TRIMMER ASSEMBLY
Parts (66)
| Ref | Part Number | Description |
|---|---|---|
| 0 | 640310 | CARBURETOR Price: $77.00 |
| 1 | 104-8714 | HOSE REEL FRAME ASM Price: $2,917.61 |
| 1 | 534234501 | Power Cord Price: $3.33 |
| 1 | 632538 | SHAFT & LEV Price: $5.16 |
| 2 | 104-8715 | CHAINGUARD-REEL, HOSE Price: $180.77 |
| 2 | 534193001 | Switch Price: $3.33 |
| 3 | 104-8799 | GUIDE-REEL, HOSE Price: $961.88 |
| 3 | 534162315 | Harness Price: $4.99 |
| 4 | 534356734 | R.H./L.H. Handle Price: $3.33 |
| 5 | 534156415 | Assist Handle Price: $4.99 |
| 6 | 534218105 | Bolt Price: $0.99 |
| 6 | 631616 | SHUTTER Price: $1.20 |
| 7 | 534437000 | Wing Nut Price: $3.33 |
| 7 | 650506 | SCREW Price: $0.87 |
| 8 | 534379803 | Upper Tube Price: Call Us |
| 9 | 534393300 | Screw Price: $3.33 |
| 10 | 534379802 | Lower Tube Price: $3.33 |
| 10 | 632566 | SHAFT & LEV Price: $3.86 |
| 11 | 534273524 | Motor Housing Price: Call Us |
| 12 | 534450007 | Motor Price: $3.33 |
| 13 | 534668005 | Shaft Adapter Price: Call Us |
| 14 | 534193700 | Screw Price: $1.99 |
| 14 | 631815 | SHUTTER Price: $1.20 |
| 15 | 534653000 | Washer Price: $0.99 |
| 15 | 630735 | SPRING Price: $1.25 |
| 16 | 534193800 | Screw Price: $3.33 |
| 16 | 632164 | FUEL FITTING Price: $5.95 |
| 17 | 534368001 | Guard Ass'y. Price: $3.33 |
| 18 | 534393500 | Nut Price: $0.99 |
| 19 | 534270100 | Hanger Price: $1.99 |
| 20 | 534393202 | Outer Tube Price: $5.99 |
| 21 | 534167215 | Rear Plate Price: $8.99 |
| 22 | 952710512 | Spool & Line Price: Call Us |
| 23 | 534316200 | O-Ring Price: $0.99 |
| 24 | 534166700 | Adapter Nut Price: $1.99 |
| 25 | 534819200 | Spring Price: $1.99 |
| 25 | 631867 | FLOAT BOWL Price: $2.34 |
| 26 | 534167935 | Hub Ass'y. Price: $3.33 |
| 26 | 632815 | SPRING This part replaces 632386. Price: $1.10 |
| 27 | 534270301 | Cotter Pin Price: $1.99 |
| 27 | 631024 | FLOAT SHAFT Price: $1.17 |
| 28 | 534167600 | Eyelet Price: $1.99 |
| 28 | 632019A | FLOAT This part replaces 632019. Price: $5.85 |
| 29 | 534167700 | Foam Pad Price: $3.33 |
| 29 | 631028A | GASKET This part replaces 631028. Price: $1.95 |
| 30 | 534367900 | Baffle Price: $3.33 |
| 30 | 631021B | INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 | 534356805 | Bushing Price: $1.99 |
| 31 | 631022 | CLIP Price: $1.25 |
| 32 | 534872701 | Endbell Ass'y. (Drive) Price: $3.33 |
| 33 | 534520022 | Washer Price: $1.99 |
| 34 | 534632001 | Wave Washer Price: $0.99 |
| 35 | 534367600 | Armature Ass'y. Price: $3.33 |
| 36 | 534367801 | Field Ass'y. Price: $3.33 |
| 36 | 640080 | NOZZLE Price: $4.95 |
| 37 | 534520031 | Washer Price: $1.99 |
| 37 | 632547 | O RING Price: $1.49 |
| 38 | 534246701 | Retaining Ring Price: $0.99 |
| 39 | 534260007 | Brush Holder Price: $2.99 |
| 40 | 534570009 | Brush Spring Price: $1.99 |
| 40 | 640008 | NUT Price: $5.16 |
| 41 | 534200018 | Brush Price: $1.99 |
| 42 | 534872601 | Endbell Ass'y. (Brush) Price: $3.99 |
| 43 | 534520020 | Lockwasher Price: $1.99 |
| 44 | 27110A | GASKET Price: $1.45 |
| 48 | 631027 | WELCH PLUG Price: $1.17 |
