| Ref | Part Number | Description |
|---|
| 1 |
1744390 |
PAD-FUEL TANK Price: Call Us |
| 2 |
751-0531B |
Gas Gauge This part replaces 1756044. Price: $73.30 |
| 3 |
1756460 |
TANK-FUEL Price: Call Us |
| 4 |
1752795 |
FUEL LINE Not Available Price: |
| 5 |
726-0205 |
Hose Clamp This part replaces 1750687. Price: $3.71 |
| 6 |
1750962 |
SCR-FHP #1 Not Available Price: |
| 7 |
1754564STB |
SHIELD-HEAT RH Price: Call Us |
| 8 |
731-0108 |
Knob, Throttle Control This part replaces 1737118. Price: $8.12 |
| 9 |
1755904 |
THROTTLE-C Not Available Price: |
| 10 |
1755903 |
CHOKE CONT Not Available Price: |
| 12 |
1185712 |
SCREW Not Available Price: |
| 13 |
1752882GAR |
SHIELD-HEAT {3114GR} Price: Call Us |
| 13 |
1752882STB |
SHIELD-HEAT (RED) {3214GR} Price: Call Us |
| 14 |
BS-298090S |
Fuel Filter This part replaces 1727491. Price: $5.76 |
| 15 |
1754578GAR |
SHIELD-HEAT {3114GR} Price: Call Us |
| 15 |
1754578STB |
SHIELD-HEAT (RED) {3214GR} Price: Call Us |
| 19 |
1732137 |
SEALING-STRIP Price: Call Us |
| 21 |
1747738 |
CLIP-J Not Available Price: |
| 22 |
1745366 |
HANGER-CAB Not Available Price: |
| 23 |
1743683 |
ELBOW 45 D Not Available Price: |
| 24 |
1743685 |
PIPE-NIPPL Not Available Price: |
| 25 |
1743684 |
ELBOW-90 DEGREES Not Available Price: |
| 26 |
1744455 |
WASHER-SPE Not Available Price: |
| 28 |
1754563STB |
SHIELD-HEAT LH Price: Call Us |
| 29 |
710-0510 |
Screw, 7/16-20, 3.00, Gr5 This part replaces 1744454. Price: $9.78 |
| 30 |
712-0147 |
U-Type Speed Nut This part replaces 1185986. Price: $6.01 |
| 31 |
1186389 |
NUT-HF/LK 1/4-20 ZP Price: $3.05 |
| 32 |
710-0599 |
SCREW 1/4-20 X.500 This part replaces 1186307. Price: $3.86 |
| 35 |
1187474 |
KEY-.25 SQ Not Available Price: |
| 36 |
1747148 |
SHEAVE Not Available Price: |
| 37 |
917-3497 |
PTO CLUTCH ASSEMBLY This part replaces 1755341. Price: $587.56 |
| 38 |
1754787 |
CLUTCH-RETAINER Not Available Price: |
| 41 |
1754612 |
TRIM Not Available Price: |
| 42 |
1754887STB |
PIPE-EXHAUST Price: Call Us |
