23 |
539104595 |
BUMPER, FRONT Price: $93.96 |
| 23 |
67-2510 |
SPRING Price: $8.45 |
| 24 |
539102484 |
BEARING RETAINER Price: $4.99 |
| 24 |
539103300 |
ZERK Price: $2.99 |
| 24 |
539103495 |
TIRE.11X4.00-5NHS.4PR.SMOOTH Price: $54.99 |
| 24 |
539104600 |
RIM Price: $27.38 |
| 24 |
539105307 |
ROLLER BEARING-CAGED 3 1/4' Price: $9.99 |
| 24 |
539106993 |
TIRE/WHEEL.CASTER This part replaces 539104594. Price: $99.99 |
| 24 |
539106994 |
RIM Price: $44.99 |
| 24 |
539114697 |
TIRE.11"X4"-5.4PLY.SMOOTH.KEND This part replaces 539106995. Price: $32.99 |
| 24 |
67-2520 |
PLUG Price: $5.65 |
| 25 |
539105543 |
SPACER Price: $8.99 |
| 25 |
86-6240 |
PLUG-TAPERED This part replaces 67-2570. Price: $5.11 |
| 26 |
539101907 |
HCS 1/2C X 5 1/2 Price: $9.99 |
| 26 |
67-2640 |
CAP Price: $10.52 |
| 27 |
539104589 |
YOKE WELDMENT ORANGE Price: $299.99 |
| 27 |
67-2660 |
O-RING Price: $6.73 |
| 28 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 28 |
67-2650 |
OIL FILTER CAP ASSEMBLY Price: $20.14 |
| 29 |
539101232 |
BUSHING, FLANGED Price: $11.99 |
| 30 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 31 |
539923787 |
BSHG .875 X 1.375 X .074 ZD Price: $2.99 |
| 32 |
539101151 |
RETAINING RING, 7/8" Price: $1.99 |
| 33 |
539103241 |
PUMP BELT Price: $34.99 |
| 34 |
539101177 |
KEY 5 MM SQ X 25 MM Price: $4.99 |
| 35 |
539101176 |
PULLEY Price: $37.99 |
| 36 |
539102717 |
SCREW 5/16C X 5/8 SQ HEAD Price: $2.99 |
| 37 |
596739801 |
PULLEYS This part replaces 539976688. Price: $29.99 |
| 38 |
596583901 |
Bolts This part replaces 539990730. Price: $2.99 |
| 39 |
539976695 |
BUSHING, IDLER FLANGE Price: $7.99 |
| 40 |
539103252 |
IDLER ARM WELDMENT Price: $72.99 |
| 41 |
539103300 |
ZERK Price: $2.99 |
| 42 |
539103429 |
PIVOT BUSHING Price: $1.89 |
| 43 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 44 |
539102337 |
TENSION ROD Price: $11.99 |
| 45 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 46 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 47 |
539104533 |
TENSION BRACKET Price: $14.99 |
| 48 |
539102817 |
COMPRESSION SPRING Price: $3.99 |
| 49 |
539105162 |
BATTERY GUARD W/DECA Price: $30.21 |
| 50 |
539102501 |
BATTERY STRAP Price: $3.16 |
| 51 |
539105119 |
ENGINE GUARD W/DECAL Price: $162.94 |
| 52 |
539103275 |
THROTTLE CABLE Price: $27.99 |
| 53 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 54 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 55 |
539104833 |
DECAL, ZTH4218 Price: $12.34 |
| 55 |
539104835 |
DECAL, ZTH4818 Price: $12.34 |
| 55 |
539104836 |
DECAL ZTH4820 Price: $14.20 |
| 55 |
539105077 |
DECAL, ZTH4821 Price: $12.84 |
| 55 |
539105602 |
DECAL ZTH4221 Price: $11.81 |
| 56 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 57 |
539104614 |
WEIGHT BLOCK Price: $59.76 |
