| Ref | Part Number | Description |
|---|
| 1 |
427106 |
Cover, Rear Price: Call Us |
| 2 |
04003-07 |
Bolt, Carriage 1/4-20 x 1/2" Price: Call Us |
| 3 |
04003-02 |
Bolt, Carriage 1/4-20 x 3/4" Price: Call Us |
| 4 |
425214 |
Bracket, Idler Stop Price: Call Us |
| 5 |
04019-02 |
Nut, Serrated Flange 1/4-20 Price: Call Us |
| 6 |
04041-07 |
Flatwasher, 3/8-.391 x .938 x .105 Price: Call Us |
| 7 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 8 |
482744 |
Pulley, 5.75 O.D. (Gasoline Engines) Price: Call Us |
| 8 |
482745 |
Pulley, 6.35 O.D. (Diesel Engine) Price: Call Us |
| 9 |
485697 |
Belt, STTII Pump Drive (Gasoline Engines) Price: Call Us |
| 9 |
485766 |
Belt, STTII Pump Drive (Diesel Engine) Price: Call Us |
| 10 |
04063-27 |
Key, 5mm x 5mm x 30mm Price: Call Us |
| 11 |
481884 |
Tapered Hub, 17mm Bore Price: Call Us |
| 12 |
483675 |
Pulley, 5.67 O.D. (Kawasaki & Kohler Only) Price: Call Us |
| 12 |
483829 |
Pulley, 5.67 O.D (Kubota Diesel Only) Price: Call Us |
| 12 |
485867 |
Pulley, 5.67 O.D. (35 BV Only) Price: Call Us |
| 13 |
04021-05 |
Nut, Center Lock 3/8-16 Price: Call Us |
| 14 |
04043-04 |
Flatwasher, 3/8-.391 x .938 x .105 HD Price: Call Us |
| 15 |
483214 |
Pulley, Idler 4" Price: Call Us |
| 16 |
48224 |
Bearing Price: Call Us |
| 18 |
04019-04 |
Nut, Serrated Flange 3/8-16 Price: Call Us |
| 21 |
482949 |
Pulley, 6.70 O.D. Price: Call Us |
| 22 |
43507 |
Stud, Anti-Rotation Price: Call Us |
| 23 |
04069-01 |
Pin, Rue Cotter Price: Call Us |
| 24 |
482845 |
Rod Assembly Price: Call Us |
| 25 |
04040-12 |
Flatwasher, 3/8-.438 x 1.00 x .083 Price: Call Us |
| 26 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 27 |
461661 |
Clutch Assembly, GT3.5 Price: Call Us |
| 27 |
461826 |
Clutch Assembly, GT5 (35BV) Price: Call Us |
| 27 |
462011 |
Clutch Assembly, GT3.5 (Diesel Engine) Price: Call Us |
| 28 |
04041-28 |
Flatwasher, 7/16-.469 x 1.50 x .1793 Price: Call Us |
| 29 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 30 |
04102-03 |
Bolt, Hex Head 7/16-20 x 2-1/4" (35BV) Price: Call Us |
| 30 |
04102-04 |
Bolt, Hex Head 7/16-20 x 2-1/2" (Kohler) Price: Call Us |
| 30 |
04103-02 |
Bolt, Hex Head M10-1.5 x 50 (Kawasaki) Price: Call Us |
| 31 |
04063-23 |
Key, 1/4 x 1/4 x 3-1/4” Price: Call Us |
| 33 |
481536 |
Tapered Hub, 1" Bore Price: Call Us |
| 34 |
04001-109 |
Bolt, Hex Head 1/4-20 x 1.375 Full Thread Price: Call Us |
| 35 |
04030-02 |
Lockwasher, 1/4" Price: Call Us |
| 36 |
48181 |
Pulley, Idler Price: Call Us |
| 37 |
482876 |
Belt, Deck Drive Price: Call Us |
| 38 |
04019-04 |
Nut, Serrated Flange 3/8-16 Price: Call Us |
| 39 |
04021-05 |
Nut, Center Lock 3/8-16 Price: Call Us |
| 40 |
483430 |
Spring, PTO (Diesel Engine) Price: Call Us |
| 40 |
484754 |
Spring, PTO (Gasoline Engines) Price: Call Us |
| 42 |
04001-171 |
Bolt, Hex Head 3/8-16 x 4-1/2" Price: Call Us |
| 44 |
43632 |
Pivot, Idler - PTO Price: Call Us |
| 45 |
481284 |
Bumper, Rubber Price: Call Us |
| 46 |
04019-03 |
Nut, Serrated Flange 5/16-18 Price: Call Us |
| 47 |
04001-19 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 48 |
04063-06 |
Key, 1/4 x 1/4 x 1-1/2" Price: Call Us |
| 50 |
461697 |
Spindle Assy., PTO Price: Call Us |
| 51 |
43534 |
Shaft, Deck Drive Price: Call Us |
| 52 |
481024 |
Seal Price: Call Us |
| 53 |
481022 |
Bearing Assembly, Tapered Price: Call Us |
| 54 |
43644 |
Spindle Housing Price: Call Us |
| 55 |
48677 |
Relief Fitting Price: Call Us |
| 56 |
48114-04 |
Grease Fitting, 1/4-28 Price: Call Us |
| 57 |
43296 |
Spacer, Inside Price: Call Us |
| 58 |
43312 |
Spacer, Outside Price: Call Us |
| 59 |
481025 |
Seal, 2" O.D. x 1.625 Bore Price: Call Us |
| 60 |
43297 |
Spindle Bushing, Bottom Price: Call Us |
| 61 |
481035 |
Nut, 1.06 - 18 Price: Call Us |
| 62 |
482438 |
Driveshaft Price: Call Us |
| 63 |
04063-20 |
Key, 1/4 x 1/4 x 1" Price: Call Us |
| 64 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" Price: Call Us |
| 65 |
04021-05 |
Nut, Center Lock 3/8-16 Price: Call Us |
| 66 |
04012-08 |
Set Screw, 3/8-16 x 3/4" Torx Head Price: Call Us |
| 67 |
452725 |
Pump Mounting Plate Weldment (Gasoline) Price: Call Us |
| 67 |
452728 |
Pump Mounting Plate Weldment (Diesel) Price: Call Us |
| 68 |
481309 |
Latch, Hood Price: Call Us |
| 69 |
04011-11 |
Screw, #10-32 x .563 Shakeproof Price: Call Us |
| 70 |
424138 |
Bracket, Spring Price: Call Us |
| 71 |
04001-45 |
Bolt, Hex Head 3/8-16 x 2" Price: Call Us |
| 72 |
04001-135 |
Bolt, Hex Head 3/8-16 x 1-3/4" Price: Call Us |
| 73 |
43286 |
Spacer Price: Call Us |
| 74 |
43063 |
Spacer Price: Call Us |
| 76 |
43631 |
Spacer Price: Call Us |
| 77 |
481531 |
Hinge, Belt Cover Price: Call Us |
